Specification
Chauvin Arnoux CA1110 Light Meter Measurement - Measurement range: 0.1Lux to 200,000Lux / 0.01fc to 18580fc
- Resolution: 0.1 lx (0.1 lx to 999.9 lx); 1 lx (1 000 lx to 9,999 lx); 10 lx (10,000 lx to 99.99 klx); 100 lx beyond / 0.01 fc (0.01 fc to 99.99 fc) 0.1 fc (100.0 fc to 999.9 fc) 1 fc (1,000 to 9.999 fc) 10 fc beyond
- Intrinsic uncertainty (Class C luxmeter as per the NF C 42-710 standard): ± 3% of reading on incandescent sources (by default); ± 6% of reading on LEDs (3,000 K to 6,000 K); ± 9% of reading on fluorescent sources
- Intrinsic uncertainty (with compensation): LED mode - ± 4% of reading (at 4,000 K); Fluorescent mode - ± 4% of reading (type F11, 4,000 K)
Functions - Recording: Manual start/stop on the product, short press for MEM - spot recording; Long press for REC: recording at the rate of the current mode; programmed recording - Start date, recording interval (from 1 minute to 2 hours) and end date are defined using the PC software
- Data storage: >1 million points
- Min-Avg-Max-Hold: Yes
- MAP mode: The MAP function can be used to map the lighting on a surface or in a room. In this way, the lighting measurements are saved in the same le.
- Units: Lux or fc
- Backlighting: Yes
- Automatic power-off: Yes
Power Supply - Type: 3 x 1.5 V AA / LR6 alkaline batteries. Connection to the mains possible with the mains / micro-USB adapter offered as an accessory.
- Battery life: 500 hrs (portable mode) / 3 years of recording (15-minute measurement interval)
Physical Specifications - Interfaces: Bluetooth / USB
- Mounting: Casing equipped with a magnet, a wall-mount system and a slot for suspending the product. Compatible with the Multi x accessory.
- Dimensions: 150 x 72 x 32mm (casing) / 67 x 64 x 35mm (sensor)
- Weight: 345g
- Ingress protection: IP50
- Product operating ranges: -10˚C to 60˚C / 0 to 90%
- Compliance: IEC61010-1 / IEC 61326-1 / Class C luxmeter as per the French NF C 42-710 standard based on the CIE guidelines
General - Data Logger Transfer Windows PC software functions: Display as a graph or a table of values / Data export in graph or Excel table form
Real-time mode / Automatic report generation in Word format / Data format compatible with the Dataview software offered as an accessory
- Warranty: 2 years
Chauvin Arnoux CA1227 Thermo-Anemometer Air flow velocity - Range: 0.25m/s to 35m/s
- Resolution: 0.01m/s (0.25m/s to 2.99m/s); 0.1m/s (≥3m/s)
- Accuracy: ±3% ±4 counts
Volume flow - Range: 0 to 2999m3/h
- Resolution: 0.01 m3/h ( 0.00 to 2.99 m3/h); 0.1 m3/h ( 3.0 to 99.9 m3/h); 1 m3/h (100 to 2,999 m3/h)
- Accuracy: ±8%
Temperature - Sensor type: CTN
- Range: -20˚C to 50˚C
- Resolution: 0.1˚C
- Accuracy: ±0.8˚C (0 to 50˚C)
Functions - Recording: Manual Start / Stop on the product: short press for MEM spot recording / Long press for REC recording at the rate of the current mode; Programmed recording: start date, recording interval (1 minute to 2 hours) and end date defined using the PC software
- Data storage: >1,000,000 values
- Min/Max/Average/Data Hold: Yes
- MAP Mode: The MAP function can be used to map the air speeds measured
Flow-rate measurement: Yes, direct reading with the cones proposed as accessories or on the basis of a surface de ned by the user.
- Backlighting: Yes
- Units: Air-speed units: m/s, km/h, fpm, mph; Air flow-rate units: m3/s, m3/h, l/s, cfm; temperature: ˚C, ˚F
- Automatic power off: Yes
Power Supply - Type: 3 x AA 1.5V batteries; Mains connection possible with the mains / micro-USB adapter offered as an accessory.
- Battery life: 200 hrs (portable mode) / 8 days of recording (15-minute intervals)
Physical Specifications - Interfaces: Bluetooth; USB
- Mounting: Casing equipped with a magnet, a wall-mount system and a slot for suspending the product. Compatible with the Multi x accessory.
