Keller LEO2 Ei Intrinsically Safe Digital Manometer (30bar)

SKU
KELL303010.0007
  • An intrinsically safe pressure gauge for hazardous ATEX environments
  • Measures pressure from -1bar to 30bar with accuracy of ±0.1% FS
  • Measurements taken via 7/16” UNF connector and piezoresistive transducer
More Info
inc VAT £264.00 ex VAT £220.00
In Stock - Available Next Day


Product Details

Keller LEO2 Ei Intrinsically Safe Digital Manometer (30bar)

The Keller LEO2 Ei Intrinsically Safe Digital Manometer has a pressure measurement range of -1bar to 30bar, an accuracy of ±0.1% FS and a resolution of 10mbar. The pressure meter has a piezoresistive pressure transducer and a 7/16” UNF male connector.

The Keller LEO2 Ei is certified as intrinsically safe and is therefore usable in hazardous environments where there is a risk of combustion. It is classified as Ex II 1 G and EEx ia IIC T6 or T5 and the certification file is LCIE 01 ATEX 6001 X.

The digital screen on the Keller LEO2 Ei shows pressure measurements in a number of different units and it is also possible to view minimum or maximum readings alongside the current pressure reading. A zero function enables relative measurement that negates the effect of variable barometric pressure.

The Keller LEO2 Ei comes supplied with an ‘O’ ring seal swivel and a G ¼” adaptor. The IP65 ingress protection certifies that the pressure gauge is suitable for challenging environments and it also benefits from a 1000-hour battery life.

Keller part number: 303010.0007

Key Features

  • Suitable for ATEX environments
  • Certified intrinsically safe
  • Ex II 1 G, EEx ia IIC T6 or T5
  • Pressure range: -1bar to 30bar
  • Accuracy: ±0.1% FS
  • Resolution: 10mbar
  • Min/max recording feature
  • 360˚ rotation with O-ring swivel
  • 7/16” UNF male connector
  • G ¼” adaptor supplied
  ECO2 LEO1 LEO2 LEO3 LEO5 LEO Record LEX1
-1 to 3bar
-1 to 30bar
0 to 100bar
0 to 300bar
0 to 400bar
0 to 700bar
0 to 1000bar
Accuracy ±0.5% FS ±0.1% FS ±0.1% FS ±0.1% FS ±0.05% FS ±0.1% ±0.05% FS
Resolution
(at smallest range)
10mbar 1mbar 1mbar 1mbar 1mbar 1mbar 0.1mbar
Temperature range 0˚C to 50˚C
Temperature accuracy ±1˚C
Intrinsically safe
version
Peak mode
Pressure connector 7/16" UNF G 1/4" 7/16" UNF G 1/4" G 1/4" G 1/4" G 1/4"
Analogue output
Internal memory
Data port RS485 Binder USB RS485 Fischer RS485 Fischer
Compatible with
Keller-Bus protocol
More Information
Specification
  • Classification: Ex II 1 G; EEx ia IIC T6 or T5
  • Certification file: LCIE 01 ATEX 6001 X
  • Range: -1bar to 30bar
  • Resolution: 10mbar
  • Overpressure: 60bar
  • Accuracy: <0.1% FS
  • Total error band: <0.2% FS
  • Storage temperature: -20˚C to 70˚C
  • Operating temperature: 0˚C to 50˚C
  • Compensated temperature range: 0˚C to 50˚C
  • Supply: 3V battery, type CR 2430
  • Battery life: 1000 hours’ continuous operation
  • Pressure connection: 7/16”-20 UNF (adaptor G ¼” included)
  • Protection rating: IP65
  • Dimensions: 59mm x 95mm x 32mm
  • Weight: 125g
