Metrel MI3136 EurotestCombo XC EVSE Test Kit with A1532XA

Metrel
SKU: METRELMI3136EVKIT
  • Multifunction installation tester and EV charger tester in one package
  • Simulates EV charging states for realistic EVSE verification without a vehicle
  • Includes automated testing, wireless connectivity, and professional reporting tools
More Info
£1,238.00 (ex VAT)
£1,485.60 (inc VAT)
In Stock - Available Next Day

Metrel MI3136 EurotestCombo XC EVSE Test Kit

The Metrel MI3136 EurotestCombo XC EVSE Test Kit combines the advanced capabilities of the MI3136 EurotestCombo XC Multifunction Tester with the specialised A1532XA EV Charging Station Adaptor, providing electricians, EV charger installers, inspectors, and maintenance professionals with a comprehensive solution for verifying the electrical safety of EV charging installations quickly, safely, and in full compliance with current electrical standards.

The kit makes it easy to commission, inspect, and troubleshoot AC electric vehicle charging points while allowing users to perform both standard low‑voltage electrical installation testing and dedicated EV charger verification using one integrated system. This eliminates the need for multiple instruments and simplifies the overall testing workflow.

Multifunction Testing Capabilities

The MI3136 features a responsive 4.3‑inch high‑resolution colour touchscreen, automated test procedures, built‑in help screens, and wireless connectivity (including Bluetooth and USB) for fast, reliable measurements across a wide range of installation testing applications. It supports comprehensive measurements such as insulation resistance, continuity, loop/line impedance, RCD testing (including Type A, AC, and B where applicable), earth resistance, and voltage checks.

It also includes automated sequences such as Auto TT, Auto TN, Auto TT RCD, and Auto TN RCD, helping technicians complete inspections consistently while reducing manual operation time and the risk of human error.

Dedicated EV Charging Station Testing

What makes this kit particularly valuable for EV charging applications is the included A1532XA EVSE adaptor. Designed specifically for Mode 2 and Mode 3 EV charging point testing, the adaptor simulates various charging conditions and communication states (CP and PP signals) used during EV charging operation.

This allows the MI3136 to carry out essential electrical safety checks directly through the charging system, including loop impedance, RCD testing, voltage verification, continuity, polarity checks, and protective earth verification.

Automated EVSE Test Sequences & Functional Verification

When used together with Metrel’s AutoSequences, prebuilt into newer multifunction testers like the MI3136, the complete EVSE charging station can be tested both electrically and functionally on a state‑by‑state basis at the push of a button. The system also integrates with Metrel Electrical Safety Manager (MESM) software, enabling users to generate professional, traceable, station‑based test reports for compliance documentation and client handover.

By simulating different EV charging states, technicians can confirm that the charger responds correctly during operation and that protective devices, such as RCDs and fault detection systems, function as intended. This is critical for ensuring regulatory compliance, user safety, and correct installation before the system is handed over to the end user.

Applications and Use Cases

The kit is suitable for testing both domestic and commercial EV charging installations, including residential homes, office buildings, public charging infrastructure, car parks, and industrial or commercial facilities. It also supports periodic inspection and maintenance testing of existing EVSE systems, helping to identify faults early and reduce the risk of safety hazards, downtime, or costly failures. The kit delivers an all-in-one solution that improves efficiency and ensures compliance with standards such as IEC 60364 and related EV charging regulations.

Comparison table outlining key difference between various Metrel Multifunction Tester models

Feature MI3125BT MI3100S MI3100SE MI3102BT MI3152XC MI3155XD MI3136 EurotestCOMBO XC
Auto Test Line/Loop X X X X ✔ ✔ ✔
Autosequence Profile X X X X ✔ ✔ ✔
Pass/Fail Indicators ✔ ✔ ✔ ✔ ✔ ✔ ✔
Pass/Fail System Evaluation ✔ X ✔ ✔ ✔ ✔ ✔
Automatic Test Sequences X X ✔ ✔ ✔ ✔ ✔
Colour Display & Touch Screen X X X X ✔ ✔ ✔
Download Capability ✔ X ✔ ✔ ✔ ✔ ✔
Voltage AC – Frequency & TRMS ✔ ✔ ✔ ✔ ✔ ✔ ✔
Current AC – TRMS X X X ✔ X ✔ X
3-Phase System (Phase Sequence) ✔ ✔ ✔ ✔ ✔ ✔ ✔
Differential Leakage Current X X X ✔ Optional Optional X
Ring Test 200 mA (UK Installations) ✔ ✔ ✔ ✔ ✔ ✔ ✔
Max Test Current 200 mA 2-wire ✔ ✔ ✔ ✔ ✔ ✔ ✔
Max Test Current 200 mA 4-wire X X X X X ✔ X
Automatic Polarity Reversal ✔ X X X ✔ ✔ ✔
Insulation Resistance – Test Voltage 50–1000V ✔ ✔ ✔ ✔ ✔ ✔ ✔
Insulation Resistance – Test Voltage 2500V X X X X X ✔ X
RCD – 10mA–1000mA ✔ ✔ ✔ ✔ ✔ ✔ ✔
RCD – Type AC, A, F ✔ ✔ ✔ ✔ ✔ ✔ ✔
RCD – Type B ✔ ✔ ✔ ✔ ✔ ✔ ✔
RCD – Type B+ ✔ ✔ ✔ ✔ ✔ ✔ ✔
Current & Voltage Harmonics ✔ ✔ ✔ ✔ ✔ ✔ X

