Testo 310 (2nd Gen) Flue Gas Analyser Printer Kit

SKU: TESTO3102KIT
  • Supplied with all standard accessories and Testo Printer
  • Fixed probe and quick start up time for efficient and easy use
  • Complies with BS7967 and EN50379. Ideal for commissioning new boilers
More Info
£508.98 £424.15
In Stock - Available Next Day
Choose Your Free Gift

This summer we're giving you a FREE set of Water Pump Pliers with every NEW Testo 310 (2nd Gen) Flue Gas Analyser or kit.
But that's not all, you still get to choose 1 of 3 free accessories on top of that. Now, that's great value!

Testo 310 (2nd Gen) Flue Gas Analyser Printer Kit

The Teso 310 (2nd Gen) Flue Gas Analyser combines a domestic standard gas analyser with an infrared printer that allows you to document your results to clients and customers.

The Testo 310 is an entry level Flue Gas Analyser designed specifically to meet the needs of the domestic service engineer. Combining simple functions with a high level of accuracy, the Testo 310 is ideal for performing all the basic measurements on heating and boiler systems.

Testo 310 Flue Gas Analyser Printer Kit Features

  • Integrated, kink resistant hose to eliminate leaks
  • Auto-zeroing of gas sensor in only 30 seconds after switching on
  • Up to 10 hours running time, with charging via USB
  • Integrated magnets on rear for easily fixing the unit to boilers
  • Condensate trap can be quickly and simply emptied
  • Two line display and clear menu structure on backlit screen
  • Measures CO, O2, Ambient CO, Flue Gas Temperature, Ambient Temperature, Draught, Pressure, Efficiency, and Flue Gas Loss
  • Supplied with a printer

Setting a new standard in reliable combustion tuning, the Testo 310 flue analyser offers quick and simple operation with intuitive navigation of testing functions and direct selection of desired measurements. The backlit display clearly shows readings, menus and descriptions of the stored fuel types to show a complete picture of the combustion process.

The gas sensors of the Testo 310 measure the exact oxygen and carbon monoxide content as well as the flue gas and ambient temperature. From these readings, parameters including CO2 value, boiler efficiency and flue gas loss can all be calculated.

The Testo 310 Domestic Flue Gas Analyser is ideal for the installation of new boilers, gas water heaters, low temperature boilers and condensing boilers as well as performing safety checks and fine tuning existing combustion systems in domestic environments.

All you need to know about servicing and calibration for this analyser

At Test Meter, we understand that choosing a new Flue Gas Analyser is not only about the cost of the analyser, but also about the cost and practicality for annual calibration and service. We've put together a useful guide that highlights all you need to know about calibration of this analyser with cost of ownership, locations of service centres in the UK and much more.

Click here to read about servicing and calibration for Testo analysers.

Testo Part Number: 0563 3107

Testo Flue Gas Analyser Comparison Table

  310 (2nd Gen) 327-1 300+
Sensors O2, CO O2, CO O2, CO, NO
Measurement ranges CO: 0-4000ppm, CO2: 0-CO2 Max CO: 0-4000ppm, CO2: 0-CO2 Max CO: 0-8000ppm, CO2: 0-CO2 Max, NO: 0-3,000ppm
NO / NOx Measurements X X Yes
Gas pressure testing
Flow/return temperature measurement X
Draught measurement Sepearate for Flue Gas measurement Parallel to Flue Gas Measurement Parallel to Flue Gas Measurement
O2 measurement (0 - 21%)
Temperature measurement (0 - 400°C) (-40 - 600°C) (-40 - 1200°C)
Instant ready standby mode X X
Printer compatible
Create & send reports directly (email/Bluetooth) X X
Inbuilt Android device X X
Software/app X X Testo EasyHeat PC Software
Memory X X 1 million measuring values
Display Graphic 7-line Display 4-Line LCD Display 5" HD Colour Display
Touchscreen X X
Sensor Warranty 2 Years 3 Years 3 Years
Instrument Warranty 2 Years 2 Years 2 Years

Available as a standalone product or part of a kit, please see the comparison table below to compare:

  Testo 310 (2nd Gen) Standard Kit Testo 310 (2nd Gen) Printer Kit
Testo 310 (2nd Gen) Flue Gas Analyser
Probe with 180mm cone
Silicone Tube for Pressure Measurement
Power Supply with Cable
Particle Filter
USB-C Cable
Battery
Calibartion Protocol
Bluetooth Printer X
Thermal Paper X
Case

What's In The Box?

