Kewtech KT66EV Multifunction Tester & EV Adapter Kit

SKU
KEWTKT66EV
  • 12-in-1 Multifunction tester with compact EV Charging Point Adapter
  • Includes Loop testing options for both 3 & 2 wire low-current tests
  • Comprehensive RCD testing facility with 6mA DC RCD test for EVSE
More Info

As low as inc VAT £1,434.00 ex VAT £1,195.00

In Stock - Available Next Day
Choose Your Free Gift
IET Code of Practice for Electric Vehicle Charging Equipment Installation (4th Edition)
Free
£58.50
50m R2 Wander Lead
Free
£39.00

Key features:

  • Easy-to-use 50m R2 Wander Reel in a sturdy drum
  • Direct R2 measurement suitable for main earth bond testing
  • Ideal for increasing electrical installation testing efficiency
HandyMAN TEK775 Earth Leakage Clamp Meter
Free
£69.00

Key features:

  • Compact and east to operate Earth Leakage Clamp Meter
  • Ideal for fault finding leakage currents causing nuissance tripping
  • Includes 3 ranges: 200mA, 2A and 200A and resolution of 100µA
VTEK900 Electricians Kit (FREE GIFT)
Free
£38.95

VTEK900 Kit includes:

  • TEK900 Voltage & Continuity Tester
  • TEK989 Socket Tester
  • TEK7100 Non-contact Volt Stick
Kewtech KT66EV Multifunction Tester & EV Adapter Kit
Kewtech KT66EV Multifunction Tester & EV Adapter Kit

In stock

Customise Kewtech KT66EV Multifunction Tester & EV Adapter Kit
1 x Kewtech KT66DL 12-in-1 Multifunction Tester   + inc VAT £0.00 ex VAT £0.00

* Required Fields

Summary

    Product Details

    Kewtech KT66EV Multifunction Tester & EV Adapter Kit

    ** For a limited time only, the IET Code of Practice for Electric Vehicle Charging Equipment Installation (4th Edition) is available as a free gift option on this product. Available while stocks last **

    The Kewtech KT66EV Multifunction Tester & EV Adapter Kit is the ultimate package for installation testing, especially for those which involve electric vehicle charging points. Test electrical safety alongside EVSE functionality, including any EV points installed with Type B RCDs or with 6mA residual direct current devices, and in either TN or TT configurations.

    Kewtech KT66DL 12-in-1 Multifunction Tester

    The Kewtech KT66DL 12-in-1 Multifunction Tester provides a comprehensive suite of features such as a pioneering loop testing system which includes both 2 & 3 wire low current test options. Anti-Trip technology (ATT) for no trip LOOP L-PE testing on all RCDs is incorporated as is an in-depth RCD testing facility.

    Built for domestic, commercial and industrial installations, the KT66DL can perform a wide range of tests:

    • Continuity
    • Insulation
    • Hi Current Loop
    • Lo Current Loop
    • PSC
    • PFC
    • RCD
    • Volts
    • Earth Resistance
    • SPD
    • Phase Rotation
    • PAT

    The full specifications of the Kewtech KT66DL 12-in-1 MFT are detailed below

    With a 3.5 inch colour LCD dot matrix display the Kewtech KT66DL boasts an advanced internal memory with help options explaining how to connect the instrument according to the selected function. Rated CAT IV 300V and CAT III 600V, the KT66DL is fully in line with the latest IEC safety guidelines.

    Kewtech KEWEVSE EV Charging Point Adapter

    The Kewtech KEWEVSE EV Charging Point Adapter is a highly portable device which when used in combination with a suitable Multifunction Tester such as the KT66DL, enables loop, RCD and Residual Direct Current Devices (RDCD) testing. It can simulate the presence of an electric vehicle in order to test the functionality of EV supply equipment, including detecting a PE fault. Capable of PP simulation & CP states A, B, C, D, this adapter uses bright LEDs to provide clear visual indication.

    Key Features

    • 12-in-1 multifunction tester
    • For testing EV charging points
    • Capable of insulation & continuity testing
    • High & low current testing with anti-trip technology
    • Phase rotation and earth rotation features included.
    • RCD testing facility with EV charging point test
    • Loop, RCD and RDCD testing
    • Loop testing system includes 3 & 2 wire low current test options
    • Includes PE Pre-Test
    • PP simulation & CP states A, B, C, D
    • CP Error / PE Error/ Earth fault
    • LED indication of Phases
    • Colour LCD display
    • Intuitive design with simple interface
    • Advanced internal memory.
    • Rated CAT IV 300V and CAT III 600V

