Pulsar Merger Duo NPX50 Thermal Imaging Binoculars

PULSAR
SKU: PULSNXP50
  • Features a 640x480 resolution sensor, 17µm pixel pitch, a <25mK NETD rating, plus 1920x1200 Full-HD CMOS digital sensor
  • Has a magnification that ranges from 3 to 24x for thermal imaging and from 2 to 16x for digital night vision
  • Offers flexible viewing options: thermal-only, digital-only, or a picture-in-picture (PiP) hybrid mode
More Info
Typically ships in 2-3 working days

Pulsar Merger Duo NPX50 Thermal Imaging Binoculars

The Pulsar Merger Duo NPX50 Thermal Imaging Binoculars combine advanced thermal imaging and digital night vision technology to give users a multispectral binocular that is able to detect, observe, and identify subjects in any lighting condition. Ideal for search and rescue teams, wildlife observers, and tactical operators, the Merger Duo NXP50 boasts a powerful dual-channel system that comes with a highly sensitive 640 x 480 resolution thermal imaging sensor, a 17µm pixel pitch, and a NETD of less than 25mK. Paired with a full-HD 1920 x 1200 CMOS digital night vision sensor, these technologies work independently or together, giving users flexible viewing options: thermal-only, digital-only, or a picture-in-picture (PiP) hybrid mode that overlays one image over the other for enhanced detail and situational awareness.

Featuring a thermal lens with a 50 mm f/1.0 aperture and a digital lens with a 50 mm f/1.4 aperture, the Merger Duo NXP50 ensures bright and crisp images even in minimal light and offers a magnification that ranges from 3 to 24x for thermal imaging and 2 to 16x for digital night vision with a wide field of view of 21.8 metres at 100 metres in thermal mode and 30.7 metres in digital mode. Users can detect human-sized heat signatures at distances up to 1800 metres away, making the Merger Duo CXP50 a powerful tool for long-range observation. With a built-in 1280 x 960 resolution AMOLED display, users get to enjoy vivid visuals, while an attachable 940 nm IR illuminator ensures the digital channel performs optimally in complete darkness without revealing the userís position.

Made for the outdoors, the Merger Duo NXP50 boasts a magnesium alloy housing and an IPX7 waterproof rating, giving users peace of mind knowing it will function reliably in rain and snow as well as in extreme temperatures that range from -25°C to +50°C. The Merger Duo NXP50 thermal imaging binoculars work on a dual battery system, combining a 4000 mAh internal battery with a replaceable 3200 mAh external APS3 Li-Ion battery to offer up to 7.5 hours of continuous use on a single charge. Additional features include Wi-Fi and USB-C to transfer images and videos seamlessly, 16 GB internal storage to store hours of video or thousands of images and Pulsar's Stream Vision 2 app for remote control, media sharing, and firmware updates.

Pulsar part number: PUL-77486

Key Features

  • Highly sensitive 640◊480, 17µm, <25mK NETD thermal sensor
  • Built-in photo and video recorder with sound (.mp4/ .jpg formats)
  • 1800m thermal detection range
  • Magnesium alloy housing
  • IPX7 submersion waterproof rated
  • Dual battery system
  • Operation in extreme temperatures -25°C to +50°C
  • Ergonomic and functional carrying case
  • Dual Wi-Fi waveband support 2.4/5 GHz
  • Stream vision 2. Wi-Fi integration with iOS and android devices
  • Proximity sensor for covert use
  • Extra low-light full-HD digital night vision
  • IR illuminator
  • Advanced pulsar image boost technology
  • Fast aperture 50mm f/1.0 thermal lens and 50mm f1.4 digital lens
  • Invisible IR illuminator for image detail increase in digital channel
  • 8 colour palettes in thermal mode
  • High-contrast HD AMOLED displays
  • Comfortable viewing experience
  • Convenient classic binocular design
  • Dual Li-Ion power system: APS 3 changeable battery (3.2 Ah) and built-in battery pack (4.0 Ah)
  • 7.5 hours operating time

What's In The Box?

  • The Pulsar Merger Duo NXP50 Thermal Imaging Binoculars
  • IR illuminator
  • Battery pack and charger
  • USB-C cable
  • Lens cloth
  • Neck strap
  • Carrying case
  • Quick start guide
  • Tripod adaptor
Specification
  • Thermal Sensor: 640◊480, 17µm, <25mK NETD uncooled, microbolometric
  • Digital Sensor: 1920◊1200 Full-HD CMOS
  • Frame Rate: 50Hz
  • Objective Lens: 50mm f1.0 (thermal) | 50mm f1.4 (digital)
  • Magnification: 3-24x (thermal) | 1.5-12x (digital)
  • FOV: 12.4 x 9.3 / 21.8 x 16.4 (thermal channel on minimal magnification) | 21.1 x 16.3 / 16.4 x 12.3 (digital channel on minimal magnification)
  • Eye Relief: 12mm
  • Display: 1280 x 960 HD AMOLED
  • IR Illuminator Emitter: LED
  • IR Wavelength: 940nm
  • IR Optical Power: 500mW
  • Beam Divergence (Degree): = FOV
  • IR Spot Position Adjustment: Yes
  • Detection Range: 1800m (thermal)
  • Video Recorder: Yes, with sound
  • Video Resolution: 1280 x 960
  • Video/Photo Format: .mp4/.jpg
  • Wireless Protocol: Wi-Fi
  • Wireless Standard: IEEE 802.11 b/g/n/ac (WPA)
  • Frequency: 2.4 / 5GHz
  • Degree of Protection: IPX7 (waterproof)
  • Operating Temperature Range: -25 to +50∞C
  • Output Voltage: 3.0 to 4.2V
  • Battery Type: Dual Li-Ion power system: APS 3 changeable battery (3.2Ah) and built-in battery pack (4.0Ah)
  • Battery Capacity: 3200 mAh (external) & 4000 mAh (internal)
  • Operating Time: 7.5 hours (at t=22∞)
  • External Power Supply: 5V, 9V (USB Type-C Power Delivery)
  • Body Material: Magnesium alloy
  • Dimensions: 207 x 140 x 73mm
  • Weight: 1200g (with batteries)
