Keller LEO Record Digital Manometer (3bar)
The Keller LEO Record Digital Manometer is an industrial pressure gauge that has a measurement range of -1bar to 3bar with accuracy of ±0.1% FS and a resolution of 1mbar. With a G ¼” male pressure connector, it is therefore suitable for high-precision pressure measurement in industrial applications.
Readings are displayed on the Keller LEO Record’s digital screen in a number of different pressure units (bar, mbar/hPa, kPa, MPa, PSI, kp/cm2, mH2O). It is operated using just two push buttons and it has a maximum display measurement rate of once-per-second. The zero function allows relative measurements by setting any value as zero.
The Keller LEO Record can be used to monitor pressure across extensive time periods as it has a large, non-volatile, internal memory with space for up to 57,000 measuring values, recording both temperature and pressure. By combining event-controlled recording and interval recording, the gauge can prevent data being recorded unnecessarily and installation data can also be stored on the instrument.
Saved data can be accessed via the Keller LEO Record’s RS485 Fischer connection. A Keller K114A cable adaptor is needed to convert this to a USB in order to communicate with a PC. Keller Logger 5 software is included as standard with the pressure gauge and this allows the user to configure the pressure meter, manage recorded data and make detailed reports.
The Keller LEO Record has an ingress protection rating of IP65 so the user can rely on it in challenging conditions. It has a battery life of approximately two years and has a compact, practical design.
Keller part number: 303025.0001
Key Features
- Range: -1bar to 3bar
- Accuracy: ±0.1% FS
- Resolution: 1mbar
- G 1/4” male connector
- Clear digital screen
- Adjustable measurement rate
- Large internal memory
- RS485 Fischer data connection
- Supplied with Keller Logger 5 software
- IP65 ingress protection rating
- Battery life: 2 years approx.
| ECO2 | LEO1 | LEO2 | LEO3 | LEO5 | LEO Record | LEX1 | |
|---|---|---|---|---|---|---|---|
| -1 to 3bar | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | |
| -1 to 31bar | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ |
| 0 to 100bar | ✔ | ||||||
| 0 to 300bar | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ |
| 0 to 400bar | ✔ | ||||||
| 0 to 700bar | ✔ | ✔ | ✔ | ✔ | ✔ | ||
| 0 to 1000bar | ✔ | ✔ | ✔ | ✔ | |||
| Accuracy | ±0.5% FS | ±0.1% FS | ±0.1% FS | ±0.1% FS | ±0.05% FS | ±0.1% | ±0.05% FS |
| Resolution (at smallest range) |
10mbar | 1mbar | 1mbar | 1mbar | 1mbar | 1mbar | 0.1mbar |
| Temperature range | 0˚C to 50˚C | ||||||
| Temperature accuracy | ±1˚C | ||||||
| Intrinsically safe version |
✔ | ✔ | ✔ | ✔ | ✔ | ||
| Peak mode | ✔ | ✔ | |||||
| Pressure connector | 7/16" UNF | G 1/4" | 7/16" UNF | G 1/4" | G 1/4" | G 1/4" | G 1/4" |
| Analogue output | ✔ | ✔ | |||||
| Internal memory | ✔ | ✔ | ✔ | ||||
| Data port | RS485 Binder | USB | RS485 Fischer | RS485 Fischer | |||
| Compatible with Keller-Bus protocol |
✔ | ✔ | ✔ |
|
| Label | Type | Size | Download | |
|---|---|---|---|---|
|
Keller LEO Record Datasheet | 1.2 MB | Download |
-
-
-
