Leica Disto D5 R Pro Pack

Leica
SKU: LEICAD5RPROPACK
  • Allows for outdoor measurements to be taken with ease and accuracy, with an in-built digital pointfinder to enhance the experience
  • The D5 R Pro Pack comes with a TRI 75 Tripod and Adaptor, which allows for the hands-free usage of the distance meter
  • The D5 R is available as a stand alone product or as part of a Pro Pack, which features accessories
More Info
In Stock - Available Next Day

Leica Disto D5 R Pro Pack

The Leica Disto D5 R Distance Meter has been designed to conduct outdoor distance measurements with ease and accuracy. With an in-built digital pointfinder, and the potential for the product to be used in conjunction with the Leica DISTO Plan App, issues are able to be solved with ease and efficiency. The results that are collated can easily be documented, allowing the user to be able to refer back to them at a later date. This ensures an error-free and target-orientated workflow, which massively benefits the user.

The target of the D5 R is always clearly visible on the display, with IPS technology ensuring that this is the case, even if the laser dot itself cannot be seen with the eye. This ensures high-accuracy when aiming, and therefore allows for clear and precise results, even in the most challenging of environments. The D5 R also includes an exciting feature, which means that it can be activated with non-contact gestures. This allows for the instrument to be activated without touch, which means that it can be kept in the correct position to enable high-accuracy measurements.

With various measurement modes available, such as Smart Horizontal Mode which enables for measurement over obstacles, height tracking mode, and profile and angle measurements that ensure every measurement task can be solved. Also, whilst in keyboard mode, the user can connect the D5 to a computer, and send values through which can then be analysed and tested on.

The D5 R Pro Pack

The D5 R is available as part of the 'D5 R Pro Pack', which is supplied with the standard accessories that are part of the D5 R, which are a pouch, a charger with cable, and hand loop. The Pro Pack also includes an FTA 360 Adaptor, which allows for D5 R to be mounted to the supplied TRI 75 Tripod. This allows for the D5 to be held in place, and when used in conjunction with the 'Gesture' feature, this allows quick and efficient usage. Aswell as these two exciting accessories, the user will also receive a Quick Start Guide, a Warranty Card, a Safety Manual, and a Silver Calibration Certificate, as well as a 3 year warranty.

The D5 R has various advanced functions, which are as follows:

  • The D5 R's features: Turn the D5 on, press the ON/DIST button, and you will receive an accurate measurement. With a range of 200 metres, and an accuracy of ±1mm, the D5 R can accurately measure in a plethora of environments.
  • Skecth Plan - The user can create a sketch on a smart phone or tablet, and assign distance measurements taken with the D1 to each line. The app has an 'auto-scale' function which adjusts the lines and scales the results
  • Sketch on Photo - Document a job site condition with a mobile phone in the Disto Plan App, and then add the exisiting dimensions from the D1, along with a sketch and message that can be sent to people who need the information. Watch the video below to learn more about the 'Sketch on Photo' feature

The Leica DISTO Range

Use this comparison table to compare Leica Disto lasers, and determine which one is best for you.

  DISTO D1 DISTO D110 DISTO D2 BT DISTO X3 DISTO X4 DISTO D5 R
Indoor/Outdoor Use Mainly Indoor Use Mainly Indoor Use Mainly Indoor Use Mainly Indoor Use Indoor/Outdoor Use Indoor/Outdoor Use
Accuracy/Range 2mm/40m 1.5mm/60m 1.5mm/100m 1mm/150m 1mm/150m 1mm/200m
Intelligent Endpiece ✔ ✔ ✔ ✔ ✔ ✔
Smart Horizontal X X X ✔ ✔ ✔
Bluetooth V4.0 Smart V4.0 Smart V4.0 Smart V4.0 Smart V4.0 Smart V4.0 Smart
Outdoor Pointfinder Camera X X X X ✔ ✔
Measure with Picture X X X X X X
SmartBase X X X X X X

DISTO Plan Software

The DISTO Plan App can dramatically improve productivity by transferring measurements, aswell as accurate sketches and plans, via bluetooth. The user can visualise, measure, communicate and document a project with efficiency and ease.

The user can measure a rough floor plan, then add measurements, doors, windows and perspective. Then, they can take a photo, add dimensions, notes, dates and forward on to who needs it. Finally, they can communicate through difficult processes to speed up the process.

Leica Disto part number: 950879

Key Features

  • 200 meter range
  • 2.4" scratch resistant display
  • Bright & clear, with IPS technology
  • ±1mm accuracy
  • Measures slopes
  • Smart horizontal mode
  • Memory for 50 measurements
  • Li-ion rechargeable battery
  • IP54 for dust & splash water protection
  • Multifunctional end-puece with automatic detection
  • Comes with a TRI 75 Tripod and a FTA 360 Adaptor
  • The D5 R Pro Pack has accessories that enhance the D5 R's capabilities

What's In The Box?

  • Leica Disto D5 R
  • DISTO Pouch
  • Charger with USB Cable
  • Hand Loop
  • FTA 360 Adaptor
  • TRI 75 Tripod
  • Quick Start Guide
  • Calibration Certificate Silver
  • 3 year warranty
Specification
  • Accuracy with favourable conditions - 1mm / 1/16"
  • Accuracy with unfavourable conditions - 2mm / 1/8"
  • Range with favourable conditions - 0.05 - 200m / 0.07 - 660ft
  • Range with unfavourable conditions - 0.05 - 120m / 0.07 - 400ft
  • Smallest unit displayed - 0.1mm / 1/32"
  • X-Range Power Technology - yes
  • Laser - Class 2, 635nm, <1mW
  • Digital Pointfinder with 4-fold zoom - yes
  • Tilt measuring range - 360°
  • Tilt measuring tolerance - ± 0.2°
  • ø laser point | at distances - 6 / 30 / 60mm | 10 / 50 / 100m
  • Protection class - IP54 (dust and splash water protected)
  • Auto. laser switch off after - 90s
  • Auto. power switch off after - 180s
  • Bluetooth Smart - Bluetooth V5.0
  • Range of Bluetooth Smart - up to 10m
  • Battery durability (Li-ion 2,000mAh) - up to 5,000 measurements, up to 10 hours operation time
  • Dimension (H x D x W) - 144 x 60 x 24mm | 5.7 x 2.4 x 0.9in
  • Weight (with batteries) - 180g / 6.35oz
  • Temperature range storage | operation - -25 to 70°C / -13 to 158°F | -10 to 50°C / 14 to 122°F
