Testo 760-3 True RMS Digital Multimeter

Testo 760-3 True RMS Digital Multimeter

The Testo 760-3 True RMS Digital Multimeter is the most advanced multimeter in Testo’s 760 range, featuring True RMS and very large measurement ranges over all major electrical variables required by the professional electrician. Additionally, the device automatically detects measurement parameters and prevents incorrect settings leading to greater accuracy and speedier use.

The Testo 760-3 can measure AC/DC voltage, AC/DC current, resistance, frequency, capacitance, and temperature with maximum values of 1000V, 10A, 60MΩ, 60MHz, 60,000µF, and 500℃. Diode and continuity testing are also possible whilst the Testo 760-3’s basic accuracy is an excellent ±0.1%, in part helped by its True RMS capabilities. The user can have further confidence in the readings as the device is rated as Cat IV up to 600V and Cat III up to 1000V.

In addition to this excellent measuring capacity, the Testo 760-3 also has several practical features to help the user. First and foremost, the device automatically detects measurement parameters based on the engaged sockets and then lights up the correct function key so the measurement settings are visible at a glance. Moreover, the large, backlit screen shows an error message if the user attempts the wrong measurement so taking readings with incorrect settings is impossible with the Testo 760-3. The function keys themselves are also an upgrade on the traditional multimeter dial as they make the device simpler and quicker to use.

The user benefits from the Testo 760-3’s two-year warranty and sturdy build quality. Overall, the excellent measurement ranges and advanced, modern operation of the Testo 760-3 make it a brilliant tool for measuring all basic electrical variables.

Testo part number: 05907603

Key Features

• True RMS leading to 0.1% basic accuracy
• AC/DC Voltage: 0.1mV to 1000V
• AC/DC Current: 0.1µA to 10A AC/DC
• Resistance: 0.1 to 60MΩ
• Frequency: 0.001Hz to 60MHz
• Capacitance: 0.001nF to 60,000µF
• Temperature: -20 to +500℃
• Diode test
• Continuity test
• Cat IV up to 600V / Cat III up to 1000V
• Modern function keys rather than traditional multimeter dial
• Automatically detects parameters based on engaged sockets
• Buttons illuminated depending on parameters
• No possibility of incorrect settings
• Sizeable, backlit digital screen
• 2-year warranty
