Protimeter Hygromaster 2 Humidity and Temperature Meter

Be the first to review this product

  • Measures surface temperature from -20˚C to 80˚C using probe or infrared
  • Measures air temperature and relative humidity using Quickstick or Hygrostick
  • Capable of performing ERH measurements in concrete flooring

rrp £389.00

now £345.00 (Ex. VAT) £414.00 (Inc. VAT)

rrp £389.00

* Required Fields

Please select a free gift below.

  • Description

    Protimeter Hygromaster 2 Humidity and Temperature Meter

    The Protimeter Hygromaster 2 Humidity and Temperature Meter deploys a multitude of different methods for measuring air and surface temperature in addition to ambient relative humidity (RH) and even equilibrium relative humidity (ERH) in concrete depending on the user’s chosen accessory kit.

    The hygrometer measures temperature from -20˚C to 80˚C via non-contact infrared surface temperature measurement. It is also compatible with the optional BLD5805 contact surface temperature probe which can measure temperature from 0˚C to 70˚C with increased accuracy.

    In terms of air temperature, the Protimeter Hygromaster 2 tester can take readings from 0˚C to 50˚C using either the Hygrostick provided in kit BLD7750 or the Quikstick provided in kit BLD7751. The difference between the two probes is in RH measurements where the Hygrostick measures between 30% and 100% whilst the Quickstick measures between 1% and 100%.

    The Quikstick is recommended for general measurement whilst the Hygrostick is more suited to high RH measurements in harsher environments such as ERH concrete floor measurement.

    In addition to these measurement functions, the Protimeter Hygromaster 2 tester can calculate surface proximity to dew point in addition to various other psychometric calculations. It can also be used to investigate dew point and condensation conditions.

    The Protimeter Hygromaster 2 has a user-friendly interface with intuitive menus and simple navigation buttons. It can store up to 8000 measurements on its internal memory with a time-and-date stamp. It comes supplied with carry case and batteries as standard whilst you can choose between the Hygrostick and Quickstick sensors by selecting the correct kit in the drop down menu above. A two-year warranty is provided by the manufacturer.

    Protimeter part number: BLD7750 / BLD7751

    Key Features Protimeter Hygromaster 2

    • Surface temperature range (IR): -20˚C to 80˚C
    • Surface temperature range (contact): 0˚C to 70˚C
    • Air temperature range: 0˚C to 50˚C
    • RH range (Hygrostick): 30% to 100%
    • RH range (Quickstick): 1% to 100%
    • Suited for general measurement or ERH measurement
    • Calculation of dew point and surface proximity to dew point
    • Simple, user-friendly operation
    • Large internal memory for 8000 readings
    • Two-year warranty

    Protimeter Hygromaster 2 Kit Comparison

    The BLD7750 Kit includes:

    • Protimeter Hygromaster 2
    • Hygrostick sensor (30 - 100 %rh)
    • Carry case
    • 2 x AA batteries
    • Instructions

    The BLD7751 Kit includes:

    • Protimeter Hygromaster 2
    • Quickstick sensor (0 - 100 %rh)
    • Carry case
    • 2 x AA batteries
    • Instructions
  • Specification

    Dimensions (LxWxH)

    • 7 in x 3.2 in x 1.5 in (178 mm x 81 mm x 38 mm)

    Display

    • 2” TFT colour display, 176 x 220, 256K colour

    Batteries (Included)

    • 9V Alkaline

    Warranty

    • 24 months on mechanical or manufacturing defects. Does not include wearing part or accessories.

    Plug in Temperature Probe Surface Temperature Probe - BLD5805

    • Range 32°F to 158°F (0°C to 70°C)
    • Accuracy at 77°F (25°C) +/- 1.3°F (0.7°C)

    Infrared Surface Temperature Range

    • IR Based – With 12:1 (D:S) Ratio Range -4°F to 176°F (-20°C to 80°C) Accuracy ±3.6°F (±2°C)

    HygroStick Data (Nominal)

    • 30% to 40% RH (±3% RH) at 68oF (20oC).
    • 41% to 98% RH (±2%) at 68oF (20oC).
    • Range 32°F to 122°F (0°C to 50°C) ±0.6°F (±0.3°C)

    QuikStick and QuikStick ST Data (Nominal)

    • 0% to 10% RH, ±3% RH at 68°F (20°C),
    • 10% to 90% RH, ±2% RH at 68°F (20°C),
    • 90% to 100% RH, ±3% RH at 68°F (20°C),
    • Range 32°F to 122°F (0°C to 50°C) ±0.6°F (±0.3°C)
    • Nominal response 30% to 90% and back to 30% RH in 45 seconds @ 68°F (20°C)

    Data Storage

    • Store up to 8,000 results with date and time stamp from all instrument functions with the push of a button. Store 6100 results with automatic logging.
  • Supplied Accessories

    BLD7750

    • Protimeter Hygromaster 2 Meter
    • Hygrostick sensor (30 - 100 %rh)
    • Carry case
    • 2 x AA batteries
    • Instructions

    BLD7751

    • Protimeter Hygromaster 2 Tester
    • Quickstick sensor (0 - 100 %rh)
    • Carry case
    • 2 x AA batteries
    • Instructions
  • Product Documents

    Product Attachments

    View FileProtimeter Hygromaster 2 Datasheet    Size: (315.88 KB)
