Fluke SMFT-1000 Solar PV Multifunction Tester and I-V Curve Tracer - PRO Kit

SKU: FLUKESMFT1000PROKIT
  • Fluke Pro kit including Fluke SMFT-1000 Solar PV Multifunction Tester and I-V Curve Tracer,Fluke TruTest™ Data Management and Reporting Software advanced licence and PVLEADS3 MC4 Solar Clamp Test Lead Set
  • All-in-one PV system test solution meeting IEC 62446-1 standards for Category 1 and Category 2 tests
  • Data and results easily exported and stored to an external device through Fluke's TruTest™ software
More Info
£4,054.80 £3,379.00
Typically ships in 3-5 working days

Purchase an SMFT-1000 Solar PV Multifunction Tester or PRO Kit before 31st December 2023, and claim a free Fluke 393FC/E Solar Clamp Meter or the Compact Fluke PTi120 Pocket Thermal Camera!

How to claim your bonus gift:
1. Get your hands on a Fluke SMFT-1000 or tool kit (FLUKESMFT1000 / FLUKESMFT1000PROKIT) by 31st December, 2023.
2. Claim your FREE Fluke gift: click here
(you will need a receipt or invoice as proof of sale - packing slips or order confirmations will not be accepted).
3. Receive and enjoy your new free Fluke tool

SPECIAL OFFER: For a limited time only, purchase the Fluke SMFT-1000 Solar PV Multifunction Tester and I-V Curve Tracer PRO Kit at a reduced promotional price.

Fluke SMFT-1000 Solar PV Multifunction Tester and I-V Curve Tracer - PRO Kit

The Fluke SMFT-1000 Solar PV Multifunction Tester and I-V Curve Tracer - PRO Kit includes the Fluke SMFT-1000 Solar PV Multifunction Tester, Fluke TruTest™ Data Management and Reporting Software and Fluke PVLEAD3 MC4 Solar Clamp Test Lead Set.

Fluke SMFT-1000 Solar PV Multifunction Tester and I-V Curve Tracer

The Fluke SMFT-1000 Solar PV Multifunction Tester and I-V Curve Tracer is targeted at PV professionals for the installation, commission and maintenance of PV systems in both commercial and Industrial industries that operate at 1000V DC or below. The SMFT-1000 offers full sequence testing to IEC 62446-1 Category 1 standards and System performance testing to IEC 62446-1 category 2 standards. For category 1 testing, protective resistance RLO, Voltage on an open circuit including polarity VOC, short circuit current ISC and insulation resistance RINS. For category 2 testing the SMFT-1000 can test irradiance, temperature, tilt and cardinal direction.

The SMFT-1000's colour screen provides an easy walk through of tests thanks to the on screen instructions. The Auto test mode allows for automatic sequence testing in a variety of combinations such as, with or without insulation tests, IEC 62446-1 testing for category 1 and 2 and IEC 624460-1 testing for protection class I and class III.

Safety rated to CAT III 1000V DC and CAT III 700V AC, the SMFT-1000 also uses Flukes 'Keep the leads' system removing the need for the operation to change the configuration of test leads when conducting different tests. Using the same test leads reduces the set up time and reduces errors when testing PV systems.

Fluke IRR2-BT Irradiance Meter

The Fluke SMFT-1000 tester Kit includes a Fluke IRR2-BT irradiance meter allowing operators to record precise I-V curve measurements, real time irradiance and temperature, when the SMFT-1000 tester and IRR2-BT are used together. The IRR2-BT can record data for up to 17 hours even if the wirelessing connectivity is broken. \the recordings can be uploaded at a later point should this happen. The IRR-2 BT has a measurement range of 50 to 1400 W/m² and a temperature range of -30°C to 100°C. The IRR2-BT allows users to make instant measurements to determine the watts per square meter solar irradiation, required by IEC 62446-1 standard. The IRR2-BT also includes a mounting bracket for accurate irradiance and temperature readings at the panel.

Visual Inspection

To meet PV systems IEC regulations for visual inspections, the Fluke SMFT-1000 features a setting that can record observations to the internal memory. These observations can be later downloaded to the Fluke Trutest™ software and included into any report generated.

