Leica Disto D2G Green Laser Distance Meter with Bluetooth

Leica Disto D2G Green Laser Distance Meter with Bluetooth

The Leica Disto D2G Green Laser Distance Meter with Bluetooth is an accurate and compact laser distance meter designed for precise indoor measurements, particularly in bright environments where laser visibility is important. With its highly visible green laser dot, which is up to four times more visible than a standard red laser, the D2G allows users to measure with greater confidence across a wide range of indoor applications. The instrument can measure up to 120 metres with an accuracy of ±1.5mm, in line with ISO 16331-1 standards.

The D2G features an automatic multifunctional endpiece, helping users achieve accurate results when measuring from corners, edges, or tight spaces. With Bluetooth 6.0 and NFC technology, measurements can be transferred quickly and easily to a smartphone, tablet, or compatible software, reducing the chance of manual recording errors and speeding up the process of storing and analysing results. The instrument is also compatible with the DISTO Plan app, allowing users to create plans, document measurements, and improve their workflow from site to office.

The ergonomic design makes the D2G easy to use, without sacrificing the quality or reliability of the results. Simply measure the intended target area, log the results digitally, and share them with the necessary people.

Advanced Functions

• Min/Max Distance Tracking - The user can select the Min/Max function, which automatically tracks the minimum and maximum distance from a position. This is useful for measuring the shortest distance at a right angle to a wall, or the longest diagonal distance across a room.
• Smart Horizontal Mode - The built-in inclination sensor allows the user to take accurate horizontal measurements, even when obstacles prevent a direct straight-line measurement.
• IP54 Rating - This ensures the instrument is protected against dust and splash water, allowing it to be used confidently across a variety of indoor environments.
• Painter Function - The Painter function allows the user to quickly determine wall surface areas by measuring the width of each wall and the room height, making it especially useful for estimating decorating, painting, or renovation work.
• Green Laser Technology - The D2G uses Leica’s advanced green laser technology for superior visibility, helping users identify the laser point more easily in bright indoor conditions.
• DISTO Plan App Compatibility - Measurements can be transferred directly to the DISTO Plan app, allowing users to create room plans, document results, and improve measurement organisation.

The Leica DISTO Range

Use this comparison table to compare Leica Disto lasers, and determine which one is best for you.

DISTO Plan Software

The DISTO Plan App massively improves productivity by allowing for measurements to be transferred quickly, aswell as sketches and plans. The user can then visualise, measure, communicate and document a project with ease and efficiency.

The user can measure a rough floor plan, then add measurements, doors, windows and perspective. Then, they can take a photo, add dimensions, notes, dates and forward on to who needs it. Finally, they can communicate through difficult processes to speed up the process.

Leica Disto part number: 1017808

Key Features

• Measures distances up to 120m, making it suitable for a wide range of indoor measuring tasks.
• Delivers accurate professional measurements with an accuracy of ±1.5mm.
• Uses a green laser dot, offering improved visibility compared with standard red laser models.
• Designed primarily for bright indoor environments, while outdoor use is possible when the laser point remains visible.
• Includes Bluetooth 6.0 for quick transfer of measurements to a smartphone, tablet, or compatible software.
• Features NFC connectivity for simple pairing and faster workflow.
• Compatible with the Leica DISTO Plan app for creating plans, documenting measurements, and organising results.
• Includes an intelligent fold-out endpiece with automatic position detection for accurate measuring from corners, edges, and tight spaces.
• Features Smart Horizontal Mode for indirect horizontal measurements when a direct line is obstructed.
• Includes an inclination sensor to support angle-based measuring functions.
• Offers useful measuring functions including area, volume, painter function, Pythagoras, addition, and subtraction.
• Built with IP54 protection, helping protect the instrument against dust and splash water.
• Compact, lightweight, and ergonomic for comfortable everyday site use.
