Trend SignalTEK NT Copper and Fibre Network Transmission Tester - R156005

For a limited time only, buy a SignalTEK NT Network Transmission Tester and get a free gift from TREND Networks.
Register your purchase to receive 2x GbE Fibre Kit SX directly from the manufacturer. Offer valid between 1st October 2023 and 31st January 2024. Terms and conditions apply, for more information please visit promo.trend-networks.com.

Trend SignalTEK NT Copper and Fibre Network Transmission Tester - R156005

Presenting a clear Pass/Fail result for the link being tested the SignalTEK NT requires no configuration, just select a usage scenario to simulate the appropriate service, from VoIP to CCTV, Video or web traffic. Swiftly demonstrate correct cabling in installations such as SOHO or residential cabling where certification is cost prohibitive or where the end customer does not require the cable manufacturer’s warranty programs.

Advanced Testing Capability

The incorporated testing features of the Trend SignalTEK NT Copper and Fibre Network Transmission Tester are both numerous and exceedingly useful. Whether it be for installation testing or a troubleshooting/diagnostic task, the SignalTEK's functions are applicable for both cabling and active networks.

Monitor test connection speeds, port ID, ping, traceroute and IPv4/IPv6, while network load testing is carried out by the SignalTEK NT through switches which simulate CCTV/IPTV/VoIP/Web traffic. PoE/PoE+ (Power over Ethernet) verification displays the available voltage at device locations, confirming if the available power meets the PoE device requirements. Check Ethernet connectivity at device locations to 10/100/1000 Mb/s and verify network configurations; device IP/gateway address/subnet mask.

Use the SignalTEK NT Tester to stress test networks before installing bandwidth hungry devices, or test the throughput of an industrial Ethernet LAN. Identify network connection problems as hardware, network or configuration faults and ping local network devices & Internet URLs. This device can even count the number of hops between network points with built-in traceroute tests. With a compatible amplifier probe, operators can identify & trace cables and if a compatible SFP is utilised, fibre cable testing provides optical power indication.

Example Problems and Solutions

• Workstation or Laptop with an exceptionally slow network access - SignalTEK NT can run a simplified transmission test to check network performance.
• A 100Mb/s LAN environment is upgraded to 1 Gb/s - SignalTEK NT can check if the existing cabling can support up to 1Gb/s Ethernet.
• An existing LAN installation is upgraded to VoIP - SignalTEK NT can ascertain if both the cabling and active components can support VoIP traffic.
• After MACs (Moves/Adds/Changes) of active devices - SignalTEK NT can ensure the minimum bandwidth requirements are met.
• In industrial Ethernet applications - SignalTEK NT can be used to verify cabling performance to 100Mb/s or Gigabit requirements.

Enhanced Reporting

The fast & flexible Trend Trend SignalTEK NT Copper and Fibre Network Transmission Tester includes automatic generation of reports in either PDF or CSV format, making documentation effortless. Each report comes with a completely customisable summary page ready for you to add your own logo, company and personal details. These reports can be set to show either passed, failed or all tests results including if installed data cables can carry Gigabit Ethernet traffic at full speed with no errors and confirmed wiremap results. Upload reports to a USB memory stick or with the free TREND AnyWARE app installed transfer test data directly to a connected smart device. Send reports from anywhere via the app, even whilst still on-site.

Ergonomic Handheld Design

Built for life in the field, the rugged casing of the SignalTEK NT provides protection against knocks and drops. Support for shielded and unshielded twisted pair cables is provided including Cat 5e, Cat 6, Cat 6A and Cat 7 TIA 568A and 568B wiring schemes. There is no requirement for annual calibration and this Transmission Tester even includes field replaceable RJ45 contacts to eliminate downtime from damaged or worn connectors.

Key Features

• For installing, maintaining or troubleshooting data cabling and Ethernet networks
• Affordable Gigabit performance testing for passive cabling or active networks
• Copper cable wiremapping with TDR fault location
• Simulates network traffic to the IEEE802.3ab standard
• Simulate the appropriate service, from VoIP to CCTV, Video or web traffic
• Wiremap testing can detect open, shorts, miswires & split pairs to the TIA-568 standard
• Port blink capability for visual cable trace
• Displays port ID of LLDP/CDP enabled switches.
• Monitor test connection speeds, port ID, ping, traceroute and IPv4/IPv6
• PoE/PoE+ verification displays the available voltage at device locations
• Check Ethernet connectivity at device locations to 10/100/1000 Mb/s
• Verify network configurations - device IP/gateway address/subnet mask.
• Stress test networks before installing devices
• Test the throughput of an industrial Ethernet LAN
• Identify network connection problems as hardware, network or configuration faults
• Ping local network devices & Internet URLs
• Traceroute tests count the number of hops between network points
• Automatic generation of reports in either PDF or CSV format
• Reports customisable with logo, personal and company details
• Upload reports to a USB memory stick
• Send reports to smart device using FREE TREND AnyWARE app
• Rugged ergonomic handheld design
• No requirement for annual calibration
• Includes field replaceable RJ45 contacts
• Requires minimal training

Trend part number: R156005
