FLIR i34 App-Enabled Thermal Camera - Wi-Fi Only

FLIR
SKU: FLIRI34
  • App-based functionality with direct cloud integration
  • 240 x 320 thermal imaging with Flir MSX® enhancement
  • Rugged design with IP54 rating and 2m drop protection
More Info
Typically ships in 7-10 working days

FLIR i34 App-Enabled Thermal Camera - Wi-Fi Only

The FLIR i34 App-Enabled Thermal Camera is a next-generation thermal inspection camera that combines the power of apps with a high performance thermography inspection tool, which allows for scalable, intuitive, and connected asset condition monitoring. This helps users to quickly assess equipment health, streamline maintenance, and improve overall network reliability. The Flir iXX series solves issues that are often associated with traditional thermal inspections, by incorporating a high-quality, app-driven platform that can simplify inspections, standardise data, and effortlessly scale across teams and sites. Built on FLIR's advanced ACE operating system, the iXX series utilises an app-driven platform with a high performance thermal imaging camera.

The FLIR i34 utilises innovative hardware features such as a built-in worklight, laser, 8MP visual camera, and a large high-resolution touchscreen, designed to support efficient inspection and documentation. With an IR resolution of 240 x 320 pixels, and a field of view (FOV) of 38° x 49°, the i34 allows for clear communication in the field, and streamlines reporting and data sharing by automatically linking thermal images and sensor data to specific assets in your system.

Connected workflows can reduce reporting time from as much as half the job to almost nothing, which allows for concrete focus on repairs as opposed to paperwork. Work orders can be created instantly in the field to shorten Mean Time to Repair (MTTR) and improve uptime, safety, and efficiency. Diagnostic apps enable faster, smarter decisions by helping even less experienced technicians accurately assess asset conditions without extensive training. Built-in enterprise security apps ensure compliance and keep data protected behind company firewalls. Multi-sensor integration, which combines thermal, acoustic, moisture, and other data, provides a richer, more complete picture of asset health.

The FLIR i34 has an excellent thermal sensitivity of <40mK, and combines thermal and optical data with tools such as MSX imaging, picture-in-picture, and a built-in laser pointer for accurate alignment. A bright 5-inch touchscreen, onboard annotation, and multiple colour palettes make inspections clear and efficient, while Wi-Fi, USB-C, and Flir Ignite cloud connectivity simplify storage and sharing. Built for field use, the i34 is IP54 rated, drop-tested to 2m, and powered by a long-lasting rechargeable battery, making it the ideal solution for thermal diagnostics. Optional FLIR Assetlink software allows for users to increase efficiency through asset-centric data, route guidance, aiming support, inspection reports, asset health dashboards, and more. FLIR Ignite can also be used to create reports and securely store, access, and share thermal images directly from the camera, anytime, anywhere.

FLIR part number: 18455-1101

Key Features

  • App-based functionality that enables efficient and secure inspections to maintenance workers at any skill level
  • Direct cloud integration with Flir IgniteTM or Assetlink via Wi-Fi for immediate uploading, organisation, and sharing of data as well as seamless reporting and analysis
  • Built on the FLIR Ace platform, the iXX series works with apps developed by FLIR, customers, and trusted third-party developers, so that the camera can evolve with your inspection needs.
  • Crystal clear, 240 x 320 pixel thermal images with Flir-patented MSX® enhancement, which embosses visible details onto thermal images for faster problem identification
  • Utilised on electrical and mechanical inspections across industrial and utility environments, which enables early fault detection and reduced downtime
  • Can also be used for high-level condition monitoring programmes with asset hierarchy, cloud-based data management, and team-wide collaboration
  • <40mK thermal sensitivity, a built-in laser pointer, and a bright 5-inch touchscreen
  • Rugged and designed for use in the field with an IP54 rating and 2m drop tested

FLIR Assetlink

This product is compatible with FLIR's Assetlink, which is a browser-based platform that connects inspection data to your asset hierarchy, helping you reduce reporting time, simplify workflows, and boost operational efficiency. It works with FLIR Exx, T5xx, T8xx, and iXX cameras, and is compatible with any browser-enabled device, so you can manage inspections from anywhere, whether in the field or the office. Assetlink is available in four configurations, which are as follows:

  • FLIR Assetlink - 10 Users, 1 Year (T850158)
  • FLIR Assetlink - 100 GB Storage, 1 Year (T850161)
  • FLIR Assetlink - 15 Users, 1 Year (T850159)
  • FLIR Assetlink - 20 Users, 1 Year (T850160)

To learn more about FLIR Assetlink, or to purchase one of four licensing options, click here.

