Testo 760-3 True RMS Digital Multimeter

SKU: TESTO7603
  • Measures all basic electrical variables including voltage up to 1000V
  • Automatically detects measurement parameters based on engaged sockets
  • Error message appears when user attempts measurement with incorrect settings
More Info
In Stock - Available Next Day

Testo 760-3 True RMS Digital Multimeter

The Testo 760-3 True RMS Digital Multimeter is the most advanced multimeter in Testo’s 760 range, featuring True RMS and very large measurement ranges over all major electrical variables required by the professional electrician. Additionally, the device automatically detects measurement parameters and prevents incorrect settings leading to greater accuracy and speedier use.

The Testo 760-3 can measure AC/DC voltage, AC/DC current, resistance, frequency, capacitance, and temperature with maximum values of 1000V, 10A, 60MΩ, 60MHz, 60,000µF, and 500℃. Diode and continuity testing are also possible whilst the Testo 760-3’s basic accuracy is an excellent ±0.1%, in part helped by its True RMS capabilities. The user can have further confidence in the readings as the device is rated as Cat IV up to 600V and Cat III up to 1000V.

In addition to this excellent measuring capacity, the Testo 760-3 also has several practical features to help the user. First and foremost, the device automatically detects measurement parameters based on the engaged sockets and then lights up the correct function key so the measurement settings are visible at a glance. Moreover, the large, backlit screen shows an error message if the user attempts the wrong measurement so taking readings with incorrect settings is impossible with the Testo 760-3. The function keys themselves are also an upgrade on the traditional multimeter dial as they make the device simpler and quicker to use.

The user benefits from the Testo 760-3’s two-year warranty and sturdy build quality. Overall, the excellent measurement ranges and advanced, modern operation of the Testo 760-3 make it a brilliant tool for measuring all basic electrical variables.

Testo part number: 05907603

Key Features

  • True RMS leading to 0.1% basic accuracy
  • AC/DC Voltage: 0.1mV to 1000V
  • AC/DC Current: 0.1µA to 10A AC/DC
  • Resistance: 0.1 to 60MΩ
  • Frequency: 0.001Hz to 60MHz
  • Capacitance: 0.001nF to 60,000µF
  • Temperature: -20 to +500℃
  • Diode test
  • Continuity test
  • Cat IV up to 600V / Cat III up to 1000V
  • Modern function keys rather than traditional multimeter dial
  • Automatically detects parameters based on engaged sockets
  • Buttons illuminated depending on parameters
  • No possibility of incorrect settings
  • Sizeable, backlit digital screen
  • 2-year warranty

What's In The Box?

  • Testo 760-3 True RMS Digital Multimeter
  • Testo 760-3 True RMS Digital Multimeter instructions
  • Test leads
  • 3 x 1.5V AAA batteries
Specification
  • Basic accuracy: 0.1%
  • DC voltage range: 0.1mV to 1000V
  • AC voltage range: 0.1mV to 1000V
  • DC current range: 0.1µA to 10A
  • AC current range: 0.1µA to 10A
  • Resistance range: 0.1 to 60MΩ
  • Frequency range: 0.001Hz to 60MHz
  • Capacitance range: 0.001nF to 60,000µF
  • Diode test: Yes
  • Continuity test: Yes
  • Display counts: 6,000
  • Measurement category: Cat IV to 600V / Cat III to 1000V
  • Protection class: IP 64
  • Operating temperature: -10 to +50℃
  • Storage temperature: -15 to 60℃
  • Dimensions: 167 x 84 x 45mm (L x W x H)
  • Weight: 340g
  • Warranty: 2 years
  • Authorisations: TUV, CSA, CE
  • Standards: EN 61326-1