- Dimensions: 17 x 72 x 32mm
- Weight: 260g
- Ingress protection: IP54
- Product operating range: -10˚C to 60˚C; 10 to 90% RH
- Compliance: IEC61010-1 / IEC 61326-1
General Specifications - Data Logger Transfer Windows PC software functions: Display as a graph or a table of values / Data export in graph or Excel table form. Real-time mode / Automatic report generation in Word format / Data format compatible with the Dataview software offered as an accessory.
- Warranty: 2 years
Chauvin Arnoux CA1246 Thermohygrometer Humidity - Type: Capacitive sensor
- Measurement range: 3 to 98%
- Resolution: 0.1% RH
- Accuracy: 10 to 90 %RH: ± (2 %RH ± 1 ct), outside that range: ± (4 %RH ± 1 ct)
- Response time: 60s
Temperature - Type of sensor: Semiconductor
- Measurement range: -10˚C to 60˚C
- Resolution: 0.1˚C
- Accuracy: 10 to 40°C: ± (0.5°C ± 1 ct); outside that range: ± (0.032 x (T-25) ± 1 ct) / T= temperature in °C
- Response time: 30s
Dew Point - Measurement range: -20˚C to 60˚C
- Resolution: 0.1˚C
Functions - Recording: Manual Start / Stop on the product short press for MEM spot recording / Long press for REC recording at the rate of the current mode Programmed recording: start date, recording interval (1 minute to 2 hours) and end date de ned using the PC software
- Alarms: Alarm thresholds settable in the software / Recording can be triggered on an alarm threshold
- Data storage: >1 million points
- Min-Max-Hold: Yes
- Units: ˚C or ˚F / RH
- Backlighting: Yes
- Auto power off: Yes (configurable)
Power supply - Type: 3 x 1.5V AA / LR6 alkaline batteries; connection to the mains possible with the mains / micro-USB adapter offered as an accessory
- Battery life: 1,000 hrs (portable mode) / 3 years of recording (15-minute measurement interval)
Physical Specification - Interfaces: 2 possible communication modes: Bluetooth wireless link and USB
- Mounting: Casing equipped with a magnet, a wall-mount system and a slot for suspending the product Compatible with the Multi x accessory.
- Dimensions / Weight: 187 x 72 x 32 mm / 260 g with batteries
Ingress protection: IP54
- Product operating ranges: -10˚C to 60˚C / 10 to 90% RH
- Compliance: IEC61010-1 / IEC 61326-1
General - Data Logger Transfer Windows PC software functions: Display as a graph or a table of values / Data export in graph or Excel table form; Real-time mode / Automatic report generation in Word format / Data format compatible with the Dataview software offered as an accessory
- Warranty: 2 years
Chauvin Arnoux CA832 Sound Level Meter - Measurement range: 3 measurement ranges; 37 dB to 130 dB
- Accuracy: ±1.5 dB
- Resolution: 0.1 dB
- Integration time: Slow (550 ms); Fast (55 ms)
- Weighting curves: dB(A) and dB(C)
- Analogue output: 10 mV/dB and 1 Vrms on 600 Ω
Operating conditions - Temperature: 0 to 50 °C
- Humidity: < 80 % RH
Storing conditions - Temperature: -20 °C to +60 °C
- Humidity: < 80 % RH
- Dimensions: 205 x 60.5 x 38 mm
- Mass: 230 g
Chauvin Arnoux VX0100 EMF Meter Measurement Sensitivity & Accuracy - 2 sensitivity ranges (compatible with standards): 1.0 to 200.0V/m, 100 to 2,000V/m
- Accuracy (in “laboratory” conditions): ±3% ±5 D at 50/60Hz
Measurement Frequency Range - Analysis of equipment connected to the mains: 5Hz to 3kHz (3kHz low-pass filter), 3kHz to 100kHz (2kHz high-pass filter), 5Hz to 100kHz (3kHz without filter)
- Power: 9V battery (included): Battery life 60 - 80 hours
- Safety: Reversed (M/F) antenna and earth terminals
- Protection: Protected reference contact
- IP65 protection
- Dimensions: 63.6 x 163 x 40 mm
- Weight: approx. 200g with battery
- Warranty: 2 years
|
