Protimeter Timbermaster BLD5609 Wood Moisture Meter

  • Moisture content measurement from 7% to 99% in wood
  • Measures over 150 different wood species
  • Automatic temperature compensation with optional probe
More Info

Protimeter Timbermaster BLD5609 Wood Moisture Meter

The Protimeter Timbermaster BLD5609 Wood Moisture Meter is the direct replacement for the previous Protimeter Timbermaster BLD5609 and provides the user with the same ability to measure moisture content between 7% and 99% in 150 wood species. This large range of different wood types is possible thanks to to eight calibration scales and nine different in built species groups. Readings are taken via two integrated pins on top of the device although there is also an input for a hammer probe.

Readings are displayed on the Protimeter Timbermaster’s clear LCD screen and the user benefits from the device’s simple push-button operation. The lightweight, rugged design mean that the device can be easily stored and this is also aided by an integrated wrist strap and a protective cap for the electrodes.

Even more functionality is available with the Protimeter Timbermaster Plus Kit which has a temperature probe. This allows automatic temperature correction for even more accurate measurement of wood moisture content.

  Protimeter Timbermaster Standard Kit (BLD5609) Protimeter Timbermaster Plus Kit (BLD5605)
Timbermaster Moisture Meter
Calibration Check Device
Heavy Duty Probe
Temperature Probe
Zip pouch

Protimeter part number: BLD5609

Protimeter moisture meters by applications and functions

  Protimeter Aquant Protimeter BLE Protimeter Digital Mini Protimeter Hygromaster 2 Protimeter Hygromaster L Protimeter Mini Protimeter Mini C Protimeter MMS3 Protimeter ReachMaster Pro Protimeter Surveymaster2 Protimeter Timbermaster Protimeter MMS3 Flooring Kit
Find your Meter by application
Building Construction
Building Survey
Concrete floors
Flood damage restoration
Home Inspection
HVAC Commissioning
HVAC Commissioning
Industrial Coatings
Marine Surveys
Wood Floors
Wood Working
Find your Meter by function
Pin moisture measurement
Non-evasive Moisture Measurement
Non-contact Temperature Measurement
Plug in Temperature Probe
Ambient Humidity
Ambient Temperature
Psychorometric Humidity Readings
Data Logging
WME Accessory Port

Key Features

  • Measures wood moisture content from 7% to 99%
  • Over 150 different wood species measured
  • Eight in-built calibration scales
  • Nine different species groups
  • Two integrated moisture pins
  • Simple operation
  • Lightweight and sturdily designed
  • Integrated wrist strap and protective cap
  • Input for hammer probe (optional)
  • Input for temperature probe (optional)
  • Automatic temperature compensation with probe
  • 2-year warranty

What's In The Box?

  • Protimeter Timbermaster Moisture Meter
  • Calibration check device
  • 2 x AA batteries
  • Instructions
  • Heavy duty probe
  • Zip pouch

Protimeter Timbermaster Plus Kit adds:

  • Temperature probe
  • Range: 7% to 99.9%
  • Display: Digital LCD display, resolution 1/10 of 1%
  • Species correction: Nine species groups built in
  • Power: 2 x AA batteries (included)
  • Dimensions: 180 x 28 x 49mm
  • Weight 150g
