Chauvin Arnoux A196A 610mm Power Quality Clamp IP67

SKU: CHAUA196450

Never Beaten On Price



We’re always working hard to give you the best possible price, but if you find it cheaper somewhere else, we’ll endeavour to match the price.



Call 0113 248 9966 or contact us online

Typically ships in 5-7 working days
Need Some Help From Our Experts? chevron-right chevron-down

We're always happy to offer help, information & advice to find the right instrument for you, so please get in touch.



To speak to our sales team, call us on 0113 248 9966, use our Live Chat service or contact us online.

Members earn 268 reward points chevron-right chevron-down

Use reward points to get money off future purchases.



Please note: Customers must be signed into their account to be elegible. Find out more about reward points here.

FREE Delivery & 60 Day Returns chevron-right chevron-down

We offer FREE standard delivery on all orders over £249, with a range of next-day options also available on many items.



Find out more on our delivery information page.

Key Features
  • IP67-rating ideal for CA8435 or PEL106 Power Quality Analysers
  • 190mm clamping diameter, 610mm length
  • 100mA to 10kA AC measurement range

Chauvin Arnoux A196A-610 Power Quality Clamp (IP67 rated)

The perfect clamp for use with the Chauvin Arnoux Power Quality Analysers in an outdoor environment due to the IP67 rating of the sensor. This includes the CA8435 and PEL106 analysers and loggers.

The A196A-610 offers a clamping diameter of 190mm, a length of 610mm and a measurement range of 100mA to 10kA AC.

With an IEC 61010 rating of 1,000V CAT III / 600V CAT IV

Chauvin Arnoux part number: P01120554

Chauvin Arnoux Power Quality Clamp Options

Model Measurement Range Clamping Ø / Length IEC 61010
MN93 500mA to 200A AC 20mm 600V CAT III / 300V CAT IV
MN 93A 0.005A to 100A AC 20mm 600V CAT III / 300V CAT IV
MA193 100mA to 10kA AC Ø 70 mm / 220 mm 1,000V CAT III / 600V CAT IV
PAC93 1A to 1,000A AC, 1A to 1,300A DC 1 x Ø 39mm, 2 x Ø 25mm 600V CAT III / 300V CAT IV
A193-450 & A196-450 100mA to 10kA AC Ø 140mm / 450mm 1,000V CAT III / 600V CAT IV
A193-800 100mA to 10kA AC Ø 250mm / 800mm 1,000V CAT III / 600V CAT IV
C193 1A to 1,000A AC 52mm 600V CAT IV
E3N 50mA to 10A AC/DC, 100mA to 100A AC/DC 11.8mm 600V CAT III / 300V CAT IV
