Radiodetection S6 Microsonde Kit, incl. battery and case (10/SONDE-MICRO33)

Radiodetection
SKU: RADI10SONDEMICRO33
  • Small transmitter which allows operators to find blockages, even in very small buried pipes and ducting
  • With a diameter of 6.4mm, it is particularly useful for tracing blockages in fiber-optic microducting
  • Supplied as a kit that includes the sonde, a flexible adaptor, 2 batteries, and a case
More Info
Typically ships in 2-4 working days

Radiodetection S6 Microsonde Kit, incl. battery and case (10/SONDE-MICRO33)

The S6 MicroSonde is a very small transmitter, which has been designed to allow operators to trace and detect blockages, even in very small buried pipes and ducting. It has a diameter of 6.4mm (0.25"), is battery-powered, and transmits on a frequency of 33kHz. The S6 MicroSonde can be attached to a cable or push rod, and inserted into the duct/pipe. The route of the duct can be traced using a Radiodetection locator, and the precise location and depth of a blockage can be detected.

The Lithium Ion battery provides approximately 10 hours' usage, although the battery life may be shorter in cold conditions. When the battery is inserted and the mounting connector is fitted, the sonde automatically switches on and starts transmitting a continuous locate signal. An LED at the tip of the S6 flashes slowly when power is on. If the battery is low, the LED will switch off, although the sonde may continue operating until the battery is totally depleted. Once 'jetted' or 'pushed-in', the sonde can be used to trace the route of the duct, or to locate the precise position of a blockage within a duct.

The S6 MicroSonde kit contains the sonde, a flexible adaptor, 2 batteries, a case, and mounting connector.

Key Features

  • Very small in size, so useful for small diameter ducts
  • 10 hour battery usage
  • Used to trace the route of the duct, or to locate a blockage
  • Operates on a 33kHz (32768Hz) frequency

What's In The Box?

  • The transmitter unit
  • Mounting connector
  • 2 batteries
  • A case
  • Flexible adaptor
  • User guide
Specification
  • Signal Frequency = 33kHz (32768Hz)
  • Battery = 3V CR425 Lithium Ion battery, providing approx. 10 hours' use
  • Indicators = Flashing power-on LED
  • Maximum Depth = Approximately 2 meters, condition-dependent
  • Intended Use = Minimum 8mm (0.3") diameter, non-conductive tubes and pipes
  • Diameter = 6.4mm (0.25")
  • Length = 83mm (3.2")
  1. The Radiodetection Logo, in Place of the Pack of 10 x Batteries for the S6 Microsonde
