Trend Tone Generator - R180002

Trend Networks
SKU: TRENDR180002
  • Trace longer cables and solve issues faster with polarity & continuity tests
  • Incorporated features such as RJ45 port and Tone Pattern Indicator
  • Battery powered tactile interface with portable, compact design
More Info
In Stock - Available Next Day

Trend Tone Generator - R180002

The Trend Tone Generator features a fantastic power output for tracing longer cables and solves issues faster thanks to a power supply for external talk sets. With this handheld, compact instrument users can swiftly verify cabling via included polarity and continuity tests.

Operated via a push button interface and featuring bright LED indicators, the Trend Tone Generator is simple to use and requires no training. The large Test Mode Selection and Tone Pattern Selection Buttons are combined with clear Tone Pattern Indicator, Low Battery Indication & Line Status LEDs. Battery powered, this Tone Generator includes an RJ45 Port and useful tether point to be used in conjunction with the included carry strap.

The Trend Tone & Probe Kit combines the Trend Amplifier Probe with the Trend Tone Generator to create a kit which can find cabling fast alongside comprehensive line testing features for troubleshooting & service verification. For more details please consult our Trend Tone & Probe Kit page.

Key Features

  • Power output for tracing longer cables
  • Power supply for external talk sets
  • Polarity test
  • Continuity test
  • Tone Pattern Indicator LED
  • Line Status LED
  • Tactile interface
  • Portable, compact design
  • Carry strap tether
  • Battery powered
  • Low battery indication LED
  • Part of the exceptional Trend Tone & Probe Kit

Trend part number: R180002

What's In The Box?

  • Trend Tone Generator
  • RJ45 to RJ11 Patch Cord
  • Crocodile to RJ45 Patch Cord
  • Carry Strap
  • User Guide
Specification
  • Port: RJ45 socket (pin 4&5 Line 1, Pin 3&6 Line 2)
  • Functions: Tone, Continuity, battery supply, line status (polarity, DC & Ringing Voltage)
  • Tone frequency: Alternating f1= 982.5 Hz, f2 =1312.5 Hz
  • Output Power: ≥ +10dBm @ 600 Ω
  • Output Voltage on continuity mode: 6-8 V DC
  • Talk battery power supply: 6.0 V DC
  • Battery: 9 V alkaline
  • Auto power off: 3 hours
  • Operation time: 70 hours typical
  • Operating Temperature: -20 °C to +60 °C
  • Storage Temperature: -40 °C to +70 °C
