Specification
Features
- Infrared resolution: 384 x 288 (110,592 pixels)
- IFOV: 1.91 mRad
- Field of view: 42° x 30°
- Minimum focus distance: 0.15 m when using manual focus. 0.5 m when using focus marker
- Focus system: Manual focus and fixed focus detent at 1 meter focus position
- Wireless connectivity: Yes, to PC, iPhone® and iPad® (iOS 4s and later), Android™ 4.3 and up, and WiFi and LAN (where available)
- Fluke Connect app compatible: Yes*, connect your camera to your smartphone, and images taken automatically upload to the Fluke Connect app for saving and sharing
- Fluke Connect Assets optional software: Yes*, assign images to assets and create work orders. Easily compare measurement types - whether mechanical, electrical or infrared images - in one location
- Asset Tagging: Scan a QR code to automatically organise and file thermal images with Fluke Connect™
- IR-Fusion technology: AutoBlend continuous 0 % to 100 %. Adds the context of the visible details to your infrared image
- Picture-InPicture (PIP): Yes
- Display: 3.5" (8.9 cm landscape) touchscreen 640 x 480 LCD
- Ergonomic design: Designed for one-handed use
- Thermal sensitivity: 40mk
- Level and span: Smooth auto and manual scaling
- Fast auto-rescale in manual mode: Yes
- Minimum span (in manual mode): 3°C (4.5 °F)
- Minimum span (In auto mode): 5°C (9.0 °F)
- Built-in digital camera (visible light): 5mp
- Frame rate: 9 Hz
- Dew point calculation: Yes, on camera
Data Storage and Image Capture
- Internal memory: 500 images
- External memory: ≥4 GB SD card (>1000 images)
- Image capture, review, save mechanism: One-handed image capture, review, and save capability
- Image file formats: Non-radiometric BMP or JPEG or fully-radiometric is2
- Memory review: Yes
- Software: Fluke Connect software—full analysis and reporting software with access to the Fluke Connect
- Analyse and store radiometric data on a PC: Yes
- Export file formats with Fluke Connect software: is3, is2, BMP, GIF, JPEG, PNG, TIFF
- Voice annotation: Yes, 60 second maximum audio recording via Bluetooth Audio Headset Profile (HSP) connection to external device.
- IR-PhotoNotes: Yes. Up to 3 extra user-selectable visible light image capture to be included in IS2 file.
- Text annotations: After IS2 capture, user can type in a note using on-screen keyboard.
- Video recording and formats: Standard and radiometric video. Up to 5 minutes recording length. avi and is3
- Remote control operations: Yes
- Auto capture (temperature and interval): Yes. User-selectable time interval for capturing IS2 or Jpeg files.
Battery
- Batteries (field-replaceable, rechargeable): Lithium-ion rechargeable battery
- Battery life: ≥3.5 hours continuous without WiFi (Actual life depends on settings and usage)
- Battery charging time: ≤2.5 hours to full charge
- Battery charging system: Ti SBC3B Two-Bay Battery Charger or in-Imager charging
- AC operation: AC operation with included power supply, universal adapters included Output: 15 VDC, 2 A
- Power saving: User-selectable sleep and power off
Temperature measurement
- Temperature range (not calibrated below -10 °C): -20 °C to 550 °C (not calibrated below -10 °C)
- Accuracy: ±2 °C or 2 % (whichever is greater) at 25 °C ambient temperature
- On-screen emissivity correction: Yes, “top ten” material list plus numerical adjustment between 0.01 and 1.00
Colour Palettes
General Specifications
- Colour alarms: Yes
- Infrared spectral band: ~8-14μm
- Operating temperature: -10 °C to 50 °C (14 °F to 122 °F)
- Storage temperature: -20 °C to 50 °C (-4 °F to 122 °F) without batteries
- Relative humidity: 10 % to 95 % non-condensing
- Spot temperature: Centre spot (unmovable)
- User-definable spot markers: Yes, 5 user-adjustable spot markers for a single pixel each. Position is adjustable. Temperature value for marker shown on screen. User can choose to switch display on/off for each marker.
- User defined measurement boxes: Yes, 5 user-adjustable rectangles. Size and position are adjustable. Rectangle statistics shown on screen: Min, Max, Average temperature. User can choose to switch display on/off for each marker.
- Hard case: Rugged hard carrying case with soft transport bag, including adjustable strap
- Safety standards: IEC 61010-1: Pollution Degree 2
- Electromagnetic compatibility: IEC 61326-1: Portable Electromagnetic Environment; IEC 61326-2-2 CISPR 11: Group 1, Class A
- Australian RCM: RCM IEC 61326-1
- US FCC: 47 CFR 15 Subpart C Sections 15.207, 15.209, 15.249
- Vibration: 10 Hz to 150 Hz, 0.15 mm, IEC 60068-2-6
- Shock: 30 g, 11 ms, IEC 60068-2-27
- Drop: Engineered to withstand 2M drop
- Sized (H x W x L): 26.7 cm x 10.1 cm x 14.5 cm (10.5 in x 4.0 in x 5.7 in)
- Weight (battery included): ≤2.27 kg (5 lb)
- Enclosure rating: IP54
- Warranty: Two-years (standard)
- Recommended calibration cycle: Two-years (assumes normal operation and normal ageing)
- Supported languages: Czech, Dutch, English, Finnish, French, German, Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Simplified Chinese, Spanish, Swedish, Traditional Chinese, and Turkish
- RoHS compliant: Yes
* Fluke Connect analysis and reporting software is available in all countries but Fluke Connect is not. Please check availability with your authorised Fluke distributor. |
