DiLOG DL9110 Multifunction Tester

SKU: DILOGDL9110
  • Features RCD-LOC XLT high accuracy loop test without tripping RCDs or RCBOs
  • Insulation resistance, continuity, polarity and RCD trip time and ramp testing
  • Automatic start for loop and continuity testing once connections are in place
More Info
Discontinued

DiLOG DL9110 Multifunction Tester

Please note this product has been discontinued. For a replacement tester please see the Dilog DL9118.

The DiLOG DL9110 Multifunction Tester boasts testing functions including insulation resistance testing (250V, 500V), continuity testing, high-current loop impedance testing, PSC & PFC tests, polarity testing, RCD trip time testing with multiple test currents, and RCD ramp testing. Additionally, it can measure voltage (0V-440V) and frequency (45Hz-65Hz).

In addition to its many test functions, the DiLOG DL9110 also boasts several additional useful features that make testing easier and more efficient. Notably, the brand new RCD-LOC XLT feature enables a highly accurate loop test without tripping any RCDs or RCBOs thanks to up-lift noise cancelling technology. Auto start for loop and continuity tests, meanwhile, can automatically perform a test once appropriate connections are in place but a Full Range Protection feature helps prevent damage should the tester be connected across phases.

Readings are shown on the DiLOG DL9110’s large, coloured display which lights up in a different colour to show an error. The test function is selected using an ergonomic dial and clearly labelled push buttons allow users to adjust the test settings before executing a test automatically or with the large ‘TEST’ button. Robust construction can stand up to the challenges of regular use and the MFT comes supplied with a useful hard carry case and a range of rest leads.

DiLOG part number: DL9110

Key Features

  • Three-wire, no-trip, high-current loop impedance test
  • Insulation, continuity, PSC and PFC tests
  • RCD trip time, current and ramp testing
  • RCD-LOC XLT accurate no-trip loop test
  • Auto start for loop and continuity testing
  • Large LCD screen with colour change to indicate error
  • Select test function using simple dial
  • Two-year warranty
  DL9110 DL9118
Continuity Test
Insulation Test 250V, 500V 250V, 500V, 1000V
Auto Start Loop & Continuity
RCD Test (AC, A, S-type)
Colour RGB display
Colour change indicates error
Auto RCD Test
RCD Ramp Test
Loop Test (3-wire no-trip)
PFC and PSC Fault Current(L-PE/L-N)
Phase-Phase Line Test (L-L)
Phase Rotation
Remote Probe
Intelligent Full Range Protection
Full calibration certificate

Dilog DL9110 Multifunction Tester

Professional Electrician Award Winner

For a limited time only, the Dilog DL9110 is available with a free Dilog DL6790 Voltage and Continuity Tester as a special launch promotion!

The Dilog DL9110 Multifunction Tester is boasts testing functions including insulation resistance testing (250V, 500V), continuity testing, high-current loop impedance testing, PSC & PFC tests, polarity testing, RCD trip time testing with multiple test currents, and RCD ramp testing. Additionally, it can measure voltage (0V-440V) and frequency (45Hz-65Hz).

In addition to its many test functions, the Dilog DL9110 also boasts several additional useful features that make testing easier and more efficient. Notably, the brand new RCD-LOC XLT feature enables a highly accurate loop test without tripping any RCDs or RCBOs thanks to up-lift noise cancelling technology. Auto start for loop and continuity tests, meanwhile, can automatically perform a test once appropriate connections are in place but a Full Range Protection feature helps prevent damage should the tester be connected across phases.

Readings are shown on the Dilog DL9110’s large, coloured display which lights up in a different colour to show an error. The test function is selected using an ergonomic dial and clearly labelled push buttons allow users to adjust the test settings before executing a test automatically or with the large ‘TEST’ button. Robust construction can stand up to the challenges of regular use and the MFT comes supplied with a useful hard carry case and a range of rest leads.

Dilog part number: DL9110

Key Features

  • Three-wire, no-trip, high-current loop impedance test
  • Insulation, continuity, PSC and PFC tests
  • RCD trip time, current and ramp testing
  • RCD-LOC XLT accurate no-trip loop test
  • Auto start for loop and continuity testing
  • Large LCD screen with colour change to indicate error
  • Select test function using simple dial
  • Three-year warranty
 DL9110DL9118
Continuity Test
Insulation Test 250V, 500V 250V, 500V, 1000V
Auto Start Loop & Continuity
RCD Test (AC, A, S-type)
Colour RGB display
Colour change indicates error
Auto RCD Test
RCD Ramp Test
Loop Test (3-wire no-trip)
PFC and PSC Fault Current(L-PE/L-N)
Phase-Phase Line Test (L-L)
Phase Rotation
Remote Probe
Intelligent Full Range Protection
Full calibration certificate

What's In The Box?

  • Dilog DL9110 Multifunction Tester
  • Padded neck strap
  • Professional carry case
  • DI-LOG mains lead
  • 1.2 M black test lead
  • 1.2 M red test lead
  • 1.2 M green test lead
  • Black crocodile clip
  • Red crocodile clip
  • Green crocodile clip
  • MN1500 (AA) 1.5v Batteries x 6
  • DL9110 Operating Instruction Manual
  • Calibration certificate
Specification
  • Display: 3½ digit LCD 1999 digits
  • Insulation resistance: 0.05 – 2000 MΩ
  • Test voltage at 1mA: 250 & 500V
  • Continuity: 0.05 – 199 Ω
  • Loop Impedance: 0.01 – 2000 Ω
  • PSCC: 0 – 26 kA
  • RCD nominal test currents: 10, 30, 100, 300, 500 mA, ½ x 30 mA, 5 x 30 mA
  • Trip time: 0 – 500 ms
  • Tripping current with ramp test: ½ rated current to 1.1 rated current
  • Voltage: 0 – 440 V
  • Frequency: 45 – 65 Hz
  • Safety standards: EN61010, BS EN 61557 BS 7671
  • Over voltage category: CAT III 440 V
  • Power supply: 6 x 1.5 V AA batteries
  • Dimensions: 260 x 105 x 55 mm
  • Weight: 836 g