    Kewtech part number: KT66EV

    Kewtech KT Series Comparison Table

      KT63DL KT63 Plus KT65DL KT66DL
    200mA Continuity Test
    Automatic Test Lead Null
    250, 500 & 1000V Insulation Resistance
    PAT Testing with optional PAT Adaptor 1
    Continuous Live Warning
    High Voltage LED Light
    3 Wire No-Trip Loop Test
    2 Wire No-Trip Loop Test
    High Current Loop Test
    PSC/PFC Test
    RCD Type AC & A: 10, 30, 100, 300 & 500 mA
    RCD Type ACS & A: 100 & 300 mA
    RCD Type AC: ACS, ACS & AS 10, 30, 100, 300, 500 & 1000 mA
    RCD Auto Test: 30 mA
    RCD Auto Test: 10, 30, 100, 300, 500 & 1000 mA
    RCD Auto Test All Results On One Screen
    6mA DC RCD Test (for EVSE)
    'Hands Free' Testing
    Wiring & Lead Polarity Check
    Volts Measurement
    Backlight
    Soft Carry Case
    IP Rating 54 54 40 40
    All Auto RCD Results On One Screen
    Remote Test Probe Included
    0.001Ω Resolution High Current Loop Test
    55V Loop Test
    Phase Rotation
    Protective Lid On Instrument
    Touch Pad for Earth Potential Limits (25V or 50V)
    Lockout Test Button
    Earth Resistance Test
    PAT Test Firmware
    Download Memory
    Colour Screen

    Specifications

    Kewtech KT66DL 12-in-1 Multifunction Tester

    Loop Impedance

    • Range: 20.00/200.0/2000Ω (auto-ranging)
    • Display range: 0.00 - 20.99Ω / 16.0 - 209.9Ω / 160 - 2099Ω
    • Measuring range: 0 – 2000Ω
    • Accuracy: ±2.0% rdg ±8 dgt
    • Open-circuit voltage: 7 – 14V DC
    • Test current:
      200mA test: 200mA or more (2Ω or less)
      15mA test: 15mA ±3mA (short-circuit)

    Enabled if pre-set NULL value is 9Ω or less

    Buzzer: Buzzer sounds when measured resistance is 2Ω or less

    Volts

    • Range: 300.0/600V (Auto-ranging)
    • Display Range: Voltage:
      2.0 – 314.9V, 240 – 629V
      Frequency: 40.0 – 70.0Hz (displayed at 2V or higher)
    • Measuring Range:
      Voltage: 2 – 600V
      Frequency: 45 – 65Hz
    • Accuracy:
      Voltage: ±2% rdg ±4 dgt
      Frequency: ±0.5% rdg ±2 dgt

    Uc (RCD)

    • Mains voltage range: 100-260V
    • Range: 100V
    • Display range: 0.0 - 104.9V
    • Measuring range: 0 - 100V
    • Accuracy: +5% to +15% rdg ±8 dgt 230V
    • Test current: 50 % or less of I∆n

    Phase Rotation

    • Measuring Range: 48 – 600V / 45 - 65Hz
    • Criteria of Judgement:
      Correct sequence: Clockwise symbol and “1, 2, 3” are displayed
      Reversed sequence: Counter-clockwise symbol and “3, 2, 1” are displayed

    General

    • Applicable Standards:
      IEC 61010-1 CATIII (600V) CATIV (300V) pollution degree 2, IEC 61010 -Tester,
      -2-030, -2-034, IEC61557-1,2,3,4,5,6,7,10, IEC 60529 IP40, EN 61326-2-2 (EMC)
    • Dimensions: 136 (L) x 235(W) x 114 (D) mm
    • Weight: 1300g including batteries (8 x AA / LR6)

    Earth

      Precise Measurement Simplified Measurement
    Range 20.00 / 200.0 / 2000Ω (auto-ranging)
    Accuracy 20Ω range; ±2% rdg ±0.08Ω
    The other ranges: ±2% rdg ±3 dgt
    (Aux. earth resistance: 100Ω)
    ±2% rdg ±0.08Ω
    The other ranges: ±2% rdg ±3 dgt
    Output
    Current
    20Ω range: approx. 3mA, 200v range: approx. 1.7mA
    2000Ω range: approx. 0.7mA Frequency: 825Hz

