Hikmicro Pocket2 Compact Thermal Imaging Camera

Hikmicro Pocket2 Compact Thermal Imaging Camera

The Hikmicro Pocket 2 Compact Thermal Imaging Camera is a pocket sized thermal image camera with a IR 256 x 192 (49,152 pixel) Vox thermal sensor and a 8MP optical lens. The 3.5 inch LCD touch screen display a temperature range of -2-ºC to 400ºC. The 25Hz frame rate allows the user to deliver smooth thermals imaging, which when the device is connected via WiFi to a smartphone or device allows for images to be be viewed and shared using the Hikmicro App. Using the App users are able to view in real time, analyse recordings and generate reports. The Hikmicro Pocket 2 can also be used alongside the Hikmicro Analyser PC software too generator reports.

The inbuilt 16GB memory provides onboard recording and playback and can capture up to 60,000 images and 54 hours of videos. Voice notes with up to 200 characters can also be added to images and videos. The thermal imager has a battery life of up to 4.5 hours from a 2.5 hour full charge. Image contrast can be adjusted easily thanks to the Hikmicro Pocket 2's three level and span modes (manual, automatic and 1-tap) to highlight potential problems. The built in speaker and flash light give audible and visual alerts to the user should any high temperatures be detected. The viewer can also select from four image modes (Thermal, Fusion, PIP and Optical modes) and 7 colour palettes (White Hot, Black Hot, Rainbow, Ironbow, Red Hot, Fusion and Rain) to give the user several different image display options. The Hikmircro Pocket2 also allows users 1.0x to 4.0x continuous digital zoom providing more image details

The camera is IP54 rated protecting the camera from dust and water ingress and is drop tested to 2m providing users with a camera suitable for being used in industrial environments as well as home thermal inspections.

Key Features

• Thermal Resolution 256 x 192 (49,152 pixels) NETD: <40mK (@ 25°C, F# = 1.0)
• Temperature range from -20°C to 400°C (-4°F to 752°F)
• Accuracy: Max. (± 2°C/3.6°F, ± 2%)
• 25Hz image frequency
• 50º Field of view
• Thermal, fusion, PIP, and optical modes, 8 MP optical camera
• Manual, automatic, and 1-Tap level and span
• 7 colour palettes: White Hot, Black Hot, Rainbow, Ironbow, Red Hot, Fusion and Rain
• High temperature alarm
• Built-in 16 GB memory
• Built in WiFi
• 3.5inch LCD Touchscreen
• LED work light
• Analyse images and create reports using Hikmicro App
• IP54 rated and 2m drop tested
• 1.0x to 4.0x continuous digital zoom
• 8 MP Optical camera
• Up to 4 hours continuous running
