Metrel MI3152 EurotestXC Multifunction Tester

  • Large, colour touch screen user interface
  • Suitable for all scopes of electrical installation testing
  • Programmable RCD testing, including 6mA test for EVSE
  • Upgradeable and future proof
More Info
In Stock - Available Next Day
Choose Your Free Gift

Metrel MI3152 EurotestXC Multifunction Tester

The Metrel MI3152 EurotestXC Multifunction Tester is a high specification installation tester featuring a large high resolution, colour touch screen user interface.

Testing with the MI3152 can be as exclusive as conducting a one-off diagnostic  test, or as inclusive as programming the instrument with specific test sequences. As such, the unit caters for the ‘Part-P’ registered domestic electrical  installer completing an occasional minor works or installation certificate for example, or perhaps a seasoned electrical inspector/engineer conducting frequent electrical installation condition reports.

With built in help screens and BS7671:2008 amendment 3 fuse tables governing a pass/fail indication for loop test measurements, the Metrel MI3152 EurotestXC is a quick and user friendly instrument suitable for all scopes of electrical contractor.

Electrical installation test functions:

Continuity – two test functions; a 7mA continuity test suitable for testing inductive loads, and a 200mA test for general R1+R2 and R2 testing
Insulation resistance – conducts tests with output voltages ranging between 50-1000VDC
Earth loop impedance - carry out high current and low current (anti-trip) loop tests
Line impedance – safe to conduct tests across live conductors (L-L, L-N)
RCD – automatic and individual testing of the trip times or currents of RCDs (general, selective, type AC, A, F, B and B+)
Voltage – measure and monitor live time TRMS voltage,  phase rotation and frequency
Power (option) – conduct live power and harmonic measurements
Earth resistance (option) – measure ground resistance using 2 or 2 wires
Stakeless earth testing (option) – measure ground resistance using current clamps
Current  (option) – monitor TRMS leakage currents and load currents
First fault leakage current and insulation monitoring devices – test electronic safety devices typically found in sensitive electrical installations (e.g., medical applications)
Light level – measure light levels, ideal for emergency lighting contractors

Below, we have included a comprehensive comparison chart outlining the key differences between the various Metrel multifunction tester models.

  MI3125BT MI3100S MI3100SE MI3102BT MI3152XC MI3155XD
Auto Test Line/Loop X X X X
Autosequence profile X X X X
Pass/Fail Indicators
Pass/Fail System Evaluation X
Automatic Test Sequences X X
Colour Display & Touch Screen X X X X
Download X
Voltage AC - Frequency & TRMS
Current AC - TRMS X X X X
3-Phase System (Phase Sequence)
Differential Leakage Current X X X Optional Optional
Ring Test 200 mA (UK Installations)
Max Test Current 200 mA 2-wire
Max Test Current 200 mA 4-wire X X X X X
Automatic Polary Reversal X X X
Insulation Resistance - Test Voltage 50 - 1000V
Insulation Resistance - Test Voltage 2500V X X X X X
RCD - 10mA - 1000mA
RCD - Type AC, A, F
RCD - Type B
RCD - Type B+
Current & Voltage Harmonics

What's In The Box?

The Metrel MI3152 Eurotest XC Multifunction Tester comes with the following accessories as standard.

  • Metrel MI3152 Eurotest XC Multifunction Tester
  • TEK119 3 wire test lead set with probes and crocodile clips
  • A1003 Mains plug test lead
  • Batteries and charger
  • Neck strap
  • Carry case
  • Metrel calibration certificate
Please click here for full product specifications.