    Insulation

    Rated Voltage 100V 250V 500V 1000V SPD (Varistor) 1000V)
    Range 2.000/20.00/200.0MΩ auto-ranging 20.00/200.0/1000MΩ auto-ranging 20.00/200.0/2000MΩ 0 -1000V (increases in 1V steps)
    Display Range 0.000 - 2.099MΩ,
    1.60 - 20.99MΩ,
    16.0 - 209.9MΩ
    0.00 - 20.99MΩ,
    16.0 - 209.9MΩ,
    160 - 1049MΩ
    0.00 - 20.99MΩ,
    16.0 - 209.9MΩ,
    160 - 2099MΩ
    1049V
    Measuring Range 0 - 200MΩ 0 - 1000MΩ 0 - 2000MΩ 0 - 1049V
    Accuracy 2.000MΩ range: ±2% rdg ±6 dgt
    20.00MΩ range: ±2% rdg ±6 dgt
    200MΩ range: ±5% rdg ±6 dgt
    20.00MΩ range: ±(2% rdg +6 dgt), 200.0MΩ range: ±(2% rdg +6 dgt) ±5% rdg +5 dgt
    1000MΩ range: ±(5% rdg +6 dgt) 2000MΩ range: ±(5% rdg +6 dgt)
    Reated meas. current 1.0 - 1.2mA at 100kΩ 1.0 - 1.2mA at 250KΩ 1.0 - 1.2mA at 500kΩ 1.0 - 1.2mA at 1MΩ 1.0mA

    Loop

    Function Loop ATT Loop High
    3-Wire L-PE 2-Wire L-PE L-PE0.01ΩRes L-PE0.001ΩRes L-N/L-L
    Mains input
    Voltage Range
    100 – 260V 50/60Hz (L-N < 20Ω) 48 – 260V 50/60Hz 100 - 260V 50/60Hz 48 - 260V 50/60Hz
    Range Loop 20.00/200.0/2000Ω (auto-ranging) 20.00/200.0/2000Ω 2.000Ω 20.00Ω
    PFC/PSC 2000A/20kA 2000A/20kA (PFC only) 2000A/50kA (PFC only) 2000A/20kA (PSC only) 2000A/20kA (PSC only)
    Display range Loop 0.00 – 20.99Ω
    21.0 – 209.9Ω
    210 – 2099Ω
    0.00 – 20.99Ω
    21.0 – 209.9Ω
    210 – 2099Ω
    0.00 – 20.99Ω
    21.0 – 209.9Ω
    210 – 2099Ω
    0.000 – 2.099Ω 0.00 – 20.99Ω
    PFC/PSC 0 - 2099A
    2.10 - 20.99kA
    0 - 2099A
    2.10 - 20.99kA
    (PFC only)
    0 - 2099A
    2.10 - 50.49kA
    (PFC only)
    0 - 2099A
    2.10 - 20.99kA
    (PFC only)
    0 - 2099A
    2.10 - 20.99kA
    (PSC only)
    Meas. range Loop 0 – 2000Ω 0 – 2000Ω 0 – 2000Ω 0 – 2Ω 0 – 20Ω
    Accuracy Loop ±(3% rdg +6 dgt) ±(3% rdg +10 dgt) ±(3% rdg +6 4gt) ±(3% rdg +25mΩ) ±(3% rdg +4 dgt)
    PFC/PSC Depending on the accuracies of voltage and LOOP measurements
    Test current @ 230V L-N:6A/60ms
    N-PE:10mA (5.3Hz)
    L-PE: 15mA 20Ω: 6A/20ms,
    200Ω: 0.5A/20ms
    2000Ω: 15mA/500ms
    25A/20ms 6A/20ms

    RCD (Mains input voltage range: 100V – 260V 50/ 60Hz. For Type AC and A RCDs rated at 100mA or higher: 190 – 260V)

    Mode Rated residual operating current (mA)(I∆n) Test current Duration
    Current (mA) rms Accuracy @230V Meas. time Accuracy
    x 1/2 AC G: 10/30/100/300/500/1000 S: 100/300/500 I∆n×1/2 -8% to-2% VAR:-10% to 0% 2000ms Trip Time ±(1%+2ms)
    A/F G: 10/30/100/300/500 AS:100/300/500 I∆n×0.35 -10% to 0%
    B G: 10/30/100/300 S:100/300 I∆n×1/2 -10% to 0%
    x 1 AC G: 10/30/100/300/500/1000 S: 100/300/500 I∆n +2% to +8% VAR:0% to +10% G:550ms S:1000ms Measuring time ±3% of FS
    A/F G: 10/30/100/300/500 AS:100/300/500 I∆n×1.4 (10mA: I∆n×2) 0% to +10%
    B G: 10/30/100/300 S:100/300 I∆n×2 0% to +10%
    6 mA DC I∆n 0% to +10% 10.5s
    x 5 AC G: 10/30/100 S: 100 I∆n×5 +2% to +8% VAR:0% to +10% 410ms
    A/F G: 10/30/100 AS: 100 I∆n×5×1.4 0% to +10%
    B 10/30 I∆n×2×5 0% to +10%
    Ramp 20 to 110% AC 10/30/100/300/500 S: 100/300/500 I∆n -4% to +4% by 10%G: 300ms S: 500ms Measuring time ±3% of FS
    A/F G: 10/30/100/300/500 AS:100/300/500 I∆n×1.4 (10mA:I∆n×2) -10% to +10%
    B G: 10/30/100/300 S: 100/300 I∆n×2 -10% to +10% by 2% /150ms
    Ramp EV 30 to 100% 6 mA DC I∆n -10% to +10% by 2% / 500ms
    What's In The Box?
    • Kewtech KT66DL 12-in-1 Multifunction Tester
    • Kewtech KEWEVSE EV Charging Point Adapter
    • ACC064SP G7 Test remote with remote test button
    • ACC065 G7 Test lead set
    • KAMP12 Mains lead
    • KEW8212-USB download lead
    • Software (CD / or download option)
    • Test lead pouch
    • Soft carry case
    • Padded strap
    • Batteries
    • Instruction Manual
    • Calibration Certificate
    1. Kewtech KTLP10 Extra Long Test Probes
      Kewtech KTLP10 Extra Long Test Probes
      inc VAT £22.80 ex VAT £19.00
      In Stock - Available Next Day
    2. Kewtech 18th Edition Testing Accessory Kit 2
      Kewtech Testing Accessory Kit 2

