Drummond SMKIT20 Smart Meter Installation Kit

Be the first to review this product

  • The complete set for checking that electrical circuits are safely isolated
  • Install smart meters in complete safety thanks to range of voltage detectors
  • Non-contact detector, single-pole detector and test lamp all included

rrp £274.00

now £217.50 (Ex. VAT) £261.00 (Inc. VAT)

rrp £274.00

OR

Please select a free gift below.

  • Description

    Drummond SMKIT20 Smart Meter Installation Kit

    The Drummond SMKIT20 Smart Meter Installation Kit contains a range of testers for checking that electrical installations are safely isolated / dead. This is ideal for those installing SMETS1 and SMETS2 smart meters in accordance with the latest guidelines. The kit contains a socket tester, non-contact voltage detector, single-pole voltage detector, test lamp, proving unit and carry case.

    A Martindale TEK101 Non-Contact Voltage Indicator glows red and emits an audible warning when it detects voltages between 180V and 600V AC. This ergonomic, user-friendly tester has an integrated proving unit for the sensor, batteries and LEDs.

    An inbuilt proving device is also found in the contact, single-pole Martindale VT7 which detects AC/DC voltage between 50V and 600V. It is specifically designed for use when the user is wearing protective gloves or gauntlets.

    In order to check sockets, a Martindale BZ101 Buzz-IT Socket Tester is included. This simple plug-in tester can detect 28 different faults in UK wall sockets and relates the results back to the user via a clear LED display.

    A Drummond MTL20 Test Lamp is also provided so that the user can perform safe isolation testing on Cat IV supply side circuits. It has a 360˚ LED display and detects voltage between 50V and 600V in addition to distinguishing between different voltages in a three-phase systems. A Martindale PD440 is included as standard in order to verify the test lamp’s performance.

    A carry case which has space for all the testers is included as standard and even has a compartment for the PD440 to be used without being taken out of the case.

    Martindale part number: MARSMKIT20

    Key Features of the SMKIT20

    • Martindale TEK101 Non-Contact Voltage Indicator
    • Martindale BZ101 Buzz-IT Check Plug
    • Martindale VT7 Single Pole Voltage Detector
    • Drummond MTL20 Test Lamp
    • Martindale PD440 Proving Unit
    • Combination soft carry case
  • Specification

    Martindale BZ101 Buzz-IT Check Plug

    • Operating voltage range: 200-250V
    • Frequency range: 30-70Hz
    • Power consumption: Check Plug <1.5W
    • Temperature range: -10 to 40°C at max, 60% RH
    • Power supply: from mains

    Martindale VT7

    Electrical

    • Audible and visual indication
    • Voltage range: 50V - 600V AC rms.
    • Frequency range: 50 - 60Hz
    • Test current: <5μA

    Environmental

    • Temperature (Operating & Storage): -10°C to 55°C
    • Humidity (Operating & Storage): ≤ 85% R.H.
    • Altitude: up to 2000m

    General

    • Power: 9V, PP3 alkaline battery included (IEC 6LR61, NEDA 1604A)
    • Current consumption: 34mA max
    • Dimensions: 236(L) x 44(W) x 33(D) mm
    • Weight: 120g (battery included) approx

    Safety

    • Conforms to BS EN61010-1 CAT IV 300V, CAT III 600V
    • Class II, Double Insulation
    • Pollution Degree: 2
    • IP rating: IP54
    • Water resistant

    EMC

    • Conforms to BS EN61326-1

    Drummond MTL10

    • Maximum Working Voltage: 500V AC, 750V DC
    • Voltage Ranges: 50, 100, 200, 400V AC/DC
    • Range Detection: Automatically
    • Response Time: <0.1s
    • Frequency Range: DC, 0-65Hz
    • Test Current (500V AC/DC): <3.5mA
    • Test Current with switches depressed: 28mA at 240V AC, 60mA at 500V AC
    • Temperature Range: -10C to 55C
    • Humidity: max 85% rel.H
    • Measurement Category: CAT IV 600V, CAT III 1000V
    • Pollution Degree: 2
    • Protection Degree: IP67
    • Dimensions: 213 x 112 x 72mm
    • Weight: 350g

    Martindale PD440

    • Output Voltage: 440V nominal
    • Operating Temperature:  -10°C to +40°C at max 70% RH
    • Battery: 6 x LR6 / MN1500 1.5V alkaline batteries or equivalent
    • Dimensions: 143 x 84 x 50mm
    • Weight: 400g approx including battery

    Martindale TEK101

    • Voltage Range: 100-600V
    • Frequency Range: 50Hz to 50kHz
    • Integrated self test proving function sensitivity: Registers at 3mm for 100V, 50Hz, 23mm for 240V, 50Hz (distances are from the tip of the unit to a flat PVC twin core and earth cable suspended in free space)
    • Visual Indication: Red LED
    • Audible Indication: 2kHz tone
    • Battery low: Green LED
    • Operating temperature: 0°C to 40°C
    • Supply: 9V alkaline battery, MN1604 or equivalent (excluded)
    • Housing: Flame retardant ABS
    • Dimensions: 202 X 32 X 22mm
    • Weight: 140g approx (excluding battery)
  • Supplied Accessories

    • Martindale TEK101 Non-Contact Voltage Indicator
    • Martindale BZ101 Buzz-IT Check Plug
    • Martindale VT7 Single Pole Voltage Detector
    • Drummond MTL20 Test Lamp
    • Martindale PD440 Proving Unit
    • Combination soft carry case
