Pulsar Merger LRF XT50 Thermal Imaging Binoculars

SKU: PULSXT50
  • Features 1280 x 1024 resolution sensor, 12µm pixel pitch and <40mK NETD rating
  • Offers a wide field of view of 17.5° with a magnification range of 2x to 16x and a long-distance detection rate of 2300 metres
  • Has a digital image stabilisation feature that allows users to observe fast-moving subjects with ease
More Info
Typically ships in 2-3 working days

Pulsar Merger LRF XT50 Thermal Imaging Binoculars

The Pulsar Merger LRF XT50 Thermal Imaging Binoculars provide an exceptional viewing experience with features like a 1280 x 1024 resolution sensor, a 12µm pixel pitch and a NETD of less than 40mK. These deliver detailed and high-contrast thermal images, even in challenging weather conditions like fog, rain, or cold environments. A powerful 50mm f/1.0 aperture objective lens and a lossless pixel transfer complement the Merger XT50 sensors, delivering clear images while offering long-range detection capabilities that identify even the smallest heat source at distances of up to 2300 metres away.

What sets the Merger XT50 apart from other models is its digital image stabilisation, a first for Pulsar's thermal binocular range, which reduces motion blur and vibration, making it easy for users to look at distant or fast-moving subjects with clarity, along with the wide field of view of 17.5° and a magnification range of 2x to 16x, which gives users an expanded observation area and ensures sharp image quality for both close- and long-range observation.

The Pulsar Merger LRF XT50 includes a built-in laser rangefinder capable of measuring distances up to 1500 metres with an accuracy of ±1 metre, which is especially valuable in tactical, rescue, and wildlife observation. Equipped with 1280 x 960 twin HD AMOLED displays to reduce eye fatigue, the Merger XT50 comes with the 8 customisable colour palettes, allowing users to optimise and adapt their viewing experience for specific environments with ease.

Housed in a robust magnesium alloy body, the Merger XT50 has an adjustable interpupillary of 63-74 mm for comfort during use and boasts an IPX7 waterproof rating, ensuring reliable operation in various wet conditions. The Merger XP50 also operates in temperatures ranging from -25°C to +50°C and features a dual battery system that includes an internal 4000mAh battery and a replaceable external 3200 mAh pack to deliver up to eight hours of continuous use (depending on the usage).

The Merger XT50 integrates seamlessly with Pulsar's Stream Vision 2 app via dual-band Wi-Fi that supports 2.4/5GHz, allowing for remote operation, media transfer, and firmware updates, while the 64 GB internal memory allows users to capture high-resolution photos and videos without needing external storage devices.

Pulsar part number: PUL-77486

Key Features

  • 1280 x 1024 resolution, 12µm pixel pitch and <40mK NETD thermal sensor
  • Powerful 50mm f1.0 objective lens
  • Long detection range of up to 2300 metres away
  • 2.0-16.0 x magnification range
  • Wide field of view of 17.5°
  • Built-in image stabilisation
  • Built-in laser rangefinder measuring extended distance of up to 1500 metres with ±1m accuracy
  • 1280◊960 twin HD AMOLED displays that reveal every detail while reducing eye fatigue
  • Ergonomically designed magnesium alloy bodyshell
  • IPX7 waterproof rating
  • Operational even in extreme temperatures ranging from -25 to +50°C
  • Advanced dual battery system with built in, rechargeable Li-Ion battery and a replaceable, rechargeable APS3 battery
  • Up to 8 hours of operating time
  • 8 colour palettes: White Hot, Black Hot, Red Hot, Rainbow, Ultramarine Sepia, Red Monochrome, and Violet
  • Built-in video recording (with audio) plus 64GB internal memory
  • Connects to Stream Vision 2 app
  • Remote viewing and control from Android or iOS devices
  • Built-in dual-band 2.4/5Ghz Wi-Fi module

What's In The Box?

  • Pulsar Merger LRF XT50 thermal imaging binoculars
  • 2 x APS3 battery packs
  • APS battery charger
  • Power adaptor
  • USB Type-C cable with USB Type-A adaptor
  • Carrying case
  • Neck strap
  • Lens cloth
  • Quick start guide
  • Tripod adaptor
Specification
  • Thermal Sensor: 1280x1024, 12µm
  • NETD: <40mK
  • sNETD*: <20mK
  • Objective Lens: 50mm f1.0
  • Magnification: 2.0-16.0 x
  • Detection Range: 2300m
  • FOV: 17.5°
  • Eye Relief: 15mm
  • Frame Rate: 50Hz
  • Image Stabilisation: Built-in
  • Display: 1280x960 HD AMOLED
  • Audio/Video: Built-in video recording (with audio) and still image capture
  • Video and image Formats: .mp4 & .jpg
  • Video Resolution: 1280x960
  • Photo Resolution: 1280x960
  • Rangefinder: Built-in precision laser rangefinder
  • Rangefinder Wavelength: 905nm
  • Measuring Distance: 1500m
  • Measuring Accuracy: ±1m
  • Built-in Memory: 64GB
  • Wi-Fi: 2.4/5.0GHz
  • App Connectivity: Stream Vision 2
  • Body Material: Magnesium Alloy
  • Level of Protection: IPX7 Waterproof
  • Battery Life: Up to 8 hours (depending on temperature)
  • Power Source: Dual rechargeable Li-Ion internal battery & rechargeable APS3 external battery
  • Dimensions: 197 x 140 x 72mm
  • Weight: 950g (with batteries)
