Leica Disto D5 R Laser Distance Meter

Leica
SKU: LEICAD5R
  • Conducts outdoor measurements with ease, with the target always visible even in harsh or unpredictable conditions
  • The D5 R can conduct several tests, with the Leica DISTO Plan App allowing for data to be uploaded and analysed
  • This product can be purchased on its own, or as part of Leica DISTO D5 R Pro Pack which includes a tripod and accessories
More Info
Typically ships in 2-4 working days

Leica Disto D5 R Laser Distance Meter

The Leica Disto D5 R Laser Distance Meter has been designed with distance measurements in outdoor areas in mind. With an in-built digital pointfinder, and the ability to use the product with the Leica DISTO Plan App, issues can be solved with ease and efficiency. Results can be easily documented, allowing the user to reference back to them at a later date. This allows for an error-free and target-orientated workflow.

The D5 R's target is always clearly visible on the display, with IPS technology ensuring that this is the case even if the laser dot is not able to be seen. This ensures accuracy of aiming, and therefore allows for precise results in the most challenging of environments. The measurement can be triggered with non-contact gestures, which means that the device does not have to be moved, and precise measurements can be guaranteed. The ability to trigger the D5 with hand movements is a new feature that has been implemented by Leica.

With various measurement modes available, such as Smart Horizontal Mode for measuring over obstacles, height tracking, profile or angle measurements ensure that every measurement task can be solved. In keyboard mode, the user can also connect the D5 to a computer, and send values through.

Various advanced measurement functions are available on the D5 R, which are as follows:

  • The D5 R's features: Turn the D5 on, press the the ON/DIST button, and you will receive an accurate measurement. With a range of 200 metres, and an accuracy of ±1mm, the D5 R can accurately measure in a plethora of environments.
  • Skecth Plan - The user can create a sketch on a smart phone or tablet, and assign distance measurements taken with the D1 to each line. The app has an 'auto-scale' function which adjusts the lines and scales the results
  • Sketch on Photo - Document a job site condition with a mobile phone in the Disto Plan App, and then add the exisiting dimensions from the D1, along with a sketch and message that can be sent to people who need the information. Watch the video below to learn more about the 'Sketch on Photo' feature

The Leica DISTO Range

Use this comparison table to compare Leica Disto lasers, and determine which one is best for you.

  DISTO D1 DISTO D110 DISTO D2 BT DISTO X3 DISTO X4 DISTO D5 R
Indoor/Outdoor Use Mainly Indoor Use Mainly Indoor Use Mainly Indoor Use Mainly Indoor Use Indoor/Outdoor Use Indoor/Outdoor Use
Accuracy/Range 2mm/40m 1.5mm/60m 1.5mm/100m 1mm/150m 1mm/150m 1mm/200m
Intelligent Endpiece ✔ ✔ ✔ ✔ ✔ ✔
Smart Horizontal X X X ✔ ✔ ✔
Bluetooth V4.0 Smart V4.0 Smart V4.0 Smart V4.0 Smart V4.0 Smart V4.0 Smart
Outdoor Pointfinder Camera X X X X ✔ ✔
Measure with Picture X X X X X X
SmartBase X X X X X X

DISTO Plan Software

The DISTO Plan App can dramatically improve productivity by transferring measurements, aswell as accurate sketches and plans, via bluetooth. The user can visualise, measure, communicate and document a project with efficiency and ease.

The user can measure a rough floor plan, then add measurements, doors, windows and perspective. Then, they can take a photo, add dimensions, notes, dates and forward on to who needs it. Finally, they can communicate through difficult processes to speed up the process.

Leica Disto part number: 950908

Key Features

  • 200 meter range
  • 2.4" scratch resistant display
  • Bright & clear, with IPS technology
  • ±1mm accuracy
  • Measures slopes
  • Smart horizontal mode
  • Memory for 50 measurements
  • Li-ion rechargeable battery
  • IP54 for dust & splash water protection
  • Multifunctional end-puece with automatic detection
  • Can be operated by hand gestures

What's In The Box?

  • Leica Disto D5 R
  • DISTO Pouch
  • USB Cable
  • Hand Loop
  • Calibration Certificate Silver
  • 3 year warranty
Specification
  • Accuracy with favourable conditions - 1mm / 1/16"
  • Accuracy with unfavourable conditions - 2mm / 1/8"
  • Range with favourable conditions - 0.05 - 200m / 0.07 - 660ft
  • Range with unfavourable conditions - 0.05 - 120m / 0.07 - 400ft
  • Smallest unit displayed - 0.1mm / 1/32"
  • X-Range Power Technology - yes
  • Laser - Class 2, 635nm, <1mW
  • Digital Pointfinder with 4-fold zoom - yes
  • Tilt measuring range - 360°
  • Tilt measuring tolerance - ± 0.2°
  • ø laser point | at distances - 6 / 30 / 60mm | 10 / 50 / 100m
  • Protection class - IP54 (dust and splash water protected)
  • Auto. laser switch off after - 90s
  • Auto. power switch off after - 180s
  • Bluetooth Smart - Bluetooth V5.0
  • Range of Bluetooth Smart - up to 10m
  • Battery durability (Li-ion 2,000mAh) - up to 5,000 measurements, up to 10 hours operation time
  • Dimension (H x D x W) - 144 x 60 x 24mm | 5.7 x 2.4 x 0.9in
  • Weight (with batteries) - 180g / 6.35oz
  • Temperature range storage | operation - -25 to 70°C / -13 to 158°F | -10 to 50°C / 14 to 122°F
