Trend LANTEK IV-L 500MHz Copper Certifier

 Limited Time Only | Offer ends 31st July 2026

TRADE-IN OFFER AVAILABLE:
For a limited time, LanTEK II owners can benefit from a 30% discount on a new LanTEK IV-S / FiberTEK IV. Please contact us for more information.

Trend LANTEK IV-L 500MHz Copper Certifier

The Trend LANTEK IV-L 500MHz Copper Certifier enables the certification of cables to Cat 6A/Class EA in 10 seconds, that complies to DRCU/PoE compliance. The LanTEK IV-L is ETL verified to TIA 1152-A/IEC 61935-1 level IIIE 500 MHz performance offering an essential solution for copper cable certification. The LanTEK IV-L is compatible with the Trend Sapphire Care Plan, that is designed to reduce the amount of down time, reduce the cost of ownership and help protect the owner from unforeseen repair bills.

The Trend VisiLINQ™ Permanent Link Adapters present a new and unique way to test in loud working environments, the LAnTEK IV-L has a clear visual indication providing immediate identification of the test status. The clear colour key alerts users to the test status: White: Torch mode,  Blue: Connected/Ready to test, Green: Pass, Yellow: Marginal Pass/Fail or Red: Fail

The LanTEK IV-L is complete with TIA 6A and ISO/EN/CENELEC EA certification and accurate to ETL and verified to TIA 1152-A/IEC 61935-1 level IIIE 500 Mhz performance. Using the LanTEK IV-L a number of measurements can be performed including;

• Length and wiretap with TDR of the fault location
• Main/Remote NEXT, PSNEXT, Return Loss, PSACR-F, ACR-N performance certification
• Main/Remote TCL/ELTCTL noise immunity certification
• Resistance Unbalance PoE++ certification
• Easy troubleshooting with distance to next/return fault location

LanTEK IV Series Certifiers

Trend AnyWARE Cloud Test Management System

The LanTek IV-L is compatible with the Trend AnyWARE Cloud Management system that allows for real time collaboration between field technicians and management. The device can be pre-configured and set up so jobs and testing can be conducted with the elimination of potential mistakes.Trend Anyway can be operated using a PC, Mac and tablets or both Android and iOS devices.

Projects can be re-certified easily and quickly using the software to save time, money and unsustainable callbacks with a simple touch of a button. All files including the cable layout drawings, videos and photos in to the AnyWARE Cloud. All data can be shared easily in report format. Using the TeamViewer function of the Cloud, allows for project managers to to connect to a LanTEK IV-L on a job site and assist field technicians to streamline troubleshooting time and increase the collaboration.

Using Fleet Management function, fleet managers can see the user of the certifier, when results have been synced, view software updates available and when a calibration is due. Using these functions allows for instrument down time to be reduced and ensure all data recorded is synced and not lost or deleted. Software updates can be installed directly from the cloud using Wi-Fi allowing for testers to be updated even when in the field without the need for a PC or special software.

Key Features

• Certifies cabling to Cat 6A/Class EA in 10 seconds including DCRU/PoE compliance
• TCL noise immunity and and distance to NEXT fault measurements
• Use the Sapphire Care Plan to help reduce downtime and unexpected bills
• Accurate to ETL Verification to TIA 1152-A/ IEC 61935-1 Level IIIe 500 MHz Performance
• Measure length and wiretap with TDR fault location
• Main/Remote NEXT, PSNEXT, Return Loss, PSACR-F, ACR-N performance certification
• Main/Remote TCL/ELTCL noise immunity certification
• Resistance unbalance PoE++ certification
• Easy troubleshooting with distance to NEXT/Return fault location
• Trend VisiLINQ™ permanent link adapters present a new and unique way to test loud working conditions thanks to the clear colour coded key
• VisiLINQ™ permanent link adaptors to help increase productivity
• Compatible with Trend AnyWARE Cloud software allowing for real time collaboration between project managers and field technicians
• Create reports and re-certify with a touch of a button
• TeamViewer Live Support allowing for support of field technicians remotely
• Fleet management to determine where the certifier is and any software updates needed
• Touchscreen