      As low as inc VAT £148.80 ex VAT £124.00

      In Stock - Available Next Day
    3. Kewtech KEW 2434 Earth Leakage Clamp Meter
      Kewtech KEW 2434 Earth Leakage Clamp Meter
      inc VAT £186.00 ex VAT £155.00
      In Stock - Available Next Day
    4. Kewtech ACCESKIT Earth Spike and Lead Kit for KT65 V2
      Kewtech ACCESKIT Earth Spike and Lead Kit for KT65
      inc VAT £118.80 ex VAT £99.00
      In Stock - Available Next Day
    5. Kewtech KEWISO3 Safety Isolation Kit
      Kewtech KEWISO3 Safety Isolation Kit
      inc VAT £154.80 ex VAT £129.00
      Due to ship September 2021
    6. 50m R2 Wander Lead
      50m R2 Wander Lead
      inc VAT £46.80 ex VAT £39.00
      In Stock - Available Next Day
    7. Kewtech R2 Socket Adaptor
      Kewtech R2 Socket Adaptor
      inc VAT £19.20 ex VAT £16.00
      In Stock - Available Next Day
    8. Professional 18th Edition Safety Lockout Kit (TAG 2)
      Professional Safety Lockout Kit (TAG 2)

      As low as inc VAT £47.94 ex VAT £39.95

      In Stock - Available Next Day
    9. HandyMAN TEK775 Mini AC Earth Leakage Clamp Meter
      HandyMAN TEK775 Earth Leakage Clamp Meter
      inc VAT £82.80 ex VAT £69.00
      In Stock - Available Next Day
    10. Kewtech Kewstick Uno Voltage Detector
      Kewtech Kewstick Uno Voltage Detector Pen
      inc VAT £16.20 ex VAT £13.50
      In Stock - Available Next Day
    11. Kewtech R1 + R2 Jump Leads
      Kewtech R1 + R2 Jump Leads
      inc VAT £16.74 ex VAT £13.95
      In Stock - Available Next Day
    12. Kewtech Testing Accessory Kit 1
      Kewtech Testing Accessory Kit 1
      inc VAT £136.80 ex VAT £114.00
      In Stock - Available Next Day
    13. Kewtech KEWISO2 Safe Isolation Kit
      Kewtech KEWISO2 Safe Isolation Kit
      inc VAT £142.80 ex VAT £119.00
      In Stock - Available Next Day
    14. Kewtech KT1710 Voltage Tester
      Kewtech KT1710 Voltage Tester
      inc VAT £34.74 ex VAT £28.95
      In Stock - Available Next Day
    15. Kewtech KEW3PH Three-Phase Adaptor
      Kewtech KEW3PH Three-Phase Adaptor
      inc VAT £58.80 ex VAT £49.00
      Due to ship December 2021
    16. Kewtech KT1780 Voltage Tester
      Kewtech KT1780 Voltage Tester
      inc VAT £46.74 ex VAT £38.95
      In Stock - Available Next Day
    17. Kewtech Kewlok
      Kewtech Kewlok - Electrical Safety Lockout Padlock
      inc VAT £21.00 ex VAT £17.50
      In Stock - Available Next Day
    18. Kewtech KT103 Wall Socket Checker
      Kewtech KT103 Wall Socket Checker
      inc VAT £15.60 ex VAT £13.00
      In Stock - Available Next Day
    19. Kewtech Kewprove 3 Proving Unit
      Kewtech Kewprove 3 Proving Unit
      inc VAT £70.80 ex VAT £59.00
      In Stock - Available Next Day
    20. Kewtech PAT Adaptor 1
      Kewtech PAT Adaptor 1
      inc VAT £33.00 ex VAT £27.50
      In Stock - Available Next Day
