Hikmicro M31 Thermal Imaging Camera

Hikmicro M31 Thermal Imaging Camera

The Hikmicro M31 Thermal Imaging Camera features a 384 x 288 (110,592 pixels) that allows users to capture temperature measurements from -20ºC to 650ºc. Centre spot, high-spot and low spot temperatures are displayed on the 3.5 inch 640 x 480 touchscreen display. The M31 camera is ideal for use in building, HVAC and auto industries where users can quickly find temperature targets in the working environments quickly and accurately. Featuring a long distance laser light showing the centre point of a chosen target and an LED light that can work as a torch in dark working environments. Hikmicro M31 camera boasts Hikmicros SuperIR technology, which boosts the thermal image to 768 x 576 (442,368 pixels)

The M31 provides users with an 8MP digital camera and a 1.0x to 8.0 continuous digital zoom and offers users with a choice of eight colour palettes (White Hot, Black Hot, Rainbow, Ironbow, Red Hot, Fusion, Rain, Blue Red) and five image modes are also available (Thermal/Visual/Fusion/PIP/Blending). The M31 also includes leading thermal image processing technology including: Adaptive AGC, DDE and 3D DNR to provide more detailed thermal images.

The M31 provides users with a NETD <30mK with 50Hz image frequency and the manual focus allowing for objects to be viewed as close as 0.1m (0.33ft). The one-span allows for areas of an image to highlighted quickly with a single tap of the display, with centre spot, hot spot and cold spot all clearly displayed for the user.

Included with the M31, is a removable 64GB Micro SD card that allows for up to 100,000 images or approximately 300 hours of MP4 video and radiometric video. Voice notes up to 60 seconds or text annotations can be added to images or videos to further enhance the analysis of objects. Powered by a rechargeable Li-ion battery, the M31 has a battery life of 4 hours and thanks to the included second battery, users are able to conduct thermal imagery for a full day in the field without having to recharge. IP54 rated, the M31 is protected from dust and water and has been drop tested to 2m.

Hikmicro Viewer App

The Hikmicro M31 is compatible with Hikmicros Viewer App, which via Wi-Fi, allows for the transfer of images and videos from the camera to a mobile device. Using the app, operators can analyse, share images and generate reports in real time even on-site.

Hikmicro Analyser

Hikmicro Analyser is a free licensed PC software that has been designed to help users to manage and analyse their thermal images and videos and quickly generate professional reports.

Key Features

• Thermal resolution of 384 x 288 (110,592 pixels
• Boasts Hikmicros SuperIR technology, enhance the thermal image to 768 x 576 (442,368 pixels)
• Capture temperature measurements from -20ºC to 650ºc
• 3.5 inch 640 x 480 touchscreen display
• Centre spot, high-spot and low spot temperatures
• long distance laser light showing the centre point of a chosen target
• LED light that can work as a torch in dark working environments
• Eight colour palettes (White Hot, Black Hot, Rainbow, Ironbow, Red Hot, Fusion, Rain, Blue Red)
• Five image modes (Thermal/Visual/Fusion/PIP/Blending)
• 8MP digital camera With a 1.0x to 8.0 continuous digital zoom
• One-span allows for areas of an image to highlighted quickly with a single tap of the display
• Manual focus allowing for objects to be viewed as close as 0.1m (0.33ft)
• NETD <30mK with 50Hz image frequency
• Removable 64GB Micro SD card for 100,000 images or approximately 300 hours of MP4 video and radiometric video
• Voice notes up to 60 seconds or text annotations
• Rechargeable Li-ion battery (x 2)
• 4 hour battery life
• IP54 rated
• Drop tested to 2m
