FLIR Breach PTQ136 Multifunctional Thermal Imaging Monocular

SKU: FLIRTAB176WN8Q14001
  • Built to match the tough conditions of law enforcement
  • Enhanced situational awareness through integrated features
  • Multiple mini-rail mounting points for hands-free operation
More Info
Typically ships in 7-10 working days

Dual-Use Item: Export authorisation may be required to move this item outside of the UK (Council Regulation (EC) No.428/2009)

FLIR Breach PTQ136 Multifunctional Thermal Imaging Monocular

The FLIR Breach PTQ136 Multifunctional Thermal Imaging Monocular is built to withstand the rigours of law enforcement, offering unmatched tactical awareness and capable of spotting suspects' heat even in pitch-black conditions. Scan forests, fields and urban environments for any object of interest without giving away your position thanks to handheld optics which generate images based on infrared radiation rather than visible light. This radiation is emitted by all animals, objects and humans which allows the Breach PTQ136 to function even through fog, haze and light vegetation. Substantially boost situational awareness while standing still or moving in a vehicle with this portable thermal imager and its 320 x 256 VOx Microbolometer detector.

Featuring the new FLIR Boson core, the advanced image processing of the Breach PTQ136 Multifunctional Monocular provides better detection and classification, day or night. The bright Quad-VGA (1280 x 960) FLCOS high-definition display creates excellent image clarity as the 60 Hz refresh rate ensures crisp, sharp thermal details. With a 9.1mm lens system, Field of View (FOV) of 24° × 19° and 1x to 4x continuous digital e-Zoom, easily document operations with on-board video recording and image capture. Alongside a digital compass/inclinometer, choose from seven palettes including White Hot, Rainbow HC and Outdoor Alert to suit individual situations and swiftly detect suspects or evidence

Weighing a mere 7.4 ounces and with a highly compact design, the FLIR Breach PTQ136 Thermal Imaging Monocular is small enough to comfortably fit in a pocket or can be mounted on a helmet with its mini-rail feature. With multiple mini-rail mounting points, hands-free operation is easier than ever as the Breach PTQ136 can be attached to a vast array of head mounts, helmet mounts or additional equipment. Complete with a 16mm eye relief for added comfort, and an internal memory capable of storing up to 1,000 images and 2.5 hours of video, the reliability of this device is guaranteed through FLIR's iconic 10-year Detector warranty.

Key Features

  • Specifically designed for the tough world of law enforcement
  • Usable even in conditions where regular night vision can fail
  • Provides the user with unmatched tactical awareness
  • Powerful new FLIR Boson thermal core
  • 320 x 256 VOx Microbolometer Detector type
  • Bright high-definition display for easy detection & clarification
  • Quad-VGA (1280 x 960) FLCOS display
  • Refresh Rate of 60 Hz
  • On-board recording and still image capture
  • Includes a lens System of 9.1 mm
  • Comes with a Field of View (H x V) of 24° × 19°
  • Features digital e-Zoom of 1× - 4× continuous
  • Seven palettes for fast detection of suspects or evidence
  • Palettes available: White Hot, Black Hot, Rainbow HC, Ironbow, Sepia, Arctic, Outdoor Alert
  • Enhance situational awareness with a digital compass/inclinometer
  • Compact design weighing only 7.4 ounces
  • Pocket-sized design
  • Multiple mini-rail mounting points
  • Easy hands-free operation
  • Comes with 16mm eye relief
  • Includes digital compass/inclinometer
  • Internal memory large enough for up to 1000 images and 2.5 hours of video
  • Protected by FLIR’s 10-year Detector warranty

FLIR part number: TAB176WN8Q14001

What's In The Box?

  • FLIR Breach PTQ136 Multifunctional Thermal Imaging Monocular
  • CR123A Battery
  • Lens Cloth
  • Hard Case
Specification

General

  • Detector Type: 320 x 256 VOx Microbolometer
  • Refresh Rate: 60 Hz
  • Start Up: <5 seconds
  • Image Processing: FLIR Proprietary Digital Detail Enhancement
  • Lens System: 9.1 mm; F/1.04
  • Optical Magnification: 1×
  • Field of View (H x V): 24° × 19°
  • Digital e-Zoom: 1× - 4× continuous
  • Diopter Adjustment Range: -5 to +5 dpt
  • Focusing Range: 0.25 m to infinity
  • Eye Relief: 16 mm
  • Display: Quad-VGA (1280 x 960) FLCOS
  • Video Output: Digital Video
  • Internal Memory: Up to 1,000 images and 2.5 hours of video on internal memory
  • Temperature Imaging Modes (Image Palettes): White Hot, Black Hot, Rainbow HC, Ironbow, Sepia, Arctic, Outdoor Alert

User Interface

  • Control Panel Buttons for Operational Settings:
    Unit On/Off
    Display Brightness Control
    Digital Zoom Control
    Image Capture and Video Record Control
    On-Screen Menu Navigation
    NUC
  • Diopter Adjustment Ring: Adjusts the Eyepiece Diopter

Interfacing

  • USB-C Connector: Power In; Video out; Video and image files transfer

Power

  • Battery Type: One CR123A 3V Lithium battery
  • Battery Life (Operating): Up to 90 minutes at 20°C
  • USB Power: 5 VDC

Environmental

  • Operating Temperature Range: -20°C to +50°C (-4°F to +122°F)
  • Storage Temperature Range: -40°C to +60°C (-40°F to +140°F)

Physical

  • Weight: 210 g (0.46 lbs)
  • Size: 139 × 70 × 49 mm (5.5 × 2.7 × 1.9 in)
  • Colour (housing): Black
  • Country of Origin: USA