Key Features

MI3136 EurotestCombo XC Tester

  • 3-inch high-resolution colour TFT touchscreen
  • Multifunction testing for low-voltage installations (verification, inspection, maintenance, and fault finding)
  • Supports TT and TN earthing systems
  • Wide range of measurements including continuity, insulation resistance, loop and line impedance, RCD testing, and voltage monitoring
  • Automated test sequences: Auto TT, Auto TT RCD, Auto TN, and Auto TN RCD
  • Predefined AUTO SEQUENCES
  • Advanced RCD testing with separate RCD type and current shape measurements
  • Built-in fuse tables for automatic evaluation of loop and line impedance results
  • Real-time voltage monitoring (L-N, L-PE, N-PE)
  • Automatic polarity reversal during continuity testing
  • Measurement filtering for improved accuracy in electrically noisy environments
  • Integrated on-screen help for instant guidance on-site
  • Wi-Fi and Bluetooth® connectivity for fast data transfer
  • Compatible with Metrel ES Manager software for reporting and data management ( Available with MESM PRO and Metrel Cloud licences)
  • Metrel Cloud and mobile app support for data storage and synchronisation
  • High-capacity 5.2 Ah Li-ion battery
  • Universal USB Type-C charging and PC communication (15 V, 3 A, 45 W fast charging)
  • Clear pass/fail indicators for quick decision-making during testing

A1532XA EVSE Adaptor

  • Banana socket outputs for connection to a 3-phase installation tester
  • Voltage indicators on EVSE output
  • Proximity Pilot resistance selector for simulation of EV cable presence and current rating detection
  • Control Pilot resistance selector for simulation of electric vehicle status
  • Socket output for connection to a 1-phase installation tester (Phase 1, Neutral, PE)
  • Type 2 Male Plug connector for connection to EVSE
  • 6 mA EV RCD support
  • Functional tests support
  • EVSE AUTO SEQUENCE® support
  • MESM report creation
  • Load testing up to 13 A on socket - 1 phase or on banana sockets - 3 phase
  • Fault simulation of Diode short, PE-CP short and PE open
  • Output BNC connector for CP signal monitoring

What's In The Box?

  • MI 3136 EurotestCOMBO XC
  • XA EVSE Adaptor
  • 1x A 1014 Test probe, Black
  • 1x A 1015 Test probe, Blue
  • 1x A 1062 Test probe, Green
  • 1x A 1013 Crocodile clip, Black
  • 1x A 1310 Crocodile clip, Blue
  • 1x A 1309 Crocodile clip, Green
  • 1x A 1193 Test cable, BLK/GRN/BLU, 1.5m, 0.75mm2
  • 1x A 1053 Test cable, 1.5m, 0.75mm2
  • 1x A 1857 USB cable, Type C
  • Calibration certificate
  • Short instruction manual
  • Instruction manual
  • Small soft carrying bag
  • Metrel ES Manager BASIC Licence
  • SW 1201 Metrel ES Manager (program installation)
Specification

MI3136 EurotestCombo XC Tester General Specifications

  • Power supply: 7,2 V (5200 mAh ) Li-ion battery pack
  • Measuring category: 600 V CAT III; 300 V CAT IV
  • Protection class: Double insulation
  • COM port: Bluetooth, USB Type-C
  • Display: Colour TFT display, 4.3 inch, 480 x 272 pixels
  • Weight: 1.35 kg
  • Size ( l x h x w ): 272 x 152 x 70 mm

For detailed specifications, please click on the datasheet below.

A1532XA EVSE Adaptor

  • Input voltage: 400 V (3-phase)
  • Frequency: 50 Hz
  • Test current: 267 A (10ms) intermittent operation
  • Maximum load current: 13 A continuous operation
  • Proximity Pilot (PP) simulation:
    Open circuit
    13 A
    20 A
    32 A
    63 A
  • Control Pilot (CP) simulation:
    State A (not connected)
    State B (connected, not charging)
    State C (charging without ventilation)
    State D (charging with ventilation)
  • Error states:
    CP short to PE via diode
    Diode short
    PE open
  • Overvoltage category: 300 V CAT II
  • Protection degree: IP 40
  • Pollution degree: 2
  • Protection classification: Double insulation
  • Altitude: 3000 m above sea level
  • Dimensions (L x W x H): 250 x 100 x 70 mm
  • Test lead length: 0.5 m
  • Weight: 0.90 kg
  • Working temperature range: 0 °C ... 40 °C @ 95 % RH, non-condensing
  • Storage temperature range: -10 °C ... +70 °C
  • Maximum storage relative humidity:
    90 % RH (-10 °C ... +40 °C)
    80 % RH (40 °C ... 60 °C)
Label Type Size Download
pdf Metrel MI3136 Datasheet pdf 3.2 MB Download
pdf Metrel A1532XA Datasheet pdf 1.3 MB Download
