Specification
Features
- Infrared resolution: 640 x 480 (307,200 pixels)
- SuperResolution: No
- IFOV with standard lens (spatial resolution): 0.93 mRad, D:S 1065:1
- Field of view: 34 °H x 24 °V
- Minimum focus distance: 15 cm (approx. 6 in)
- MultiSharp Focus: No
- LaserSharp Auto Focus: Yes, for consistently in-focus images
- Laser distance meter: Yes, calculates distance to the target for precisely focused images and displays distance on screen
- Advanced manual focus: Yes
- Wireless connectivity: Yes, to PC, iPhone® and iPad® (iOS 4s and later), Android™ 4.3 and up, and WiFi to LAN (where available)
- Fluke Connect app compatible: Yes*, connect your camera to your smartphone, and images taken automatically upload to the Fluke Connect app for saving and sharing
- Fluke Connect Assets: Through the desktop, assign images to assets, easily compare measurement types in one location and create reports
- Fluke Connect instant cloud upload: Yes*, connect your camera to your building’s WiFi network, and images taken automatically upload to the Fluke Connect system for viewing on your smartphone or PC
- Fluke Connect instant server upload: Yes**
- IR-Fusion technology: Yes, adds the context of the visible details to your infrared image
- Ruggedised touchscreen display: 3.5 inch (landscape), 640 x 480 LCD
- Ergonomic design: Pistol-grip design for one-handed use
- Thermal sensitivity (NETD)**: ≤0.075 °C at 30 °C target temp (75 mK)
- Level and span: Smooth auto and manual scaling
- Touchscreen adjustable level/span: Yes. Span and level can be easily and quickly set by simply touching the screen
- Fast auto toggle between manual and auto modes: Yes
- Fast auto-rescale in manual mode: Yes
- Minimum span (in manual mode): 2.0 °C (3.6 °F)
- Minimum span (in auto mode): 3.0 °C (5.4 °F)
- Built-in digital camera (visible light): 5MP
- Frame rate: 60 Hz or 9 Hz versions
- Laser pointer: Yes
- LED light (torch): Yes
- Digital zoom: No
Data Storage and Image Capture
- Extensive memory options: Removable 4 GB micro SD memory card, 4 GB internal flash memory, save to USB flash drive capability, upload for permanent storage
- Image capture, review, save mechanism: One-handed image capture, review, and save capability
- Image file formats: bmp, jpeg, is2
- Memory review: Thumbnail and full screen review
- Software: Full analysis and reporting software with access to the Fluke Connect system
- Analyse and store radiometric data on a PC: Yes
- Export file formats with Fluke Connect software: Bitmap (.bmp), GIF, JPEG, PNG, TIFF
- Voice annotation: 60 seconds maximum recording time per image; reviewable playback on camera, optional Bluetooth headset available but not required
- IR-PhotoNotes: Yes - 2 images
- Text annotations: Yes. Including standard shortcuts as well as user programmable options
- Video recording and formats: No
- Remote control operations: Remote display through Fluke Connect
- Auto capture (temperature and interval): No
Battery
- Batteries (field-replaceable, rechargeable): Two lithium ion smart battery packs with five-segment LED display to show charge level
- Battery life: 2-3 hours per battery (actual life varies depending on settings and usage)
- Battery charging time: 2.5 hours to full charge
- Battery charging system: Two-bay battery charger or in-imager charging. Optional 12 V automotive charging adapter
- AC operation: AC operation with included power supply (100 V AC to 240 V AC, 50/60 Hz)
- Power saving: User selectable sleep and power off modes
Temperature Measurement
- Temperature measurement range (not calibrated below -10 °C): -20 °C to +650 °C (-4 °F to +1,202 °F)
- Accuracy: ±2 °C or 2 % (at 25 °C nominal, whichever is greater)
- On-screen emissivity correction: Yes (both value and table)
- On-screen reflected background temperature compensation: Yes
- On-screen transmission correction: Yes
- Line temperature graph: No
Colour Palettes
- Standard palettes: 9: Rainbow, Ironbow, Blue-Red, High Contrast, Amber, Amber Inverted, Hot Metal, Grayscale, Grayscale Inverted
- Ultra Contrast palettes: 9: Rainbow, Ironbow, Blue-Red, High Contrast, Amber, Amber Inverted, Hot Metal, Grayscale, Grayscale Inverted
Smart Lenses
- Macro-25 micron lens: 25 MAC2: Yes
- 2 x telephoto lens: TELE 2: Yes
- 4 x telephoto lens: TELE 4: Yes
- Wide angle lens: WIDE 2: Yes
General Specifications
- Colour alarms (temperature alarms): High temperature, low temperature, and isotherms (within range)
- Infrared spectral band: 7.5 μm to 14 μm (long wave)
- Operating temperature: -10 °C to +50 °C (+14 °F to +122 °F)
- Storage temperature: -20 °C to +50 °C (-4 °F to +122 °F)
- Relative humidity: 10 % to 95 % non-condensing
- Centre-point temperature measurement: Yes
- Spot temperature: Hot and cold spot markers
- User-definable spot markers: No
- User defined measurement boxes: 1 expandable-contractible measurement box with MIN-MAX-AVG temp display
- Hard Case: Rugged, hard carrying case; soft transport bag
- Safety: IEC 61010-1: Overvoltage category II, Pollution Degree 2
- Electromagnetic compatibility: IEC 61326-1: Basic EM environment. CISPR 11: Group 1, Class A
- Australian RCM: IEC 61326-1
- US FCC: CFR 47, Part 15 Subpart B
- Vibration: 0.03 g2/Hz (3.8 g), 2.5 g IEC 60068-2-6
- Shock: 25 g, IEC 68-2-29
- Drop: Engineered to withstand 2 meter (6.5 feet) drop with standard lens
- Size (H x W x L): 27.7 x 12.2 x 16.7 cm (10.9 x 4.8 x 6.5 in)
- Weight (battery included): 1.04 kg (2.3 lb)
- Enclosure rating: IEC 60529: IP54 (protected against dust, limited ingress; protection against water spray from all directions)
- Warranty: Two-years (standard), extended warranties are available
- Recommended calibration cycle: Two-years (assumes normal operation and normal ageing)
- Supported languages: Czech, Dutch, English, Finnish, French, German, Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Simplified Chinese, Spanish, Swedish, Traditional Chinese, and Turkish
- RoHS compliant: Yes
* Please Note: Fluke Connect analysis and reporting software is available in all countries but Fluke Connect is not. Please check availability with your authorised Fluke distributor.
** Indicates Fluke Connect™ features that will be available soon. Watch the Fluke website for software and firmware updates. |
