Testo 550s Smart Digital Manifold (Choice Of Kit)

SKU: TESTO550S
  • Automatic Bluetooth connection for wireless measurement
  • Rugged Digital Manifold with 2-way valve block
  • Compatible with Testo Smart App & Testo DataControl Software
More Info
Choose Your Free Gift

For a limited time only we're giving away a FREE Testo branded Socket & Bit Set with every Testo 300 & Testo 327 Flue Gas Analyser and Testo 550i, Testo 550s , Testo 570s & Testo 557s Digital Manifold.
Offer available until the 30th of April 2024. Terms and conditions apply.

Buy a Testo 550i, 550s or 557s digital refrigeration manifold and get a FREE professional work light!
Offer valid while stocks last.

Testo 550s Digital Manifold

The Testo 550s Digital Manifold featuring incorporated Bluetooth, is an ergonomically designed device with a large easy-to-use display. Exceptionally compact and featuring a 2-way valve block, the 550s is ideal for commissioning, servicing and performing maintenance on refrigeration systems and heat pumps. The automatic Bluetooth connection provides the user with the ability to measure vacuum and temperature wirelessly & efficiently. The bigger screen with dot matrix technology aids user in evaluating results by showing more values simultaneously and creating flexible graphics, such as an analogue look for fast and easy pressure values.

For tasks with crucial system parameters, the 550s Digital Manifold features stored programs which provide the user with clear operational guides. Assisting with measurements, these programs automatically determine numerous variables such as superheating, sub cooling, cooling/heating capacity and more. Test menu sequences are included for vacuum, target superheat, pressure leak test and discharge line temperature. Refrigerant favourites are also now saved internally for easy selection, with the list constantly updated by the free app.

With an improved operating concept and fewer buttons, the intuitive Testo 550s guarantees continuously high performance. Due to a direct and easy wireless connection up to 150m, Testo Smart Probes remain consistently connected to your device. Effortlessly link these Testo probes for temperature, pressure and humidity readings. The robust housing of the 550s covering an internal metal frame boasts an IP54 protection rating, ensuring the durability needed for difficult workspaces.

Testo 550s Heat Pump Kit

The Testo 550s Heat Pump Kit allows user to measure monobloc or split heat pump systems. Supplied with a Testo 770-3 clamp meter for compressor current testing, whilst the Testo 560i digital scales allow for accurate and effective refrigerant charging via weight. The test menu sequence for pressure leak test, vacuum, discharge line temperature and target superheat (Testo 552i required for vacuum measurement). The kit comes complete with two Testo 115i Bluetooth temperature clamp probes that allow for simple measurements of superheat and subsoil values. The Testo Heat Pump kit provides users the ideal kit to measure, commission, service and maintain heat pumps, refrigeration and air conditioning systems.

Testo 552i Smart Probe Vacuum Gauge (optional extra)

The Testo 552i Smart Probe Vacuum Gauge is a robust device ideal for quickly and easily identifying vacuum. Measure vacuum wirelessly though a single service port and avoid unnecessary leaks, utilising the probe's integrated 45˚ angle for simple installation. Rated IP54, this Smart Probe automatically connects to the free Testo Smart App or Digital Manifold via Bluetooth with a range of up to 130m. Results are displayed graphically either in app or on the manifold digital display screen.

Testo Smart App

The Testo Smart App is a free to download App on iOS and Android, suitable for use in all refrigeration, air conditioning, heating and ventilation applications. Users are able to operate, measure and document test results when using the Smart App alongside all compatible Testo Bluetooth enabled measuring instruments. Pro measurement programs air balancing and multi site measurements allow numerous sites to be managed simultaneously.

The App is easy to use thanks to the intuitive measurement menus with quick configuration and uncomplicated documentation design. All measurements are quickly viewable in just a few clicks with graphic and tabular curve displayed. Test measurements and customer data can be stored on the app, with reports easily generated and dispatched to customers and colleagues direct from the App.

The Testo Smart app is free to download and free to use, and is always up to date thanks to continuous updates and extensions from Testo. Data exchange is also available with the Testo PC software DataControl.

Testo DataControl Software

Including an intuitive user interface, the Testo DataControl Software provides the user with all the information available in a single click. Save and export graphics, with up to 4 readings displayable at once. Manage customer profiles, sort, filter measurements & even assign measuring points using this professional software.

Testo 550s Digital Manifold Kits

The Testo 550s is available in four sets; Testo 550s Basic Kit, Testo 550s Smart Kit, Testo 550s Smart Kit With Hose Set and Testo 550s Heat Pum Kit.

