Extech SDL730 Differential Pressure Manometer/Datalogger (7000mbar)

Extech Instruments
SKU: EXTESDL730
  • High-range differential pressure measurement up to 101.5 psi (7000 mbar)
  • SD card datalogging with date/time stamps in an Excel-compatible format
  • Essential features for repeatable readings, including Max/Min, data hold, and zero offset correction
More Info
Typically ships in 3-5 working days

Extech SDL730 Differential Pressure Manometer/Datalogger (7000mbar)

The Extech SDL730 Differential Pressure Manometer/Datalogger is designed for measuring and recording high-range pressure readings in HVAC, building services, and maintenance applications. It measures gauge and differential pressure up to 101.5 psi (7000 mbar) using dual differential inputs with internal sensors, making it suitable for higher pressure system checks and general diagnostics.

For documentation, the SDL730 supports both manual and continuous logging. Users can store up to 99 readings manually, or log continuously to an SD memory card with date/time stamps. Readings can then be exported in an Excel-compatible format for straightforward download and analysis.

Practical functions include Max/Min record and recall, data hold, and a zero function for offset correction. Multiple selectable units of measure provide flexibility across different job requirements, and auto power off can be disabled for longer logging sessions.

Extech part number: SDL730

Key Features

  • Measures gauge and differential pressure up to 101.5 psi (7000 mbar)
  • Dual differential inputs with internal sensors
  • Manual storage of up to 99 readings
  • Continuous data logging to SD card with date/time stamp
  • Excel-compatible file format for easy transfer to a PC
  • Max/Min record and recall
  • Data hold function
  • Zero function for offset correction
  • Multiple selectable units of measure
  • Auto power off with disable option
Specification
  • Pressure (atmosphere) - 6.905atm
  • Pressure (atmosphere) Basic Accuracy - ±2% full scale
  • Pressure (atmosphere) Max Resolution - 0.005atm
  • Pressure (hPa) - 7000hPa
  • Pressure (hPa) Basic Accuracy - ±2% full scale
  • Pressure (hPa) Max Resolution - 5hPa
  • Pressure (inH2O) - 2810inH₂O
  • Pressure (inH2O) Basic Accuracy - ±2% full scale
  • Pressure (inH2O) Max Resolution - 2inH₂O
  • Pressure (inHg) - 206.7inHg
  • Pressure (inHg) Basic Accuracy - ±2% full scale
  • Pressure (inHg) Max Resolution - 0.1inHg
  • Pressure (kgcm²) - 7.135kg/cm²
  • Pressure (kgcm²) Basic Accuracy - ±2% full scale
  • Pressure (kgcm²) Max Resolution - 0.005kg/cm²
  • Pressure (kPa) - 700kPa
  • Pressure (kPa) Basic Accuracy - ±1% full scale
  • Pressure (kPa) Max Resolution - 0.5kPa
  • Pressure (mbar) - 7000mbar
  • Pressure (mbar) Basic Accuracy - ±2% full scale
  • Pressure (mbar) Max Resolution - 5mbar
  • Pressure (mH₂O) - 71.35mH₂O
  • Pressure (mH₂O) Basic Accuracy - ±2% full scale
  • Pressure (mH₂O) Max Resolution - 0.05mH₂O
  • Pressure (mmHg) - 5250mmHg
  • Pressure (mmHg) Basic Accuracy - ±2% full scale
  • Pressure (mmHg) Max Resolution - 5mmHg
  • Pressure (psi) - 101.5psi
  • Pressure (psi) Basic Accuracy - ±2% full scale
  • Pressure (psi) Max Resolution - 0.05psi