Fluke TruTest™ Data Management and Reporting Software advanced licence

The Fluke SMFT-1000 Solar PV Multifunction Tester and I-V Curve Tracer - PRO Kit includes one Fluke TruTest™ Data Management and Reporting Software advanced licence for the Fluke SMFT-1000 Solar PV Multifunction Tester. The softare  allows for data to be easily exported to an external device directly from the tester for further analysis and data storage without having a computer in the field. Pervious measurements can be compared and analysed against new recordings quickly and easily, allowing comprehensive client reports to be generated. Printable test certificates and customised reports can be produced with company logos and signatures using the software.

Live data can be viewed on screen using then Fluke dashboard interface. Pre-defined test codes or alternatively creating their own, users are able to ensure the correct data is collected. Tree Topology Flexible testing and reporting can be maintained through hierarchical tree topology, allowing large networks of clients, sites, locations and appliances to be easily managed.

Fluke Premium Care Plan

The Fluke Premium Care Plan aims to reduce the cost of ownership of the SMFT 1000 by eliminating the service and support charges, the Care Plan is available as a one year or three year option. The care plan includes one annual calibration per year at a Fluke Authorised Service Centre. If any accessories originally shipped with the SMFT 1000 are discovered to be defective, these will be replaced free of charge once a year under the care plan.

If the users SMFT 1000 is accidentally damaged, then repair of the tester will also be covered in the care plan, providing users with peace of mind should any unforeseen accidents happen.

With the Fluke Premium Care Plan the calibration, repair, collection and delivery of the SMFT 1000 will expedited reducing the downtime for the user.

Simply check the one year or three year service plan when placing your order, and your new analyser will be protected with Fluke premium care.

Care Plan Benefits vs Standard Warrranty

  Standard Warranty Fluke Premium Care
Repair manufacturing defects
Annual calibration
Accidental damage and repair of main unit
Expedited calibration and repair
Expedited freight
Replacement or repair of damaged accessories
Priority Tech Support

PVLEAD3 MC4 Solar Clamp Test Lead Set

The Fluke SMFT-1000 Solar PV Multifunction Tester and I-V Curve Tracer - PRO Kit includes one set of PVLEAD3 MC4 Solar Clamp Test Leads. The Test leads are designed for use alongside clamp meters that accept 4mm sheathed banana plugs to test, measure and troubleshoot on solar PV panels. The leads create a connection between solar panels and inverter when measuring with a clamp meter. The test lead set includes a black and red MC4 solar clamp test leads. The Black MC4 red lead (male) breakout to 12 inch MC4 (female) and 36 inch 4mm sheathed banana plug test lead.

The PVLEAD3 test leads are CAT III 1000V and CATIV 600V safety rated and comply with 20A ratings according to IEC/EN 61010-031 specifications.

We know the importance of getting the right instrument for the job, so we now offer a "Try Before You Buy" option on many of our products to help you make a more informed buying decision. Simply give us a call or click here to find out more.

Key Features

Fluke SMFT-1000 Solar PV Multifunction Tester and I-V Curve Tracer:

  • Designed for PV professionals that provide installation, commissioning and maintenance services to systems that operate at 1000 V DC or under
  • Conforms to IEC 62446-1 standards
  • Full sequence safety testing IEC 62446-1 Category 1
  • Protective resistance earth (Rpe) testing
  • Voltage on open circuit (Voc) testing
  • Short circuit current (Inc) testing
  • Insulation resistance (Rins) testing
  • Polarity testing
  • Auto Test mode
  • Diode testing
  • ROI and system performance testing – IEC 62446-1 Category 2:
  • I-C Curve tracing and software analysis with TruTest™
  • Wireless irradiance meter and mounting bracket
  • Irradiance, temperature, tilt and cardinal direction
  • Keep the leads system for one time test lead configuration
  • Colour screen
  • On location I-V Curve results
  • Recorded visual inspection
  • Fluke backpack
  • i100 AC/DC current clamp

Fluke TruTest™ Data Management and Reporting Software:

  • Management of installation and commissioning test and measurement data
  • Create inspections and reports compliant with IEC 62446-1 as well as international directives
  • Provides I-V curve analysis containing easily identifiable pass/fail visuals; see changes in I-V curve over multiple site visits
  • Compare historical site data and view performance and condition changes over time