FLIR ACE and the Approved App Gallery

FLIR ACE ensures that instruments that are built on the Android Camera Ecosystem (ACE) will work just like a smartphone, powered by and utilising apps to make inspections faster, easier, and much more convenient. By harnessing the power of the ACE ecosystem, instruments become powerhouses that host both Flir and third-party apps to solve common but challenging user issues.

You can find these approved apps onboard FLIR instruments, in the FLIR app store. Apps developed by both FLIR and trusted third-party developers are available, ensuring that your instruments evolve with inspection needs. Some examples of these apps are listed below:

FLIR Assetlink - With FLIR Assetlink, you can increase efficiency through asset-centric data, route guidance, aiming support, inspection reports, asset health dashboards, and more. Requires a FLIR Assetlink account to operate.

FLIR Ignite - Unlock the ability to create reports and securely store, access, and share thermal images - directly from the camera, anytime, anywhere. Requires a FLIR Ignite account to operate.

A range of other third-party apps are also available, which benefit users and help them in several different ways.

FLIR iXX-Series Comparison Table

  FLIR i34 FLIR i35 FLIR i64 FLIR i65
IR Resolution 240 x 320 pixels 240 x 320 pixels 480 x 640 pixels 480 x 640 pixels
Camera Temperature Range −20°C to 200°C (−4 to 392°F) 10°F to 450°C (50°F to 842°F) −20°C to 200°C (−4 to 392°F) 10°F to 450°C (50°F to 842°F) −20°C to 200°C (−4 to 392°F) 10°C to 550°C (50°F to 1022°F) −20°C to 200°C (−4 to 392°F) 10°F to 550°C (50°F to 1022°F)
Thermal Sensitivity/NETD <40mK at 30°C (86°F) <40mK at 30°C (86°F) <40mK at 30°C (86°F) <40mK at 30°C (86°F)
Field of View (FOV) 38° x 49° 38° x 49° 38° x 49° 38° x 49°
Spatial Resolution 2.9 mrad 2.9 mrad 1.5 mrad 1.5 mrad
Display 5 in. 720 x 1280 colour LCD 5 in. 720 x 1280 colour LCD 5 in. 720 x 1280 colour LCD 5 in. 720 x 1280 colour LCD
Image Modes MSX, Thermal, Picture-in-Picture, Digital Camera MSX, Thermal, Picture-in-Picture, Digital Camera MSX, Thermal, Picture-in-Picture, Digital Camera MSX, Thermal, Picture-in-Picture, Digital Camera
Accuracy ±2°C (±3.6°F) or ±2% ±2°C (±3.6°F) or ±2% ±2°C (±3.6°F) or ±2% ±2°C (±3.6°F) or ±2%
Digital Camera, Resolution, FOV 8 MP, Autofocus, 50.5° x 64.5° 8 MP, Autofocus, 50.5° x 64.5° 8 MP, Autofocus, 50.5° x 64.5° 8 MP, Autofocus, 50.5° x 64.5°
Cellular No Yes No Yes

Specialists In Thermal Imaging Solutions

Watch the video above to see how we can help you find the right thermal imaging solution & get in touch on 0113 248 9966 or sales@test-meter.co.uk.

As the UK's leading thermal imaging solutions provider, we have a wide range of knowledge and experience. From common electrical and industrial mechanical inspections to renewable energy, building inspections and much more, our thermography-trained team ensures your enquiry is looked after from start to finish.

Find the best solution for your application and budget through:

  • Onsite-demo/remote consultations on request
  • 'Try Before You Buy' and hire options available
  • After-sales care that provides ongoing calibration and servicing
  • Finding the optimal software package, ensuring the correct reporting and data functionality for your needs

To help you find the right thermal imaging solution, please get in touch on 0113 248 9966 or sales@test-meter.co.uk

What's In The Box?

