Pulsar TELOS XQ35 Thermal Imaging Monocular (Select Model)

SKU: PULSXQ35-CONF
  • Has a 384×288, 17µm, <25mK NETD sensor which delivers exceptional and reliable thermal imaging performance
  • The Pulsar TELOS XQ35 can be optimised for various environments and tasks, with the Telos range designed for customisability
  • An IPX7 rating ensures the monocular is well protected, with the user able to enhance the XQ35 by opting to order it with a Laser Range Finder
More Info

Pulsar TELOS XQ35 Thermal Imaging Monocular (Select Model)

The Pulsar TELOS XQ35 Thermal Imaging Monocular is a highly sensitive, fully upgradeable instrument with an impressive 1300m detection range. The Telos range is fully upgradeable to suit the needs of the user, with the components able to replaced for more relevant and powerful ones. Whether it be day or night, or rain or shine, nothing will remain unseen with this impressive Lynred thermal sensor, which is European-made and has a sensitivity of 384×288, 17 µm, <25 mK NETD. This, paired with the powerful 35mm f/1.0 fast-aperture germanium objective lens, delivers exceptional thermal imaging performance, with a large detection range in virtually any weather condition, including heavy rain, dense fog, snow, and high humidity. The user can select between a standard Pulsar TELOS XQ35, or one that is equipped with a Laser Range Finder, which enhances its functionality by providing precise distance measurement and enhancing its long range capabilities.

Pulsar's Image Boost technology ensures that the TELOS XQ35 is able to provide the highest possible level of detail, clarity, and contrast. Image processing algorithms work to render complex scenes, which ensure high levels of thermal informativity, through the enhancement of detail and object sharpening at a range of distances. The XQ35's thermal sensor sensitivity can be manually adjusted to improve the quality of detection, with a smoothing filter that has a wide range of brightness and contrast settings ensuring that long periods of observation are possible.

The Pulsar TELOS XQ35 has an easily-accessible button layout along the top panel of the monocular, which ensures use is both comfortable and convenient. An attachable hand strap allows for both left and right handed users to operate the XQ35, as it can be rotated from one side to the other with considerable ease. Focus and magnification rings are also located on the objective lens, which allows for the smooth magnification of imaging, and quick focusing.

The XQ35 offers a highly customisable user experience with adaptable controls and an interface that allows users to prioritise menu items and button configurations for quick access to essential functions. With eight color palettes, it enhances observation by optimising visibility for different tasks and conditions, including object detection, recognition, and long-duration night use. Built for durability, its polymeric rubber-coated casing provides a secure grip, resists wear, and is easy to clean, while its IPX7 rating ensures water resistance up to 1m for 30 minutes. Designed for extreme temperatures (-25°C to +40°C), it maintains reliable performance in harsh environments. Additionally, its built-in still image and video recorder, with 32GB of storage, enables users to effortlessly capture and save countless photos and hours of video.

The Pulsar Telos range is united by the concept of upgradability, with the possibility of technical component upgrades to suit the specific needs of the user. This is a more cost effective way to ensure you stay ahead of the curve when it comes to technological advancements. The XQ35 is available to be purchased as a standalone monocular, or with a built-in Laser Range Finder (LRF), which is able to measure distances in both single measurements and continuous scanning modes. It has a range of up to 1 kilometre, and an accuracy of ± 1 metre.

Stream Vision 2

Stream Vision 2 is available for use with this product, with this free application able to further enhance selected PULSAR products.

Stream Vision 2 is a mobile application designed to enhance the functionality of Pulsar's thermal imaging, digital night vision, and multispectral electro-optic devices by connecting them to smartphones via Wi-Fi. Available for both Android and iOS platforms, the app offers features such as real-time image streaming, remote device control, and firmware updates. Users can access free cloud storage to synchronize and store photos and videos, making them accessible across various devices. Additionally, the app provides a newsfeed to keep users informed about the latest developments in night vision and thermal imaging technologies.

Key functionalities of Stream Vision 2 include remote real-time image viewing, allowing users to see live footage from their devices on their smartphone screens, and a photo and video browser to manage and share media files. The app also enables remote control of device settings, with real-time updates visible in the viewfinder for on-the-go adjustments. Firmware updates are streamlined through the app, ensuring devices are equipped with the latest features and enhancements. The integrated newsfeed keeps users updated on advancements and news in the night vision market, including updates from Pulsar and Yukon.