PVLEAD3 MC4 Solar Clamp Test Lead Set:

  • Black and red MC4 to 4mm adaptor test leads for solar applications
  • Black MC4 (female) to 4mm sheathed banana plus on a 60 inch test lead
  • Red lead MC4 (male) to 4mm sheathed banana plug ion a 60 inch test lead
  • Compatible with testing tools that accept 4mm sheathed banana plugs
  • Ensures safe current and voltage measurements of PV modules and systems
  • Connect measuring devices to test, measure and troubleshoot solar PV panels
  • Nickel plated contacts
  • Temperature Range: +5°C to +40°C (+41°F to +104°F)
  • Current: 20A
  • Complies to IEC / EN 61010-031 standards/ CAT III 1000V / CAT IV 600V rated

We teamed up with Fluke to host a webinar, entitled "Installation Commissioning & Maintenance of Solar Systems with SMFT-1000", hosted by Fluke's Marc Sherwood (Senior Technical Sales Manager).

In this webinar, Marc be demonstrated best practices for testing a commissioned Solar Farm or Domestic Solar Installation using the Fluke SMFT-1000, while also covering solar energy trends, the UK solar market, PV testing standards, troubleshooting PV installations, associated PV testing products and more.

Check it out on our YouTube channel now.

What's In The Box?

  • Fluke SMFT-1000 Multifunction PV analyser
  • IRR2-BT Wireless Solar Irradiance Meter
  • i100 AC/DC Current Clamp 100A
  • MB1-IRR Panel Mounting Bracket (for Irradiance Meter)
  • Zero Adapter
  • 80PR-IRR External Temperature Probe
  • TPAK Magnet Set
  • Carry Strap (for SMFT-1000)
  • Carry Case (for Irradiance Meter)
  • TP1000 Test Probe with Remote Test Button
  • TL1000-MC4 Test Lead Set (Male and Female)
  • Coupler Set
  • Fuse Pack
  • TL1000/30M 30 m Test Lead on Reel
  • TL1000-KIT Test Lead Kit
  • IR Optical-to-USB Adapter Cable
  • FlukePack30 Professional Tool Backpack
  • Batteries: 6 x AA Alkaline IEC LR6 (for SMFT-1000, not installed), 4 x AA Alkaline IEC LR6 (for IRR2-BT, not installed),2 x AA Alkaline IEC LR6 (for i100, not installed)
  • Fluke TruTest™ Data Management and Reporting Software x1 Licence
  • Set of black and red solar power clamp test leads
Specification

Fluke SMFT-1000 Solar PV Multifunction Tester and I-V Curve Tracer

Technical Specifications

  • Protective conductor resistance (Rlo)
  • Accuracy: ± (2 % + 2 Digit)
  • Measurement range: 0.20Ω to 199Ω
  • Resolution: 0.1Ω maximum
  • Test current: ≥ 200 mA (≤ 2Ω + Rcomp)
  • Test Voltage: 4V DC... 10V DC
  • Polarity reversing: Yes
  • Test lead zero: Up to 3 Ω
  • PV module/ PV string, open- circuit voltage (VOC)
  • Display range: 0.0V to 1000V DC
  • Measuring range: 5.0V DC - 1000V
  • Resolution: 0.1V - 1V DC
  • Accuracy: ± (0.5 % + 2 Digit)
  • Polarity test: Yes
  • PV module/ PV string, short circuit current (Is/c)
  • Display range: 0.0A - 20.0A
  • Measurement range: 0.2A - 20.0A
  • Resolution: 0.1A
  • Accuracy: ± (1 % + 2 Digit)

Insulation Resistance:

  • Display range: 0.00 - 199.9Ω
  • Measuring range: 0.20MΩ - 199.9MΩ
  • Resolution: 0.1 MΩ maximum
  • Accuracy: 0.00V- 99.9MΩ ±(5 % + 5 Digit) - 100MΩ- 1999.9MΩ ±(10 % + 5 Digit)

Test voltage at no load:

  • Measuring range: 50V/ 100V/ 250V up to 199MΩ- 500V/1000V up to 999MΩ
  • Resolution: 1V
  • Accuracy: 0 % to + 20 %
  • Test voltage @ ≥ 1 mA: 250 V @ 250 kΩ, 500 V @ 500 kΩ, 1000 V @ 1 MΩ
  • Resolution: 1V
  • Accuracy: 0 % to + 10 %
  • Testing Current: Min. 1 mA (@ 250 kΩ / 500 kΩ / 1 MΩ), Max. 1.5 mA (short circuit)

Blocking diode checking:

  • Display range: 0.00V DC - 6.00V DC
  • Measuring range: 0.50V DC - 6.00V DC
  • Resolution: 0.01V DC
  • Accuracy: ± (5 % + 10 Digit)

Overvoltage protective devices (BV):

  • Display range: 0.00V DC- 1000V DC
  • Measuring range: 50V DC- 1000V DC
  • Resolution: 1V DC
  • Accuracy: ± (10 % + 5 Digit)

AC/DC voltage measurement via 4mm test sockets:

  • Display range: 0.00V AC - 700V AC 0.00VDC - 1000V DC
  • Measuring range: 5.0V AC - 700V AC, 5.0V DC - 1000V DC
  • Resolution: 0.1V - 1.0V
  • Accuracy: ± (2.5 % + 2 Digit)
  • Detection AC/DC: Yes (automatic)
  • =/- polarity check: Yes

AC/DC voltage measurement via 4mm test sockets:

  • AC/DC current with i100 clamp adaptor:
  • Display range: 0.0A DC - 100A DC, 0.00A AC - 100A AC TRMS
  • Measuring range: 1.0A AC - 100A AC TRMS
  • Resolution: 0.1A
  • Accuracy (DC, AC 50Hz/60Hz): ± (5 % + 2 Digit), i100 clamp tolerances not inclusive

i100 Clamp adaptor tolerances:

  • Measuring range: 1A -100A DC or AC < 1kHz
  • Accuracy (DC, AC 50Hz/60Hz): ± (1.5 % + 0.1 A)

AC/DC power measurement (with i100 clamp adaptor)

  • Display range: 0.00V AC - 700V AC, 0.00V DC - 1000V DC
  • 0A AC/DC - 100A AC/DC
  • 0kW/kVA- 100kW/kVA
  • Measuring range: 5.0V AC - 700A AC, 5.0V DC - 1000V DC
  • 1A AC/DC - 100A AC/DC
  • Resolution: 0.1V, 0.1A, 1kW/kWA
  • Accuracy (DC, AC 50 Hz/60 Hz): Voltage AC/DC ± (2.5 % + 2 Digit)
  • A AC/DC ± (6.5 % + 3 Digit)
  • kW/kVA ± (10 % + 4 Digit)

General specifications:

  • Dimensions: 10cm x 25cm x 12.5cm (3.8" x 9.9" x 4.9")
  • Weight: 1.4kgs (3.09lb)
  • Battery: 6 x AA IEC LR6 batteries
  • Operating temperature: 0 °C to 50 °C (32 °F to 122 °F)
  • Storage temperature: -30 °C to 60 °C (-22 °F to 140 °F) batteries removed

Wireless radio module:

  • Frequency range: 2.402 GHz to 2.480GHz
  • Output power: 8 dBm

Fluke TruTest™ Data Management and Reporting Software

System requirements

  • Operating system: Microsoft Windows 10. 64-bit and 32-bit recommended Microsoft Windows 8/8.1 64-bit and 32-bit Windows 7 with service pack 1, 64-bit and 32-bit
  • System memory: Minimum 4 GB RAM (6-bit) or 2GB RAM (32-bit)
  • Hard disk space: Minimum 2 GB available hard disk space
  • Display Resolution: Minimum screen resolution 1366x768
  • Communication Interfaces: USB

PVLEAD3 MC4 Solar Clamp Test Lead Set

  • Lead length: 36 inch, 12 inch
  • Contact: Brass, Nickel plated
  • Test lead type: 4mm Connector test leads
  • Colour; Black and Red
  • Voltage: CAT III 1000V, CAT IV 600V
  • Current: 20 amp
  • Standards: IEC 61010-031