  • FLIR i34 Infrared Camera with battery
  • Extra battery
  • Battery charger
  • USB-C cable
  • Printed documentation
  • Hard transport case
  • Wrist strap
Specification

Imaging and Optical Data

  • IR Resolution – 240 x 320 pixels
  • Thermal Sensitivity/NETD - <40mK at 30°C (86°F)
  • Field of View (FOV) – 38° x 49°
  • Minimum Focus Distance – 0.5m
  • Spatial Resolution (IFOV) – 2.9 mrad
  • F-number – 1.4
  • Image Frequency – 30Hz
  • Focus – Fixed focus
  • Spectral Range - 7.5–13µm
  • Colour Palettes – Iron, White Hot, Black Hot, Rainbow, Arctic, Lava, Rainbow HC

User Interface

  • Display – 5 in. 720. X 1280 colour LCD
  • Touch Screen – Capacitive touch
  • Text – Text annotation on image using onscreen keyboard
  • Flashlight – Manually activated bright LED
  • Image Adjustment – Automatic/Manual

Laser Pointer

  • Laser – Class 2
  • Laser Alignment – Position of laser pointer automatically displayed on the infrared image

Image Presentation Modes

  • Image Modes – MSX, Thermal, Picture-in-Picture, Digital camera

Measurement

  • Camera Temperature Range - −20°C to 200°C (−4 to 392°F), 10°F to 450°C (50°F to 842°F)
  • Accuracy - ±2°C (±3.6°F) or ±2%

Measurement Analysis

  • Spotmeter – Centre spot, box with min./max.
  • Isotherm – Above, Below
  • Delta T – Yes, NFPA 70B compliant
  • Emissivity Correction – Variable from 0.1 to 1.0
  • Emissivity Table – Emissivity table of predefined materials
  • Measurements Correction – Emissivity, matt/semi-matt/semi-gloss + custom value, reflected apparent temperature, atmospheric compensation
  • 1-touch Level/Span – Yes; automatic contrast

Storage of Images

  • File Formats – Standard JPEG, 14-bit measurement data included
  • Storage Media – Internal memory, onboard Flir ignite cloud and Assetlink connectivity

Digital Camera

  • Digital Camera, Resolution – 8 MP, Autofocus
  • Digital Camera, FOV – 50.5° x 64.5°

Data Communication Interfaces

  • Cellular - No
  • Interfaces – USB-C: Data transfer to and from PC and MAC device
  • Wi-Fi – IEEE 802.11 a/ac/b/g/n (2.4 and 5 GHz)

Radio

  • Operating Frequency – WLAN 2.4 GHz: 2412 to 2462 MHz, WLAN 5 GHz: 5150 to 5250 Mhz

Power System

  • Battery Type – Rechargeable Lithium-ion battery
  • Battery Operating Time – 4 hours at 25°C (77°F) ambient temperature and typical use
  • Charging System – Battery is charged inside the camera or in specific charger (included)
  • Charging Time – 2 hours in charger / 4 hours to 90% capacity in-camera
  • Power Management – Automatic shut-down
  • AC Operation – Optional accessory: 45 W AC adaptor, 100V to 240V AC input, 15V DC, 3A output to camera

Environmental and Certifications

  • Drop Test – 2m (6ft 7in)
  • Encapsulation – IP54 IP54 (IEC 60529)
  • Operating Temperature Range - –15°C to 50°C (5°F to 122°F)
  • Storage Temperature Range - –40°C to 70°C (–40°F to 158°F)
  • Humidity (Operating and Storage) - IEC 60068-2-30/24 h 95% relative humidity
  • EMC – EN 301 489-1, EN 301 489-17, EN 61000-6-3, EN 61000-6-2, FCC 47 CFR Part 15 Class B
  • Radio Spectrum – ETSI EN 300 328, ETSI EN 301 893, FCC 47 CFR part 15, RSS-247
  • Shock – 25g (IEC 60068-2-27)
  • Vibration – 2g (IEC 60068-2-6)

Physical Data

  • Camera Weight, Incl. Battery – 0.8kg (1.76lb)
  • Camera Size (L x W x H) – 225 x 136 x 73mm (8.9 x 5.4 x 2.9in)
  • Colour - Black