  Testo 550s
Basic Kit
Testo 550s
Smart Kit
Testo 550s
Smart Kit
With Hose Set
Testo 550s
Heat Pump Kit
Order No. 0564 5501 02 0564 5502 02 0564 5503 02 300564 5502 02
Smart Digital Manifold
Calibration Protocol
Instrument Case
Clamp Temperature Probe Kit - - -
Wireless Clamp Temperature
Probe (Smart Probe)
- ✔ x2 ✔ x2 ✔ x2
Testo 560i Digital refrigerant scale set - - -
Testo 770-3 Clamp meter - - -
Hose filling set (3 hoses) - - -

Key Features

  • Bluetooth & App connection
  • No cables or wires
  • Large digital display
  • Intuitive user interface
  • Ideal for refrigeration, air conditioning systems & heat pumps
  • Incorporates 2-way valve block & robust hook
  • Automatic probe recognition
  • Control using a smartphone or tablet
  • Hard-wearing housing
  • Rated IP 54
  • Compact, minimalistic design
  • Usable with Testo Smart App
  • Easy-to-read results
  • Craft professional reports
  • Built-in favourite refrigerants list
  • Compatible with Testo Smart Probes
  • Measure vacuum, temperature & humidity wirelessly
  • Test menu sequences for superheat, discharge line temp and more
  • Compatible with Testo DataControl Software
  • Manage measuring points and customer profiles

Testo Refrigeration Manifolds Range Overview

Order No. Kit Name Case, Calibration
Protocol &
Batteries
2x NTC
Temperature
Probes
2x 115i Smart
Probes
1x Testo 552i
Smart Probe
Hose Filling Set 1x 770-3 Clamp Meter

1x 560i Digital refrigerant scale set


0564 2550 02 Testo 550i - - - - - - -
0564 3550 02 Testo 550i
Smart Kit
- - - - -
300564 3350 02 Testo 550i
Heat Pump Kit
- - - -

0564 5501 02 Testo 550s
Basic Kit
- - - - -
0564 5502 02 Testo 550s
Smart Kit
- - - - -
0564 5503 02 Testo 550s
Smart Kit
With Hoses
- - - -
300564 5502 02 Testo 550s
Heat Pump Kit
- -

0564 5571 02 Testo 557s
Smart Vacuum Kit
-   - -

0564 5572 02

Testo 557s
Smart Kit
With Hoses
-
300564 5571 02 Testo 557s
Heat Pump Kit
- - ✔ & Intelligent Valve Set

What's In The Box?

Testo 550s Basic Kit Includes:

  • Clamp Temperature Probe Kit
  • Hard Instrument Carrying Case

Testo 550s Smart Kit Includes:

  • 2 x Testo 115i Wireless Clamp Temperature Probe (Smart Probe)
  • Hard Instrument Carrying Case

Testo 550s Smart Kit With Hose Set Includes:

  • 2 x Testo 115i Wireless Clamp Temperature Probe (Smart Probe)
  • Hose Filling Set (3 Hoses)
  • Hard Instrument Carrying Case

Testo 550s Heat Pump Kit (300564 5502 02) Includes:

  • Testo 550s Digital Manifold (without sight glass) including 4 x AA batteries. Bluetooth connection use with Testo Smart App (Free download0
  • 2 x Testo 115i Bluetooth Pipe Clamp Thermometers
  • 1 x Testo 770-3 Clamp meter
  • 1 x Testo 560i Digital refrigerant scale set
  • Carry case
  • User guides
  • Calibration protocol
Specification

Technical Data

  • Operating Temperature: -10 to +50 °C
  • Storage Temperature: -20 to +60 °C
  • Battery Type: 4 AA microcells
  • Battery Life:
    250 h with no illumination, no Bluetooth
    100 h with illumination and Bluetooth
  • Auto Power Off: After 10 minutes when not connected via Bluetooth
  • Dimensions: 210 x 121 x 60 mm
  • Weight: 826 g
  • Protection Class: IP54
  • Bluetooth Technology/Range: Bluetooth® 5.0/150 m
  • Compatibility:
    requires iOS 11.0 or newer/Android 6.0 or newer
    requires mobile terminal device with Bluetooth® 4.0

Sensor Type

  • Measuring range
    Pressure: -1 to 60 bar
    Temperature: -50 to +150 °C
  • Accuracy (at 22 °C)
    Pressure: ±0.5% fs
    Temperature: ±0.5 °C
  • Resolution
    Pressure: 0.01 bar
    Temperature: 0.1 °C
  • Probe Connections
    Pressure: 3 x 7/16" – UNF
    Temperature: 2 x plug-in (NTC)
  • Overload
    Pressure: 65 bar
    Temperature: -