  • Testo 310 (2nd Gen) Flue Gas Analyser
  • Flue Gas Probe
  • 180mm Cone
  • Silicone Tube for Pressure Measurement
  • Power Supply with Cable
  • Particle Filter
  • USB-C Cable
  • Battery
  • Calibration Protocol
  • Bluetooth Printer
  • Thermal Paper
  • Case
Specification

Temperature (Flue Gas)

  • Measuring Range - 0 to +400°C
  • Accuracy ±1 digit - ±1 °C (0 to +100°C) ±1.5% of m. v. (>100°C)
  • Resolution - 0.1°C
  • Adjustment Time - <50 sec

Temperature (Ambient Temperature)

  • Measuring Range - -20 to +100.0°C
  • Accuracy ±1 digit - ±1°C
  • Resolution - 0.1°C
  • Adjustment Time - <50 sec

Draught Measurement

  • Measuring Range - -20 to +20hP
  • Accuracy ±1 digit - ±0.02 hPa (-0,6 to +0,6 hPa), ±0.03 hPa (-3 to -0.6 hPa and +0.6 to +3 hPa), ±1.5% of m.v. (-20 to -3 hPa and +3 to +20 hPa)
  • Resolution - 0.01 hPa

Pressure Measurement

  • Measuring Range - -40 to +100hPa
  • Accuracy ±1 digit - ±0.5 hPa (0 to 50 hPa), ±1% of m.v. (remaining measuring range)
  • Resolution - 0.1hPa

O2 Measurement

  • Measuring range - 0 to 21 vol%
  • Accuracy ±1 digit - ±0.2 vol.%
  • Resolution - 0.1 vol.%
  • Adjustment time - 30 sec

CO Measurement (without H2 compensation)

  • Measuring Range - 0 to 4000ppm
  • Accuracy ±1 digit - ±20 ppm (0 to 400 ppm), ±5% of m.v. (401 to 2000 ppm), ±10% of m.v. (2001 to 4000 ppm)
  • Resolution - 1ppm
  • Adjustment time - 60 sec

Ambient CO Measurement

  • Measuring Range - 0 to 4000ppm
  • Accuracy ±1 digit - ±20 ppm (0 to 400 ppm), ±5% of m.v. (401 to 2000 ppm), ±10% of m.v. (2001 to 4000 ppm)
  • Resolution - 1ppm
  • Adjustment time - 60 sec

Efficiency Testing (Eta)

  • Measuring Range - 0 to 120%
  • Resolution - 0.1%

Flue Gas Loss

  • Measuring Range - 0 to 99.99%
  • Resolution - 0.1%

General Technical Data

  • Storage Temperature - -20 to +50°C
  • Operating Temperature - -5 to +45°C
  • Power Supply - Rechargeable battery 1500mAh, mains unit 5V/2A
  • Memory - Storage option also via the connection to the Testo Smart App
  • Display - Graphic 7-line display
  • Weight with probe - Approx. 690g
  • Dimensions - 203 x 83 x 46mm
  • Battery Life - > 8 h (pump on, 20°C ambient temperature)
  • Humidity Application Range - 0 - 80%RH
  • 0 to 80%RH - IP40
  • BT Range - 60m (without obstruction)
  • System Requirements Testo Smart App - Requires iOS 13.0 or newer; requires Andriod 8.0 or newer; requires mobile end device with Bluetooth 4.0
  • Certification - according to DIN EN 50379-1, 3