Key Features

  • Functional and ergonomic design for ease of use
  • Has an 8 colour display palette
  • Equipped with three calibration modes: Manual, Semi-Automatic, and Automatic
  • Has a detection range of 1300m
  • Comes with three levels of sensitivity enhancement: Normal, High, and Ultra
  • Has a plethora of intuitive features, such as display off function, display dimming function, auto shutdown, and defective pixel repair
  • Device firmware can be regularly updated using the free Stream Vision 2 App
  • IPX7 rating ensures that the product is fully waterproof
  • Built in video and sound recorder
  • Can be integrated with both iOS and Android devices
  • Wi-Fi remote control and viewing using a smartphone
  • Photos and videos can be stored in Cloud when using the Stream Vision 2 App
  • This product can be purchased with an equipped Laser Range Finder
  • The Laser Range Finder provides distance measurements up to 1km

What's In The Box?

  • Either Pulsar TELOS XQ35 or Pulsar TELOS LRF XQ35
  • LPS7i Battery Pack with Protective Cover
  • Spare Battery Compartment Cover
  • Power Adaptor
  • USB Type-C Cable with USB Type-A Adaptor
  • Case
  • Hand Strap
  • Quick Start Guide
  • Lens Cloth
  • Warranty Card
Specification

Pulsar TELOS XQ35

  • Sensor Type - Uncooled
  • Sensor - 384×288, 17µm, <25mK NETD
  • Frame Rate - 50Hz
  • Objective Lens - 35mm f1.0
  • Magnification - 3.0 – 12.0x (x4 Digital Zoom)
  • Field of View - 10.7° x 8.0°
  • Eye Relief - 14mm
  • Display - 1024×768 AMOLED HD
  • Detection Range - 1300m
  • Video Recording - Yes, with Audio
  • Still Image Capture - Yes
  • Video / Photo Resolution (Pixels) - 1024×768
  • Video / Photo Format - .mp4 / .jpg
  • Built-In Memory - 64GB
  • Wi-Fi - Built-In
  • Wireless Standard - IEEE 802.11 b/g/n/ac (WPA)
  • Wi-Fi Frequency - 2.4 GHz / 5 GHz
  • Degree of Environmental Protection, IP Code (IEC60529) - IPX7 (Waterproof)
  • Operating Temperature Range - -25°С – +40°С
  • Compatible Mounts - 1/4″
  • Supported Applications - Stream Vision 2
  • Power Output Voltage - 3.0-4.2 V
  • Battery Type - LPS 7i Li-Ion Battery Pack
  • Capacity - 6400 mAh
  • Operating Time on Battery Pack (at t=22°C) - 8.5 Hours
  • External Power Supply - 5V, 9V (USB Type-C Power Delivery)
  • Body Material - Rubber Armoured Reinforced Plastic
  • Dimensions - 224 х 66 х 59 mm
  • Weight - 430 g (w/o LPS7i Battery), 570 g (w/ LPS7i Battery)

Pulsar TELOS LRF XQ35

  • Sensor Type - Uncooled
  • Sensor - 384×288, 17µm, <25mK NETD
  • Frame Rate - 50Hz
  • Objective Lens - 35mm f1.0
  • Magnification - 3.0 – 12.0x (x4 Digital Zoom)
  • Field of View - 10.7° x 8.0°
  • Eye Relief - 14mm
  • Display - 1024×768 AMOLED HD
  • Detection Range - 1300m
  • Safety class for laser equipment according to IEC 60825-1:2014 - 1
  • Wavelength - 905 nm
  • Max. Measuring Range - 1000
  • Measurement Accuracy - ± 1 m
  • Video Recording - Yes, with Audio
  • Still Image Capture - Yes
  • Video / Photo Resolution (Pixels) - 1024×768
  • Video / Photo Format - .mp4 / .jpg
  • Built-In Memory - 64GB
  • Wi-Fi - Built-In
  • Wireless Standard - IEEE 802.11 b/g/n/ac (WPA)
  • Wi-Fi Frequency - 2.4 GHz / 5 GHz
  • Degree of Environmental Protection, IP Code (IEC60529) - IPX7 (Waterproof)
  • Operating Temperature Range - -25°С – +40°С
  • Compatible Mounts - 1/4"
  • Supported Applications - Stream Vision 2
  • Power Output Voltage - 3.0-4.2V
  • Battery Type - LPS 7i Li-Ion Battery Pack
  • Capacity - 6400mAh
  • Operating Time on Battery Pack (at t=22°C) - 8.5 Hours
  • External Power Supply - 5V, 9V (USB Type-C Power Delivery)
  • Body Material - Rubber Armoured Reinforced Plastic
  • Dimensions - 224 х 66 х 87 mm
  • Weight - 480 g (w/o LPS7i Battery), 630 g (w/ LPS7i Battery)
