Megger VCM100D Digital Voltage Checker (for OTSAF and PB models)

Megger
SKU: MEGG1001105
Trustpilot

Never Beaten On Price



We’re always working hard to give you the best possible price, but if you find it cheaper somewhere else, we’ll endeavour to match the price.



Call 0113 248 9966 or contact us online

Typically ships in 5-7 working days
Need Some Help From Our Experts? chevron-right chevron-down

We're always happy to offer help, information & advice to find the right instrument for you, so please get in touch.



To speak to our sales team, call us on 0113 248 9966, use our Live Chat service or contact us online.

Members earn 1185 reward points chevron-right chevron-down

Use reward points to get money off future purchases.



Please note: Customers must be signed into their account to be elegible. Find out more about reward points here.

FREE Delivery & 60 Day Returns chevron-right chevron-down

We offer FREE standard delivery on all orders over £249, with a range of next-day options also available on many items.



Find out more on our delivery information page.

Key Features
  • Compatible with Megger AF and PB oil testers with voltages up to 100kV
  • Simulates a dielectric test of insulating oil with ramp voltage with 10kV steps
  • Checks voltage outputs up to 100kV in line with national standards

Related Categories

Oil and Transformer Testing Accessories
Description

Megger VCM100D Digital Voltage Checker (for OTSAF and PB models)

The Megger VCM100D Digital Voltage Checker allows the user to test the voltage output of a Megger oil test set. It will check the accuracy of the tester’s voltage output across the entire range with a 10kV stepped ramp from 0kV to maximum output and it shows the output on the clear display.

Oil testers that are compatible with the Megger VCM100D have a pre-configured test sequence for calibration purposes. The checker is inserted into the tester’s oil testing chamber instead of a normal test vessel which then allows simulation of a dielectric strength test.

The Megger VCM100D is compatible with Megger oil test sets with a maximum test voltage of 100kV. These include the OTS60AF, OTS80AF, OTS100AF, OTS60PB, and OTS80PB. The checker is provided with a carry case and calibration certificate as standard.

Megger part number: 1001-105

Key Features

  • Check oil tester output voltages up to 100kV
  • Suitable for Megger AF and PB testers up to 100kV
  • Simulates dielectric test of oil test vessel
  • Tests throughout range in 10kV, 10s steps
  • Calibrates to national standards
  • Output shown on clear digital screen

What's In The Box?

  • Megger VCM100D Digital Voltage Checker
  • Carry Case
  • Instruction Card
  • Certificate of Calibration
Specification
Show Trustpilot Reviews
Specification
No
  • Meter type: Proprietary 100kV Megger OTS voltmeter
  • Accuracy (@ 23˚C): ±(2% + 2 digits), ≤50kV RMS; ±(2.5% + 5 digits), >50kV RMS to 75kV RMS; ±(3% + 2 digits), >75kV RMS to 100kV RMS
  • Operating temperature range: 0˚C to 40˚C
  • Storage temperature range: -30˚C to 70˚C
  • Operating humidity range: 50% RH at 20˚C
  • Storage temperature: 93% RH at 40˚C
  • Safety: Approved for Megger oil test sets only
  • Dimensions: 250mm x 150mm x 115mm
  • Weight: 1.8kg
