Kewtech KT64DL Multifunction Tester & KEWEVA Adaptor Kit

Kewtech KT64DL Multifunction Tester & KEWEVA Adaptor Kit

The Kewtech KT64DL Multifunction Tester & KEWEVA Adaptor Kit includes the compact and reliable KT64DL multifunction tester, along with the simple yet effective KEWEVA EV Charge Point Testing Adaptor. When combined, these two instruments offer a comprehensive and efficient solution for the testing of EV charge points and standard electrical installations.

The Kewtech KT64DL Multifunction Tester is a compact, lightweight, and high-performance instrument designed for testing and certifying both domestic and commercial electrical installations. It offers essential features such as insulation and continuity testing, full no-trip loop testing on all types of RCDs, and a dedicated 6mA DC test for EV charge point verification, making it a future-proof investment for electricians.

Safety is a key focus, with simultaneous PSC and PFC readings displayed alongside loop impedance, anti-trip technology, and continuous live voltage monitoring to prevent damage during testing. The "No Bangs" feature ensures blown fuses and damaged PCBs are avoided, while the electronic hands-free lock-down test button enhances both safety and convenience.

Designed for ease of use, the KT64DL features a single rotary dial for function selection, a large, clear display, and an intuitive interface that simplifies the testing process. Its innovative design includes ultra-slim probe tips, allowing easy access to push-fit connector blocks commonly found in modern electrical installations. A built-in magnetic base enables hands-free attachment to metal cabinets, freeing up the user’s hands for other tasks.

Built to withstand the demands of daily use, the KT64DL has a robust and durable construction with an IP54 rating, providing protection against dust and water ingress. It comes with a soft carry case for safe transport, a mains lead, distribution board leads for versatile connections, and a padded neck strap for added comfort throughout the working day.

Kewtech KEWEVA EV Charge Point Testing Adaptor

The Kewtech KEWEVA EV is an EV charge point adaptor designed for ease of use, featuring a simple single-dial operation. It works by simulating the presence of a car, allowing for accurate testing of EV supply equipment functionality. With a lower resistance design that ensures high-quality loop measurements, the KEWEVA also includes an in-built CP auto check for added reliability.

Unlike adaptors with cables, the KEWEVA is cable-free, eliminating the risk of tangled wires during testing. It is suitable for both single and three-phase charging equipment and connects using standard 4mm connectors. A separate red LED provides a clear indication when voltage is applied, giving the user confidence in their testing process. Supplied with a durable carry case, the KEWEVA is a practical and efficient tool for EV charge point testing.

Kewtech part number: KT64DL/EVA

Key Features

• Continuity - switchable buzzer and auto null
• Insulation - 250, 500 & 1000V with voltage warning LED and auto discharge
• Loop - ATT (low current), high current 0.01 ohm resolution
• Anti Trip Technology loop for full no trip Loop testing of RCDs with low susceptibility of RCD uplift and noise interference
• PSC/PFC - clear indication of what is being tested and displayed with loop reading
• RCD - Type AC, A, ACS, AS, auto & ramp
• Type AC RCDs - Tests 10mA, 30mA, 100mA, 300mA & 500mA
• Type A RCDs - Tests 10mA, 30mA, 100mA & 300mA
• 6mA DC test at 0 & 180 for EV charge point testing
• 30mA x 1 RCD test at 0 & 180
• RCD auto test mode for 30 mA RCDs
• RCD ramp test function
• SDP testing
• Gold plated probe tips for more consistent readings
• Test leads auto-null for continuity mode
• Polarity check
• Instant correct wiring status check
• Red LEDs will indicate live status per phase
• A single rotary dial controls the CP status simulation, with standby, ready, and charging
• Seperate RED LED indicates when the voltage is applied to output connectors
• Auto check of 1kHz
• IEC 62196-2 Type 2 connector for EV charging units
• LED indication of phases
• Type 2 male connector for EVSE connection
• Cordless for ease of use
• One of the smallest products available for EV point testing
