Testo 770-2 True RMS Clamp Meter

Be the first to review this product

  • True RMS measurement over all electrical variables including µA
  • Unique pincer clamp mechanism for accessing awkward wiring
  • Automatically detects AC or DC as well as selecting relevant measurement parameters

rrp £119.00

now £103.00 (Ex. VAT) £123.60 (Inc. VAT)

rrp £119.00

Please select a free gift below.

"A unique pincer clamp brings access to awkward wiring"

  • Description

    Testo 770-2 True RMS Clamp Meter

    The Testo 770-2 True RMS Clamp Meter combines clever mechanical and electrical features to make it an extremely practical, comprehensive measurement instrument. It can measure AC/DC voltage, AC/DC current (including a µA range), resistance, capacitance, frequency and temperature so it is ideal of assessing the health of an electrical circuit. The Testo 770-2 can perform diode and continuity testing as well as Inrush current measurements for assessing current during start up phases. Data hold, True RMS, and Min/Max measurement also contribute to an excellent all-round clamp meter.

    The first thing that stands out about the Testo 770-2 is its unique pincer clamp. This mechanism makes it easier to access awkward wiring because the fixed jaw of clamp can be worked in behind a wire before the fully retractable pincer jaw comes up to meet it (watch the video to see this in action).

    The other main user-friendly aspect of the Testo 770-2 is the automatic AC/DC and parameter detection that senses whether voltage and current are AC or DC as well as selecting other appropriate parameters, thus making the device simpler to use and helping to avoid errors. The clear, two-line display gives the user simultaneous real-time readings for two different variables and the portable, lightweight design makes it easy to use and transport.

    The clever pincer clamp and usual Testo build quality combine to create an excellent multi-purpose clamp meter that is suitable for inspections and troubleshooting.

    Testo part number: 05907702

    Key Features

    • True RMS
    • 0.8% basic accuracy
    • AC/DC voltage range: 1mV to 600V
    • Resistance range: 0.1Ω to 40MΩ
    • Frequency range: 0.001Hz to 10kHz
    • Capacitance range: 0.001µF to 100µF
    • Diode and continuity testing
    • Cat IV to 600V
    • Unique pincer clamp
    • Two-line, backlit screen
    • Automatically detects AC or DC for voltage/current
    • Automatically selects parameter
    • Two-year warranty
  • Specification

    • True RMS: Yes
    • Basic accuracy: 0.8%
    • Voltage range: 1mV to 600V AC/DC
    • Current range: 0.1 to 400A AC/DC
    • µA range: 0.1 to 400µA AC/DC
    • Resistance range: 0.1Ω to 40MΩ
    • Frequency range: 0.0001Hz to 10kHz
    • Capacitance range: 0.001µF to 100µF
    • Temperature measurement: -20 to +500℃
    • Continuity testing: Yes
    • Diode test: Yes
    • Hold: Yes
    • MinMax: Yes
    • Inrush current measurement: Yes
    • Display (counts): 4,000
    • Measurement category: Cat IV 600V / Cat III 1000V
    • Operating temperature: -10 to +50℃
    • Storage temperature: -15 to +60℃
    • Dimensions: 243 x 96 x 43mm (L x W x H)
    • Weight: 378g
    • Warranty: 2 years
    • Authorisations: TUV, CSA, CE
    • Standards: EN 61326-1, EN 61140
  • Supplied Accessories

    • Testo 770-2 True RMS Clamp Meter
    • Testo 770-2 True RMS Clamp Meter instructions
    • Batteries
    • Measuring cables
